SIIG Network Device EVTEK-5103 Overview

Providing Power for EVTEK-5103:

Choosing EVTEK-5103 Operation Modes:

Switch Position:
MSB (* mid (*
LO LO
LO LO
LO HI
LO HI
HI LO
HI LO
HI HI
HI HI
(* when seen from the front, MSB switch is the rightmost, and LSB is the leftmost

Implementing Serial Connection:

Connect the EVTEK-5103 Board's serial port 1 and PC's available serial port with a cross-connected serial cable

Interfacing the EVTEK-5103 from a PC:

It is recommended to use the "EVTEK-5103 Interface" application, that is specifically made for this purpose. The
user guide for the application: START MENU
If using a terminal program instead of "EVTEK-5103 Interface" application:
Use Hyperterminal (not under Windows 2000), or Tera Term

Terminal Program Connection parameters:

Baud rate = 57600 kbps
Parity = none
Enter key = CR+LF
Also, set terminal scrollback buffer to at least 500 lines for convenience of use.
EVTEK-5103 Board's Programmable Peripheral Datasheets:
8051 AT89C55WD
CPU: DS89C420
UART: TL16C552
PIO: M82C55A
1) If the main power input is used, connect the MASCOT 8717 plug
2) If the auxiliary power input is used, connect a standard 9 V battery
Mode
nr.
LSB (*
0
LO
HI 1
LO 2
HI 3
LO 4 Start executing program code from 4000h
HI 5 Stand-alone – does first mode 3, then 4
LO 6 Board's Embedded Debugger CLI Tool
HI 7
PROGRAMS
Data bits = 8
Stop bits = 1
Local echo = no
http://www.atmel.com/dyn/resources/prod_documents/DOC1921.PDF
http://pdfserv.maxim-ic.com/arpdf/DS89C420.pdf
http://focus.ti.com/lit/ds/symlink/tl16c552a.pdf
http://www.okisemi.com/datadocs/doc-eng/msm82c55a_2rs.pdf
Corresponding Operation Mode:
Receive a file from PC to Board RAM
Transmit a file from Board RAM to PC
Copy lowest 32 kB RAM to EEPROM
Copy 32 kB EEPROM to lowest RAM
Test mode – blinks Board's I/O-ports
EVTEK-5103
http://hp.vector.co.jp/authors/VA002416/teraterm.html
Flow control = none
COM port = the one you're using on PC
Destructive backspace = yes
Terminal
Response:
"(enter)RCV:"
"(enter)TMT:"
"(enter)R2E:"
"(enter)E2R:"
"(enter)EXC:"
"(enter)S-A:"
"(enter)DBG:"
"(enter)Test"
INTERFACE MANUAL
