Page 1: User Manual
BiPAC 6300VNOZ VoIP Wireless-N VPN Broadband Router User Manual Version Released: 1.02b.rc6.dt5 Last Revised Date: October 30, 2013... -
Page 2: Table Of Contents
Table of Contents Chapter 1................................1 1.1 Introducing the BIPAC 6300VNOZ........................1 1.2 Features of the BIPAC 6300VNOZ ........................3 Network Protocols and Features........................3 Firewall ................................3 Quality of Service Control..........................4 Wireless LAN..............................4 VoIP.................................4 USB Application Server ...........................4 IPTV Applications ............................4 Management ..............................4 1.3 Hardware Specifications..........................5 Physical Interface............................5 1.4 Applications for the BIPAC 6300VNOZ ......................6 Chapter 2................................7 2.1 Important note for using the BIPAC 6300VNOZ ..................7 2.2 Package Contents ............................8 2.3 The Front LEDs..............................9 2.4 The Rear Ports ............................11 2.5 Power Source .............................12 2.6 Cabling................................14 Chapter 3................................15 3.1 Before Configuration..........................15 3.1.1 Configuring a PC in Windows 7 ......................16 3.1.2 Configuring a PC in Windows Vista......................19 3.1.3 Configuring a PC in Windows XP ......................21 ... - Page 3 4.2.1 Device Info ............................31 4.2.2 System Log............................33 4.2.3 Statistics...............................34 4.2.4 DHCP Table ............................37 4.2.5 Disk Status ............................38 4.2.6 VoIP Status............................39 4.2.6.1 VoIP Status ............................39 4.3 Quick Start..............................40 4.4 Configuration..............................44 4.4.1 Interface Setup ............................45 4.4.1.1 Internet ............................45 4.4.1.2 LAN..............................49 4.4.1.3 Wireless............................53 4.4.1.4 Wireless MAC Filter ........................65 4.4.2 Advanced Setup...........................66 4.4.2.1 Firewall............................66 4.4.2.2 Routing............................67 4.4.2.3 NAT..............................69 4.4.2.4 Static DNS............................74 4.4.2.5 QoS..............................75 4.4.2.6 Interface Grouping........................76 4.4.2.7 Port Isolation..........................78 4.4.2.8 Time Schedule..........................79 4.4.3 VoIP..............................80 4.4.3.1 Basic ..............................81 4.4.3.2 Media ............................82 4.4.3.3 Advanced ............................83 4.4.3.4 Speed Dial .............................84 4.4.3.5 Call Features..........................85 4.4.4 Access Management..........................87 ...
- Page 4 Problems starting up the router ......................111 Problems with the WAN Interface......................111 Problems with the LAN Interface......................111 Recovery procedures for non‐working routers ..................112 APPENDIX ................................113...
-
Page 5: Introducing The Bipac 6300Vnoz
Introduction the BIPAC 6300VNOZ 1.1 Introducing the BIPAC 6300VNOZ Thank you for purchasing BIPAC 6300VNOZ Router. The BIPAC 6300VNOZ is a compact and advanced broadband gateway(router) that offers flexible and multiple internet connection services for home, SOHO and office users to enjoy high-speed, high-level security internet connection via cellular wireless and/or Ethernet WAN. - Page 6 easily which they get from ISP, then surf the Internet immediately. Firmware Upgradeable Device can be upgraded to the latest firmware through the WEB based GUI.
-
Page 7: Features Of The Bipac 6300Vnoz
1.2 Features of the BIPAC 6300VNOZ • Gigabit Ethernet WAN (GbE WAN) for Fibre (FTTC/ FTTP/ FTTH) high WAN throughput • Gigabit Ethernet LAN • IPv6 ready (IPv4/IPv6 dual stack) • Multiple wireless SSIDs with wireless guest access and client isolation •... -
Page 8: Quality Of Service Control
Quality of Service Control • Traffic prioritization management based-on Protocol, Port Number and IP Address (IPv4/ IPv6) Wireless LAN • Compliant with IEEE 802.11 b/ g/ n standards • 2.4 GHz - 2.484GHz radio band for wireless • Up to 300 Mbps wireless operation rate •... - Page 9 • Web-based GUI for remote and local management (IPv4/ IPv6) • Firmware upgrades and configuration data upload and download via web-based GUI • Supports DHCP Server/ Client/ Relay • Supports SNMP v1, v2, v3. MIB-I and MIB-II TR-069* supports remote management •...
