Lehigh Collection
Dining Chair
Assembly Guide
Left Side Assy
INSERTS TO
INSIDE
Right Side Assy
2) Attach the seat assembly to the legs
with (4) "B" bolts. The Highwood badge
should be visible from the back.
3) Tighten all bolts with supplied hex key.
highwood
NATURE'S CLOSEST RIVAL
Back Assy
1) Attach the left & right leg assemblies
to the back assembly with (4) "A" bolts.
DO NOT FULLY TIGHTEN.
A x4
For information on Care and Cleaning or to register your
highwood product, please visit www.highwood-usa.com.
Seat Assy
B x4
HARDWARE
A
#1/4-20 x 2"
x4
B
#1/4-20 x 1-1/2"
IMPORTANT!
DO NOT fully tighten the bolts until all
bolts are started. Once all bolts are inserted,
go back & tighten all the bolts.
Retain these instructions for future reference
INCLUDED TOOLS
5/32" HEX KEY
x4
CHDL1
03.13.18
PAGE 1 OF 1
