Silex technology Network Adapter C-6700WG Setup Manual page 2

Con gure Through a Wired LAN
1.
The following items are required:
Install the printer driver on your PC.
-Ethernet Hub -network cable -USB cable
For details, refer to the manual that came with
your printer.
Use to connect this product and a printer. (Install the printer driver on your PC and make
There is no need to purchase a new USB cable if a cable was
sure you can print with a directly attached USB
bundled with the printer to be connected to this product.
connection from your computer before using
this product.)
8.
Click Wired. * In a Windows XP (SP2 or higher) or Vista environment, the above message
will be displayed. Select Yes.
* The User Account Control screen is displayed when con guration is performed
on Windows Vista. Select Continue.
14. 15.
Con rm the con guration parameters and click Select Yes and click Finish.
Execute.
Step2 : Install the Application
2.
Important: It is necessary to install the
applications on each computer that
will use the Canon multifunction
printer.
1.
Insert the CD-ROM (CX User Software) into your Check the message and click OK.
Windows PC.
8. 9.
Select Yes and click Finish. Add CX Print Wizard screen is displayed.
Click Next.
Step3 : Use the Canon Multifunction Printer
Printing:
The printer is set up as a Windows printer. Just select the approriate Canon printer
when printing.
Scanning and other functions:
1.
Click start - All Programs - SX Virtual Link - SX Virtual Link.
2. 3.
Connect a network cable to this product. Connect the AC adapter to this product and the power
Connect the other end of the network cable
plug to the outlet.
to a network hub, switch, or router.
(Do not connect the printer to this product yet. Printer
will need to be connected at '17'.)
* Use a crossover cable when connecting this product directly to the PC.
. 9 1 . 0
Read the SOFTWARE LICENSE AGREEMENT and
Quick Setup screen is displayed.
Read the notes on the screen and click Next. click Yes.
17.
To re ect the wireless con guration, disconnect the power
plug from the outlet and unplug the network cable.
* If you are to use this product in a wired LAN environment after you nish the
setup, you do not have to unplug the network cable.
4.
3.
Click Application Installation. Check the notes on the screen and click Next.
* The User Account Control screen is displayed when con guration is
performed on Windows Vista. Select Continue.
10. 11.
Select the destination print server and Click Click Next.
Next.
3.
2.
Con rm " " (available). Select the Canon multifunction printer and click Connect.
4.
Verify the Link LED (Green) turns on and the
Wireless LED (Green) turns o .
1 . 1
Select a product to be con gured and click Next.
* If your product is not displayed in the list, click Search.
* If multiple products are displayed in the list, check the
Ethernet Address on the label of this product.
Connect the printer to be shared over the network along
with this product via a USB cable and insert the power plug
of this product into the outlet.
5.
Read the SOFTWARE LICENSE AGREEMENT and click
Yes.
12.
Con rm the con guration parameters and
click Finish.
* If the IP address of this product is changed after the port is created,
printing from the port will be unavailable.
4.
Con rm " " (connected).Refer to the operation manual
of the Canon multifunction printer to use the scanner,
card reader, and fax function.
5. 6.
Insert the CD-ROM (CX User Software) into your Windows
Read the message on the screen and click OK .
PC.
12. 13.
When you will use this product in the wireless
Select Get IP Address Automatically
network, select the wireless network that you wish
and click Next.
to use from the list, enter the wireless network key
and click Next.
6.
7.
Select the applications you want to install
Click Start.
and click Next.
* CX Print
is for printing from your computer.
* SX Virtual Link is for scanning and other functions. .
13. 14.
Select the printer you want to use with this Follow the instructions in the message on the
product and click Next.
screen and click Finish.
Important: One person can be connected with SX Virtual Link
for scanning at a time. When you are done scanning, you should
disconnect from the Canon multifunction printer in SX Virtual
Link so it will be available for another PC to be able to connect.
7.
Startup menu is displayed.
Click Print Server Setup.
* If the wireless network that you wish to use is not
shown in the list, click Detailed Con g and con gure
each setting.
* When in a Windows XP (SP2 or higher) or Vista environment, the above message will be
displayed. Select Yes.
* The message below is displayed when installing the application on Windows Vista.
(1) Windows Security screen is displayed. Choose Install.
(2) The screen to con rm the user adding the application to the Windows rewall exemptions list
is displayed. Select Yes.
15.
Click Finish.
Now, the printer can be used in a network environment.
To disconnect:
Select the Canon multifunction printer and click
Disconnect.