-
Page 10: Hardware Specifications
1.3 Hardware Specifications Physical Interface • Detachable antennas: 2 high performance external antennas • SIM Card slot: Mini SIM card (2FF) slot for mobile broadband connectivity • VoIP Phone port: 2 RJ-11 FXS for connecting to regular telephones • USB: 1 USB 2.0 type A port for storage service •... -
Page 11: Applications For The Bipac 6300Vnoz
BIPAC 6300VNOZ is embedded with a module supporting mobile SIM card. It can be used to connect to high speed mobile broadband connection. BiPAC 6300VNOZ also supports one USB ports for your mobile dongle. It can be used to connect to high speed mobile broadband connection, too. - Page 12 Broadband router mode BIPAC 6300VNOZ has a Gigabits Ethernet WAN port to connect to your Fibre/ Cable/ xDSL modem.
-
Page 13: Chapter 2
Do not use the same power source for the BIPAC 6300VNOZ as other equipment. Do not open or repair the case yourself. If the BIPAC 6300VNOZ is too hot, turn off the power immediately and have it repaired at a qualified service center. Warning ... -
Page 14: Package Contents
2.2 Package Contents BIPAC 6300VNOZ - VoIP Wireless-N VPN Broadband Router Quick Start Guide CD containing user manual Ethernet (RJ-45 CAT-5) cable Two detachable Antennas Power adapter... -
Page 15: The Front Leds
2.3 The Front LEDs Status Meaning Green System ready Power Boot failed Green AC working and battery OK Orange Only AC working, battery fail and has to change battery Battery Orange blinking AC fail and battery working The power input is from power adapter not UPS Green Transmission speed hitting 1000Mbps Orange... - Page 16 Green blinking quickly Signal strength 75% ~ 50% Orange blinking quickly Signal strength 50% ~ 25% Orange blinking slowly Signal strength < 25% Orange No signal, but module OK module fails or No module Obtaining IP failure Green Having obtained an IP address successfully Internet Router in bridged mode or WAN connection not present.
-
Page 17: The Rear Ports
2.4 The Rear Ports Port Meaning Power source selector. Switch between DC power adapter and UPS (DC). Power Source Connect the supplied DC power adapter to this jack. After the device is powered on, press it 6 seconds or above: to restore to factory default settings (this is used when you can not login to the router, e.g. -
Page 18: Power Source
2.5 Power Source 6300VNOZ offers two kinds of power input, namely, DC power Adapter and DC UPS (or BBU). 6300VNOZ can take the advantage of UPS (Uninterruptible Power Supply) to keep working even if the power outage hit your router when the router in working in DC UPS mode. (a picture of the rear focusing on the power source) (a shot from the front panel, with second icon being identified as the Battery LED) How to switch between the two power input:... - Page 19 The meanings of the different status of Battery LED: Green lit: AC is working, UPS battery working well Orange Lit: Only AC is working, but Battery fails. And you have to change battery Orange Blinking: AC fails, but battery is working...
-
Page 20: Cabling
Make sure that all other devices (e.g. telephones, fax machines, analogue modems) connected to the same telephone line as your Billion router have a line filter connected between them and the wall socket (unless you are using a Central Splitter or Central Filter installed by a qualified and licensed electrician), and that all line filters are correctly installed in a right way. -
Page 21: Chapter 3
The TCP/IP protocol stack and Ethernet network adapter must be installed. If not, please refer to your Windows-related or other operating system manuals. Any TCP/IP capable workstation can be used to communicate with or through the BIPAC 6300VNOZ. To configure other types of workstations, please consult the manufacturer’s documentation. -
Page 22: Configuring A Pc In Windows 7
3.1.1 Configuring a PC in Windows 7 Go to Start. Click on Control Panel. Then click on Network and Internet. When the Network and Sharing Center window pops up, select and click on Change adapter settings on the left window panel. Select the Local Area Connection, and right click the icon to select Properties. - Page 23 IPv4: Select Internet Protocol Version 4 (TCP/IPv4) then click Properties In the TCP/IPv4 properties window, select the Obtain an IP address automatically and Obtain DNS Server address automatically radio buttons. Then click OK to exit the setting. Click OK again in the Local Area Connection Properties window to apply the new configuration.
- Page 24 IPv6: Select Internet Protocol Version 6 (TCP/IPv6) then click Properties In the TCP/IPv6 properties window, select the Obtain an IPv6 address automatically and Obtain DNS Server address automatically radio buttons. Then click OK to exit the setting. Click OK again in the Local Area Connection Properties window to apply the new configuration.
