Step 1
You will need:
8*Bolt
(H1)
Spring
8*
Washer
(H2)
8*Flat Washer
(H3)
(P2)
Take out the 4 wooden legs and the package of
hardware accessories from the seat(P1).
Insert each leg(P2,P3) completely vertically into each seat frame corner.
Now tighten the bottom bolt at first, then the blot on the top by using
8 Bolts(H1)+8 Flat washer Rings(H3)+8 Spring washer Rings(H2) with the tool provided.
THE JOB IS COMPLETE
PLEASE DISPOSE OF ALL PACKAGING THOUGHTFULLY
IN THE INTEREST OF OUR ENVIRONMENT
Page 4
Assembly Instructions
NEW ZEALAND
TUB CHAIR
(P1)
(P3)
(H1)
(H2)
(H3)
Ver1.1
