ATA C B
OMMAND LOCK AND
Identify Drive — Drive Attribute Data
Word
Address
0
1
2
3
4
5
6
7-8
9
10-19
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
3600D-04DSR
S D
ET ESCRIPTION
Table 35: Identify Drive — Drive Attribute Data
Data Default Bytes Data Description
045Ah 2
XXXXh 2
0000h 2
00XXh 2
0000h 2
XXXXh 2
XXXXh 2
XXXXh 4
0000h 2
XXXXh 20
S S
ILICON YSTEMS
All unauthorized use and/or reproduction is prohibited.
P
SSD-D
General configuration bit information
• 15: Non-magnetic disk
• 14: Formatting speed latency
permissible gap needed
• 13: Track Offset option supported
• 12: Data Strobe Offset option supported
• 11: Over 0.5% rotational speed
difference
• 10: Disk transfer rate >10Mbps
• 9: 10Mbps >= disk transfer rate >5Mbps
• 8: 5Mbps >= disk transfer rate
• 7: Removable cartridge drive
• 6: Fixed drive
• 5: Spindle Motor Control option
executed
• 4: Over 15μs changing head time
• 3: Non-MFM encoding
• 2: Soft sector allocation
• 1: Hard sector allocation
• 0: Reserved
Number of cylinders
Reserved
Number of heads
Number of unformatted bytes per track
Number of unformatted bytes per sector
Number of sectors per track
Number of sectors per device
Reserved
Serial number
P
ROPRIETARY
34
AGE
(I)-3600 D S
XXX ATA HEET
F 2, 2009
EBRUARY