-
Page 25: Configuring A Pc In Windows Vista
3.1.2 Configuring a PC in Windows Vista 1. Go to Start. Click on Network. Then click on Network and Sharing Center at the top bar. 2. When the Network and Sharing Center window pops up, select and click on Manage network connections on the left window pane. - Page 26 IPv4: 4. Select Internet Protocol Version 4 (TCP/IPv4) then click Properties. 5. In the TCP/IPv4 properties window, select the Obtain an IP address automatically and Obtain DNS Server address automatically radio buttons. Then click OK to exit the setting. 6. Click OK again in the Local Area Connection Properties window to apply the new configuration.
-
Page 27: Configuring A Pc In Windows Xp
3.1.3 Configuring a PC in Windows XP IPv4: 1. Go to Start / Control Panel (in Classic View). In the Control Panel, double-click on Network Connections 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window, click Properties. 4. - Page 28 IPv6: IPv6 is supported by Windows XP, but you should install it first. Act as shown below: 1. On the desktop, Click Start > Run, type cmd, then press Enter key in the keyboard, the following screen appears. 2. Key in command ipv6 install Configuration is OK now, you can test whether it works ok.
-
Page 29: Configuring A Pc In Windows 2000
3.1.4 Configuring a PC in Windows 2000 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and Dial-up Connections. 2. Double-click Local Area Connection. 3. In the Local Area Connection Status window click Properties. 4. -
Page 30: Configuring A Pc In Windows 98/Me
3.1.5 Configuring a PC in Windows 98/Me 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Configuration tab. 2. Select TCP/IP ->NE2000 Compatible, or the name of your Network Interface Card (NIC) in your PC. -
Page 31: Configuring A Pc In Windows Nt4.0
3.1.6 Configuring a PC in Windows NT4.0 1. Go to Start / Settings / Control Panel. In the Control Panel, double-click on Network and choose the Protocols tab. 2. Select TCP/IP Protocol and click Properties. 3. Select the Obtain an IP address from a DHCP server radio button and click OK. -
Page 32: Factory Default Settings
3.2 Factory Default Settings Before configuring your router, you need to know the following default settings. Web Interface: Username: admin Password: admin LAN Device IP Settings: IP Address: 192.168.1.254 Subnet Mask: 255.255.255.0 DHCP server: DHCP server is enabled. Start IP Address: 192.168.1.100 IP pool counts: 20 3.2.1 Username and Password The default username and password are “admin”... -
Page 33: Lan Port Addresses
3.3 LAN Port Addresses The parameters of LAN ports are pre-set in the factory. The default values are shown below. IPv4: 192.168.1.254 IP address 255.255.255.0 Subnet Mask Enabled DHCP server function 100 IP addresses continuing from 192.168.1.100 through IP addresses for distribution to PCs 192.168.1.199 3.4 Information from your ISP Before configuring this device, you have to check with your ISP (Internet Service Provider) what kind of service... -
Page 34: Chapter 4
Open your web browser, enter the IP address of your router, which by default is 192.168.1.254, and click “OK”, a user name and password window prompt will appear. The default username and password are “admin” and “admin”. Congratulation! You are now successfully logged on to the BIPAC 6300VNOZ! - Page 35 At the configuration homepage, the left navigation pane where bookmarks are provided links you directly to the desired setup page, including: Status(Device Info, System Log, Statistics, DHCP Table, Disk Status, VoIP Status) Quick Start (Wizard Setup) Configuration (Interface Setup, Advanced Setup, VoIP, Access Management, Maintenance) Language Please see the relevant sections of this manual for detailed instructions on how to configure your router.
-
Page 36: Status
4.2 Status In this section, you can check the router working status, including Device Info, System Log, Statistics, DHCP Table, Disk Status, and VoIP Status. - Page 37 4.2.1 Device Info Users will see device's basic information in this page. EWAN...
- Page 38 Device Information Model Name: Show model name of the router Firmware Version: This is the Firmware version MAC Address: This is the MAC Address IPv4: IP Address: LAN port IPv4 address. Subnet Mask: LAN port IP subnet mask. DHCPv4 Server: LAN port DHCP role - Enabled, Relay or Disabled. ...
-
Page 39: System Log
4.2.2 System Log In system log, users can check the operations to the router and track the glitches to the router when occurred. Refresh: Press this button to refresh the statistics. -
Page 40: Statistics
4.2.3 Statistics Ethernet Interface: This field displays the type of port Transmit Frames: This field displays the number of frames transmitted until the latest second. Transmit Multicast Frames: This field displays the number of multicast frames transmitted until the latest second. - Page 41 Wireless Transmit Frames: This field displays the number of frames transmitted until the latest second. Transmit Error Frames: This field displays the number of error frames transmitted until the latest second. Transmit Drop Frames: This field displays the number of drop frames transmitted until the latest second. Receive Frames: This field displays the number of frames received until the latest second.
