highwood Deck Storage Box Assembly Manual

Deck Storage Box
Assembly Guide
A
SIDE PANEL
A
FRONT PANEL
FLOOR PANEL
2) With the Box on it's Side, Insert
the Floor Panel into the Box and
Fasten with (8) "B" Bolts
3) Tighten all Bolts.
highwood
NATURE'S CLOSEST RIVAL
1) Place Front Panel on Flat Surface
With Inside of Panel Facing Up. Insert
A the Dowels in the Side Panels into the
Holes on the Front Panel and Fasten
with (4) "A" Bolts Thru Holes in Legs.
BACK PANEL
Repeat for the Back Panel.
SIDE PANEL
A
B
For information on Care and Cleaning or to register your
highwood product, please visit www.highwood-usa.com.
HARDWARE
A
#1/4-20 x 2"
x8
B
#1/4-20 x 1-3/4"
C
x6
No.14 x 1" WOOD SCREW
IMPORTANT!
DO NOT fully tighten the bolts until all
bolts are started. Once all bolts are inserted,
go back & tighten all the bolts.
Retain these instructions for future reference
INCLUDED TOOLS
5/32" HEX KEY
#3 PHILLIPS BIT
x8
AD-DBXL1
07.23.18
PAGE 1 OF 2
