- Page 1 Hardware Manual: Customer Development Board PNEV5180B BL ID Doc Rev 1.00 Approved — 2015.11.13 Document information Info Content Author Pavel Slamnik Author Role Design Engineer Keywords Customer Development Board PNEV5180B, RFID, NFC,...
-
Page 2: Revision History
First Version Pavel Slamnik Copyright: @2009, NXP Semiconductors The information contained herein is the exclusive and confidential property of NXP Semiconductors and, except as otherwise indicated, shall not be disclosed or reproduced in whole or in part. SRS Template_vs 1.0 public ©... - Page 3 Hardware Manual BL ID Project Name: Integration Manual Project ID: 62743 Contents SRSt Template 1.0 public © NXP B.V. 2015. All rights reserved Doc ID: DOC-XXXXXX Doc Rev 1.00 Approved — 2015.11.13 3 of 16...
- Page 4 Hardware Manual BL ID Project Name: Integration Manual Project ID: 62743 STS Template 1.0 public © NXP B.V. 2015. All rights reserved Doc ID: DOC-XXXXXX Doc Rev 1.00 Preliminary — 2015.11.13 4 of 16...
-
Page 5: Customer Evaluation Board Pnev5180B: Photo
Hardware Manual BL ID Project Name: Integration Manual Project ID: 62743 1. Customer Evaluation Board PNEV5180B: Photo Figure 1: Customer Evaluation Board PNEV5180B – side view. Figure 2: Customer Evaluation Board PNEV5180B – top view. STS Template 1.0 public © NXP B.V. 2015. All rights reserved Doc ID: DOC-XXXXXX Doc Rev 1.00 Preliminary —... -
Page 6: Customer Evaluation Board Pnev5180B: Description
2. Customer Evaluation Board PNEV5180B: Description Operational desription Customer Evaluation Board PNEV5180B is an example of implementation of ISO/IEC 14443A and ISO/IEC 14443B reader/writer, NFC reader/writer and Card Emulation Device on the same printed board. Middle size antenna, implemented on the same pcb (reader and antenna can be broken into separate parts), permits reading/writing on distance up to 50 mm (RFID card or other NFC device). - Page 7 Hardware Manual BL ID Project Name: Integration Manual Project ID: 62743 Figure 3: Customer Evaluation Board PNEV5180B - Block diagram. STS Template 1.0 public © NXP B.V. 2015. All rights reserved Doc ID: DOC-XXXXXX Doc Rev 1.00 Preliminary — 2015.11.13...
- Page 8 Hardware Manual BL ID Project Name: Integration Manual Project ID: 62743 Figure 4: Customer Evaluation Board PNEV5180B: dimensions, pcb with elements. STS Template 1.0 public © NXP B.V. 2015. All rights reserved Doc ID: DOC-XXXXXX Doc Rev 1.00 Preliminary — 2015.11.13...
-
Page 9: Customer Evaluation Board Pnev5180B: Specification
Hardware Manual BL ID Project Name: Integration Manual Project ID: 62743 3. Customer Evaluation Board PNEV5180B: SPECIFICATION 3.1. Customer Evaluation Board PNEV5180B: Specifications Table 2: Customer Evaluation Board PNEV5180B – specifications Antenna PCB type, 65 mm x 65 mm Contactless operating frequency 13.56 MHz... - Page 10 Hardware Manual BL ID Project Name: Integration Manual Project ID: 62743 Electrical and Mechanical Specifications 5V DC 5%, 500 mA (via USB port) or Power Supply external power suply 7.5 V DC ±15% / 500 mA PCB Dimensions (L x W x 152 mm x 68 mm x 15 mm Weight approx.
- Page 11 Hardware Manual BL ID Project Name: Integration Manual Project ID: 62743 3.2. Customer Evaluation Board PNEV5180B: Electrical characteristics Table 3: Customer Evaluation Board PNEV5180B – Electical Specifications Operating Range Symbol Description Conditions Unit PWR_DC DC Power Supply Active Reader Ambient Temperature C...
-
Page 12: Installing Manual
Customer Evaluation Board PNEV5180B and personal computer. External power supply 7.5 V DC / 500 mA is connected to power jack X4 to supply Customer Development Board PNEV5180B. On board IC LT1129IST-5 is used to stabilize voltage to 5 Note 1: Power supply from USB port on personal computer has to comply with LPS requirement of IEC60950-1. - Page 13 General user instructions Reading/writing is possible with MIFARE contactless cards, FeliCa cards or with NFC device. PNEV5180B board can detect contactless card or NFC device up to 50 mm from the center reader's antenna. PNEV5180B board can emulate contactless (NFC) card.
- Page 14 Hardware Manual BL ID Project Name: Integration Manual Project ID: 62743 5.2. Instructions for safe work, maintaining and care • Be careful not to damage the connectors, antenna, PCB, ICs and other connected parts. • Because of the specifics of the device and the damage, only quallified staff, authorized by the producer, are allowed to repair the device.
-
Page 15: Electromagnetic Compatibility
PNEV5180B board has passed spurious emissions test without shielding and is certified as limited modular transmitter. Under FCC part 15.212(b), shielding is not required. Concerning §2.803 the PNEV5180B board will be not offered for sale to other parties or to end users located in a residential environment. - Page 16 Project Name: Integration Manual Project ID: 62743 COMPLIANCE INFORMATION according to 47CFR 2.1033 We, declare that the product Customer Evaluation Board PNEV5180B FCC 12.225, Limited Modular Approval, FCC ID: OWRPNEV5180B is in conformity with Part 15 of the FCC Rules.
