4. Disconnect the electrical connector, located on the right side of the sump. (Fig.5) .
5. Release the right sump locking tabs by turning 90º. This allows the sump to be lifted completely from its
location. (Fig. 11)
6. Gently lift up the sump, taking care to keep level so as not to spill any water. Sit the assembly in the sink.
7. Release the left sump locking tabs by turning 90º, then lift off the Nozzle. (Fig.3)
8. Lift out the transducer and carefully tilt, as shown, so that the liquid drains out of the sump. (Fig.13)
9. Put a small amount of washing up liquid into the sump, and using the supplied brush, gently clean all
surfaces in the sump and gently clean the transducer including the metal discs located in the top grooved
surface. (Fig.14)
10. When cleaned, thoroughly rinse the sump with clean water to remove all traces of washing up liquid.
11. Clean the Nozzle with the brush and flush out thoroughly with water. (Fig.15)
12. Reverse the above steps to reassemble.

Air filter

1. Gently lift out the fuelbed and place carefully on the ground.
2. Gently slide the air filter upwards out of its plastic holder. (Fig.16)
3. Gently rinse with water in the sink and dry with fabric towel before returning.
4. Replace the filter making sure that the coarse black filter is facing the front of the fire.

Additional Information

After Sales Service
Your product is guaranteed for one year from the date of purchase. Within this period, we undertake to
repair or exchange this product free of charge (excluding transducer discs & subject to availability) provided
it has been installed and operated in accordance with these instructions. Your rights under this guarantee
are additional to your statutory rights, which in turn are not affected by this guarantee.
The transducer is a consumable item and may need to be replaced through time, depending on its usage.
Replacement transducers can be purchased from your supplier.
The transducer has a 12 month warranty period.
CAUTION: Do not use if the heater's mains power lead is damaged. Such use may cause a hazard. If
damaged, the mains power lead must be replaced by the manufacturer or its authorised dealer.
Recycling
For electrical products sold within the European Community - At the end of the electrical products
useful life it not be disposed of with household waste. Please recycle where facilities exist. Check
with your Local Authority or retailer for recycling advice in your country.
Patent / Patent Application
Products within the Optimyst range are protected by one or more of the following patents and patent
applications:
Great Britain GB2460259B, GB2475794B, GB2418014, EP2029941, GB2436212, GB2402206B
United States US8413358, US8136276, US7967690, US8574086
Russia RU2434181
European EP2029941, EP2315976, EP1787063 (A1), EP2388527
China CN101883953A, CN102105746A, CN101057105 (A), CN101438104
Australia AU2009248743A1, AU2007224634
Canada CA2725214, CA2579444, CA2645939
