Summary of Contents for CalDigit Thunderbolt 3 miniDock
- Page 1 Thunderbolt ™ Double HDMI Double DisplayPort USER GUIDE For more information visit www.caldigit.com...
-
Page 2: Table Of Contents
Table of Contents Section 1 : General Information General Use Warnings Safety Warnings System Requirements In the Box Thunderbolt™ 3 mini Dock Diagram Section 2 : Using the Thunderbolt 3 mini Dock Compatibility Using the Thunderbolt 3 mini Dock Configuring Dual Monitors Supported Resolutions for Dual Monitors Ethernet Section 3 : Technical Support and... -
Page 3: Section 1 : General Information
Thunderbolt 3 or USB-C port. In the case of any issue with the device do not attempt to repair or open the device yourself. Doing so can result in personal injury damage the device and will void the warranty. If you have any issues please contact CalDigit Technical Support. -
Page 4: System Requirements
3 computers macOS 10.12 Sierra or later Windows 10 or later In the Box • 1 x CalDigit Thunderbolt 3 mini Dock -Dual HDMI • 1 x CalDigit Thunderbolt 3 mini Dock -Dual DisplayPort* *DisplayPort conversion to another output, such as HDMI or DVI requires an “Active” adapter / cable... -
Page 5: Thunderbolt™ 3 Mini Dock Diagram
Thunderbolt 3 mini Dock Diagram mini Dock - Dual HDMI mini Dock - Dual DisplayPort... -
Page 6: Section 2 : Using The Thunderbolt
2. Using the Thunderbolt 3 mini Dock Compatibility The Thunderbolt 3 mini Docks are compatible with the following computers. Thunderbolt™ 3 Thunderbolt™ 3 mini Dock Dual HDMI mini Dock Dual DisplayPort ✓ ✓ Thunderbolt™ 3 Mac ✓ ✓ Thunderbolt™ 3 PC USB-C Mac USB-C PC Using the Thunderbolt... -
Page 7: Supported Resolutions For Dual Monitors
Supported Resolutions for Dual Monitors Resolution Video Display Frequency Dual Monitor 2K (2560 x 1600) 60 Hz Full HD (1920 x 1080p) 60 Hz 60 Hz 2K (2560 x 1600) 30 Hz Full HD (1920 x 1080p) 30 Hz Ethernet The Thunderbolt 3 mini Docks have a single Gigabit Ethernet port to connect to a Gigabit Ethernet network. - Page 8 CalDigit Thunderbolt™ 3 mini Dock Specifications Package Dimension and Weight • Height: 0,74 pouces (18,8 mm) • Width: 4.88 pouces (124 mm) • Depth: 2,55 pouces (65 mm) • Cable: 7,87 pouces (200 mm) Interface • 1 x Thunderbolt™ 3 •...
-
Page 9: Section 3 : Technical Support And Warranty Information
To be eligible for customer support and warranty services, please register your CalDigit product on our website. • http://www.caldigit.com/Register/Register.asp When contacting CalDigit Technical Support, make sure to be at your computer and have the following information available: 1. Your Thunderbolt 3 mini Dock serial number 2.
