CalDigit Thunderbolt™ 3 mini Dock Specifications
Package Dimension and Weight
• Height: 0,74 pouces (18,8 mm)
• Width: 4.88 pouces (124 mm)
• Depth: 2,55 pouces (65 mm)
• Cable: 7,87 pouces (200 mm)
Interface
• 1 x Thunderbolt™ 3
• 1 x USB 3.0 (5Gbps)
• 1 x Gigabit Ethernet
Dual DisplayPort
• 2 x DisplayPort 1.2 (4096x2160 60Hz)
Dual HDMI
• 2 x HDMI 2.0 (3840x2160 60Hz)
• 1 x USB 2.0 (480Mb/s)
Power
Bus-Powered
System Requirements
Thunderbolt ™ 3 computers
macOS 10.12 Sierra or later
Windows 10 or later
Environment
0°C ~ 70°C (32°F ~ 158°F)
