OPERATING INSTRUCTIONS
FP-AO-210
8-Channel, 10 V Analog Output Module
Features
The FP-AO-210 is a FieldPoint analog output module with the
following features:
•
Eight 0–10 V outputs
•
0.2 V over-range ability
•
12-bit resolution digital-to-analog converters
•
Onboard diagnostics, including current limit indicators
•
Hot plug and play operation
•
3,000 Vrms input-to-output isolation
•
Double insulated for 250 V safe working voltage
•
Up to 1 kOhm load impedance (with optional external power
supply)
•
–40 to +70 °C operation
Use this document to install the FP-AO-210 and learn about its
features and characteristics. For more information about
configuring and accessing the FP-AO-210 over a network, refer to
the user manual for the FieldPoint network module you are using
with the FP-AO-210.
Install Your Module
The FP-AO-210 mounts on a FieldPoint terminal base (FP-TB-xx)
unit. Because of its hot plug and play operation, you can install the
FP-AO-210 onto a powered terminal base without disturbing the
operation of other modules or terminal bases. The FP-AO-210
receives operating power from the terminal base.
FieldPoint ™ is a trademark of National Instruments Corporation. Product and company names
mentioned herein are trademarks or trade names of their respective companies.
322365A-01
© Copyright 1999 National Instruments Corp. All rights reserved.
May 1999
