Lehigh Collection
Counter/Bar Stool
Assembly Guide
LEG
BRACE
A
1) Install Braces Between Legs
Using (4) "A" Bolts as Shown.
2) Attach Leg Assembly to Seat
Using (4) "A" Bolts and (4) "B"
Bolts as Shown.
highwood
NATURE'S CLOSEST RIVAL
LEG
A
BRACE
B
A
SEAT
For information on Care and Cleaning or to register your
highwood product, please visit www.highwood-usa.com.
A
B
LEG ASSEMBLY
B
A
HARDWARE
1/4-20 X 2"
1/4-20 X 3"
IMPORTANT!
DO NOT fully tighten the bolts until all
bolts are started. Once all bolts are inserted,
go back & tighten all the bolts.
Retain these instructions for future reference
INCLUDED TOOLS
5/32" HEX KEY
CHR-KS2/3
05.23.18
x8
x4
PAGE 1 OF 1
