Clean World Distribution, Inc. Rhino-Mat RHM-CS Operation Manual page 23

RHINO-MAT
4. SERVICING
CAUTION: Turn off water supply before servicing.
The check valve parts are in the metering knob and can be cleaned by
removing the four screws. The knob may be rotated if it is more convenient
to have the adjusting screw on another side of the injector. As with any
injector, if spray jets become clogged or downstream restriction increases
in any manner, the injector will stop drawing fluid. If it is inconvenient
to remove the restriction immediately, the injector may be put back into
operation by turning the water bypass screw further clockwise; this adjusts
the injector to the lower flow rate. The bypass screw should be reset once
the restriction is removed.
CAUTION: When servicing, make sure that replacement parts have
been installed according to drawing. Be certain to check valve parts
are in place.
RETURNS: NO MERCHANDISE MAY BE RETURNED FOR CREDIT
WITHOUT DEMA'S WRITTEN PERMISSION. RETURN MERCHANDISE
AUTHORIZATION NUMBER REQUIRED IN ADVANCE OF RETURN.
WARRANTY: DEMA products are warranted against defective material
and workmanship under normal use and service for one year from the
date of manufacture. This limited warranty does not apply to any products
which have a normal life shorter than one year or failure and damage
caused by chemicals, corrosion, improper voltage supply, physical abuse,
or misapplication. Rubber and synthetic rubber parts such as "o"- rings,
diaphragms, squeeze tubing and gaskets are considered expendable
and are not covered under warranty. This warranty is extended only to
the original buyer of DEMA products. If products are altered or repaired
without prior approval of DEMA, this warranty will be void.
Defective units or parts should be returned to the factory with
transportation prepaid. If inspection shows them to be defective, they will
be repaired or replaced without charge, F.O.B. factory. DEMA assumes no
liability for damages. Return merchandise authorization number, to return
units for repair or replacement, must be granted in advance of return.
44
Liquid Carpet Cleaner
Features:
• Concentrated fast drying, low foaming shampoo ideal for
Rhino Mat Machines
• Deep cleaning with optical brighteners that beautify carpets
Direction for Rhino-Mat Machine:
• Dilute 1 to 3 parts for Heavy Duty. Dilute 1 to 5 parts for Light Duty
• Install according to you Rhino-Mat model's directions
• Dilute one part product to 5 parts water for pre-spot spray
1 Gallon
1 Gallon x 4 pcs / Case
30 Gallon
OPERATIONS MANUAL
5 Gallon
55 Gallon
45
