Summary of Contents for EK E3 Spot

  • Page 2: Table Of Contents

    www.eklights.com TABLE OF CONTENTS Before carrying out any operations with the unit, carefully read this instruction manual and keep it for future reference. It contains important information about the WARNING installation, usage and maintenance of the unit. SAFETY SAFETY DIMENSIONS General Instructions The products referred to in this manual conform to the European Community Directives.

  • Page 3: Dimensions

    www.eklights.com DIMENSIONS DESCRIPTION Compact, quick, feature-packed moving head 1 x 60W OSRAM RGBW LED Infinite RGBW color mixing with 7 gobos + open Ultra smooth dimming and perfectly consistent color mixing Advanced optical system projects saturated colors Flawless motorized pan/tilt movement and gobo indexing Selectable DMX channels 15/18/23 INTRODUCTION...

  • Page 4: Power Linking

    www.eklights.com INTRODUCTION POWER LINKING 1. Safety Rope Mounting Hole 2. Handle 3. Power Indicator 4. Left 6. Right 7. POWER CON In 5. Up 8. POWER CON Out 11. Main Fuse Holder 12. Clamp Fast Holder 9. DMX 3-Pin XLR Out DMX 3-Pin XLR 13.

  • Page 5: Dmx Connection

    www.eklights.com DMX CONNECTION DMX CONNECTION Relation between DMX and Address STARTING ADDRESS STARTING ADDRESS STARTING ADDRESS STARTING ADDRESS MODE ALLOCATION DMX512 Controller 1ST FIXTURE 2ND FIXTURE 3RD FIXTURE 4TH FIXTURE 15CH 001-001 18CH 002-019 23CH 002-024 DMX Signal Cable DMX Signal Cable DMX Signal Cable Follow above method for subsequent fixtures, calculating starting addresses as indicated.

  • Page 6: Technical Specifications

    www.eklights.com TECHNICAL SPECIFICATIONS MENU Photometrics: Misc/Options Main Menu Menu level 2 Menulevel Menu level 4 Remark Light Source：OSRAM 60W RGBW LED Default ： 1 Power Cord: Neutrik POWER CON DMXAddress 1-512 Beam Angle：18° 15CH DMX Functions Omega Bracket：Included (1 pc) Default ：...

  • Page 7: Menu Description

    www.eklights.com MENU MENU DESCRIPTION Motor Setup Auto Test Auto Test … 000-255 Default ： 1. Pan/Tilt inverse on/off selection Pan Fine 000-255 Tilt:=128 Tilt 000-255 Dimmer=255 2. Pan/Tilt motor offset (for fine tuning pan/tilt position) Shutter = 255 Tilt Fine 000-255 3.

  • Page 8: Dmx Channels

    www.eklights.com DMX CHANNELS DMX CHANNELS 15CH 15CH 000-010 Prism 011-127 Prism On Prism 128-189 Left Rotation Fast to Slow 15CH Function Value Percent/Setting Remark 190-193 Stop Rotation 000-255 Rotation Angle: 540 194-255 Right Rotation Slow to Fast Pan Fine 000-255 Shutter closed 000-0 31 Tilt...
  • Page 9 www.eklights.com DMX CHANNELS DMX CHANNELS 23CH 18CH 23CH Function Value Percent/Setting Remark 000-007 WHITE 000-255 Rotation Angle: 540 008-015 Gobo 1 016-023 Gobo 2 Pan Fine 000-255 024-031 Gobo 3 Tilt 000-255 Rotation Angle: 270 032-039 Gobo 4 Tilt Fine 000-255 040-047 Gobo 5...
  • Page 10 www.eklights.com DMX CHANNELS DMX CHANNELS 23CH 23CH 000-127 Stop Rotation Auto Program Speed 000-255 Speed slow to fast 128-189 Left Rotation Fast to Slow Gobo Rotation 000-010 Sound sensitivity OFF 190-193 Stop Rotation Sound Sensitivity 011-255 Sound sensitivity adjustment (low to high) 194-255 Right Rotation Slow to Fast No Function...
