FP-1000
FieldPoint RS-232 Network Module
Highlights
•
RS-232 interface to host computer
•
Built-in isolated RS-485 repeater to connect to FP-1001
network modules
•
Compatible with industry standard Optomux protocol
•
Runs on 11 to 30 VDC power
•
Built-in high efficiency power supply powers I/O modules
•
-40° to +70° C operation
Overview
The FP-1000 is a network module for the FieldPoint system. It
provides connection to an RS-232 network using a simple ASCII
protocol. In addition, it has an isolated RS-485 repeater built in to
transparently add up to 24 FP-1001 network modules to the same
host computer serial port.
This document provides a quick guide to installing and configuring
the FP-1000 network module. For more detailed information on
using the network module, refer to the FP-1000/1001 user manual.
For information on the ASCII protocol used by the network
module, refer to the FP-1000/1001 programmer reference manual.
FieldPoint ™ is a trademark of National Instruments Corporation. Product and company names are
trademarks or trade names of their respective companies.
321697A-01
© Copyright 1997 National Instruments Corp. All rights reserved.
July 1997

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FieldPoint FP-1000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for National Instruments FieldPoint FP-1000

Summary of Contents for National Instruments FieldPoint FP-1000

  • Page 1 For information on the ASCII protocol used by the network module, refer to the FP-1000/1001 programmer reference manual. FieldPoint ™ is a trademark of National Instruments Corporation. Product and company names are trademarks or trade names of their respective companies.

  • Page 2: Din Rail Mounting

    DIN Rail Mounting NOTE: Terminal bases must be connected to the network module before applying power to the module. Do not connect or disconnect terminal bases while power is applied to the network module. The FP-1000 has a simple rail clip for mounting reliably onto a standard 35 mm DIN rail.

  • Page 3: Network Connection

    4. Add terminal bases to the DIN rail with their local bus connectors firmly mated to the FP-1000 local bus connector. The FP-1000 is shipped with a protective cover over the local bus connector. Remove this protective cover, and place it over the local bus connector of the last terminal base in the stack.
  • Page 4 Legend: NC = Not Connected TX = Transmit GND = Ground RTS = Request to Send RX = Recieve DSR = Data Set Ready Figure 4. RS-232 Connector Pinout Up to 24 additional FP-1001 network modules can be connected to this FP-1000 module by using the built in RS-485 repeater.

  • Page 5: Setting The Address And Baud Rate

    These connections are shown in Figure 6. FP-1001 FP-1001 FP-1000 120Ω 120Ω To Host Computer's RS-232 Receive Input From Host Computer's RS-232 Transmit Output 120Ω 120Ω Ground Connect the TX outputs of the FP-1001 to the RX inputs of the FP-1000, and the RX inputs of the FP-1001 to the TX outputs of the FP-1000.
  • Page 6 module is at address 22, and so on. A terminal base is assigned a network address whether an I/O module is inserted into it or not. 1 2 3 4 5 6 7 8 Baud Address Rate 1 2 3 4 5 6 7 8 Switch Cover (Removed) Figure 7.
  • Page 7 Table 1. Network Address Switch Settings (Continued) Switch Network Module Switch Network Module Positions 1-5 Address (Decimal) Positions 1-5 Address (Decimal) 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8...

  • Page 8: Powering The Fp-1000

    Powering the FP-1000 NOTE: Terminal bases must be connected to the FP-1000, and the baud rate switch must be set, before power is applied to the FP-1000. An 11-30 VDC power supply is required by each FieldPoint stack. The network module filters and regulates this supplied power and provides power for all the I/O modules in the stack.

  • Page 9: Specifications

    Specifications Network ports ........1 RS-232 port, 1 RS-485 repeater port Baud Rates ........300, 1200, 2400, 9600, 19200, 38400, 57600, 115200 (switch selectable) Communication parameters ....1 start bit, 8 data bits, 1 stop bit, No parity RS-485 isolation ....... 2500 Vrms breakdown, 250 Vrms operational * ∑...
  • Page 10 Mechanical Dimensions Figure 9 shows the mechanical dimensions of the FP-1000. 4.19 [106.4] 4.31 [109.5] 3.58 [90.9] Figure 9. Mechanical Dimensions...
