Signal Descriptions; Table 8: Signal Descriptions - Silicon Systems SiliconDrive SSD-D16G(I)-3600 Datasheet

E S
LECTRICAL PECIFICATION
S D
IGNAL ESCRIPTIONS
Signal Name
A2-A0
-CS0,-CS1
-CSEL
D15-D0
-DMACK
DASP
This document and the information contained within it is confidential and proprietary to SiliconSystems, Inc.
3600D-04DSR

Table 8: Signal Descriptions

Pin(s) Type Description
36, 33, I Address Inputs. These signals are
35 asserted by the host to access the task
registers in the device.
37, 38 I In the true IDE mode, -CS0 is the chip
select for the task file registers while -CS1
is used to select the Alternate Status
register and the Device Control register.
28 I Cable Select. This internally pulled-up
signal is used to configure this device as a
master or a slave when the jumper
configuration is in CSEL mode.
When this pin is:
• Grounded by the host, this device is
• Open, this device is configured as a
18, 16, I/O Data Inputs/Outputs. This is the 8-bit or
14, 12, 16-bit bidirectional interface between the
10, 8, 6, host and device. The lower eight bits are
4, 3, 5, 7, used for 8-bit register transfers.
9, 11, 13,
15, 17
29 I DMA Acknowledge. This signal is used by
the host in response to DMARQ to initiate
DMA transfers. The DMARQ/-DMACK
handshake is used to provide flow control
during the transfer. When -DMACK is
asserted, -CS0 and -CS1 are not asserted
and transfers are 16-bits wide.
39 I/O Disk Active/Slave Present. This open
drain output signal is asserted low any time
the drive is active. In a master/slave
configuration, this signal is used by the
slave to inform the master that a slave is
present.
S S
ILICON YSTEMS
All unauthorized use and/or reproduction is prohibited.
P 7
AGE
SSD-D
XXX
configured as a master.
slave.
P
ROPRIETARY
(I)-3600 D S
ATA HEET
F 2, 2009
EBRUARY
