Step 2
You will need:
8*Bolt
(H1)
Spring
8*
Washer
(H2)
8*Flat Washer
(H3)
(P3)
Take out the 4 wooden legs and the package of
hardware accessories from the seat(P1).
Insert each leg(P3,P4) completely vertically into each seat frame corner.
Now tighten the bottom bolt at first, then the blot on the top by using
8 Bolts(H1)+8 Flat washer Rings(H3)+8 Spring washer Rings(H2) with the tool provided.
THE JOB IS COMPLETE
PLEASE DISPOSE OF ALL PACKAGING THOUGHTFULLY
IN THE INTEREST OF OUR ENVIRONMENT
Page 4
(P1)
(P4)
(H1)
(H2)
(H3)
Assembly Instructions
NEW CASTLE
TUB CHAIR
Ver1.1
Advertisement
Related Manuals for Jar Furniture NEW CASTLE
Summary of Contents for Jar Furniture NEW CASTLE
- Page 1 Step 2 Assembly Instructions You will need: 8*Bolt (H1) NEW CASTLE Spring Washer TUB CHAIR (H2) 8*Flat Washer (P1) (H3) (P4) (P3) (H1) (H2) (H3) Take out the 4 wooden legs and the package of hardware accessories from the seat(P1).
- Page 2 What you Need 1x Allen Key (5mm) (PROVIDED) the back of a chair Chair seat (P2) (P1) 8*Bolt (H1) 8*Spring Washer (H2) 8*Flat Washer (H3) 2*Front legs 2*Back legs Please make sure you have all (P3) (P4) these parts before you start. Step 1 (P2) (P2)