- Page 42 EWAN Transmit Frames: This field displays the total number of frames transmitted until the latest second. Transmit Multicast Frames: This field displays the total number of multicast frames transmitted till the latest second. Transmit Total Bytes: This field displays the total number of bytes transmitted until the latest second. Transmit Collision: This is the number of collisions on this port.
-
Page 43: Dhcp Table
4.2.4 DHCP Table DHCP table displays the devices connected to the router with clear information. #: The index identifying the connected devices. Host Name: Show the hostname of the PC. IP Address: The IP allocated to the device. MAC Address: The MAC of the connected device. Expire Time: The total remaining interval since the IP assignment to the PC. -
Page 44: Disk Status
4.2.5 Disk Status Partition: Display the USB storage partition. Disk Space(KB): Display the total storage space of the NAS in KBytes unit. Free Space(KB): Display the available space in KBytes unit. -
Page 45: Voip Status
4.2.6 VoIP Status 4.2.6.1 VoIP Status VoIP status give users a directive picture on the registered VoIP accounts. Phone Number: The phone number user registers and fills in the Basic page of VoIP. Host: Show the IP address and port number of SIP Registrar. Status: The status of the registered SIP account. -
Page 46: Quick Start
4.3 Quick Start For detailed instructions on configuring WAN settings, see the Interface Setup section of this manual. The Quick Start Wizard is a useful and easy utility to help setup the device to quickly connect to your ISP (Internet Service Provider) with only a few steps required. It will guide you step by step to configure the password, time zone, and WAN settings of your device. - Page 47 Step3: Set your wireless connection. Click NEXT to continue.
- Page 48 Step4: Set your Internet connection WAN Transfer Modes: EWAN EWAN 1). Select EWAN. Refer to your ISP to choose the appropriate connection protocol. Click NEXT to continue. Enter the PPPoE account information provided to you by your ISP. Click NEXT to continue. 3).The Setup Wizard has completed.
- Page 49 Switch to Status > Device Info to view the status. ...
-
Page 50: Interface Setup
4.4 Configuration Click this item to access the following sub-items that configure the router: Interface Setup, Advanced Setup, VoIP, Access Management, and Maintenance. -
Page 51: Internet
4.4.1 Interface Setup First, let us take a look at the Interface Setup. There are four items contained in this section, namely, Internet, LAN, Wireless and Wireless MAC Filter. Each is described in the following scenario. 4.4.1.1 Internet EWAN... - Page 52 Multi Service Service Index: The index to mark the EWAN interface of different ISP type, ranging from 0-7. Service Summary: The diagram for view of service information. Status: Select whether to enable the service. IPv4/IPv6 IP version: choose IPv4, IPv4/IPv6, IPv6 based on users’ environment. Here we take IPv4/IPv6 for example, when you just choose IPv4 or IPv6, you can just get information from the following listed parameters.
-
Page 53: Routing
working in the internet. Connection Setting Connection: Always On: Click on Always On to establish a PPPoE session during start up and to automatically re-establish the PPPoE session when disconnected by the ISP. Connect Manually: Select Connect Manually when you don't want the connection up all the time. TCP MSS Option: Enter the TCP Maximum Segment Size (MSS). - Page 54 When router’s Internet configuration is finished successfully, you can go to status to get the connection information.
- Page 55 4.4.1.2 LAN A Local Area Network (LAN) is a shared communication system to which many computers are attached and is limited to the immediate area, usually the same building or floor of a building. IPv6 The IPv6 address composes of two parts, thus, the prefix and the interface ID. There are two ways to dynamically configure IPv6 address on hosts.
- Page 56 IPv4 Parameters IP Address: Enter the IP address of Router in dotted decimal notation, for example, 192.168.1.254 (factory default). IP Subnet Mask: The default is 255.255.255.0. User can change it to other such as 255.255.255.128. Alias IP Address: This is for local networks virtual IP interface. Specify an IP address on this virtual interface. Alias IP Subnet Mask: Specify a subnet mask on this virtual interface.
- Page 57 If set to Disabled, the DHCP server will be disabled. If set to Relay, the BIPAC 6300VNOZ acts as a surrogate DHCP server and relays DHCP requests and responses between the remote server and the clients. Enter the IP address of the actual, remote DHCP server in the Remote DHCP Server field in this case.
- Page 58 IPv6 parameters Interface Address / Prefix Length: enter the static LAN IPv6 address, we suggest leave the field empty because when setted wrong, it will result in LAN devices not being able to access other IPv6 device through internet. Router will take the same WAN’s prefix to LAN side if the field is empty. MLD Snooping: Similar to IGMP Snooping, but applicable for IPv6.
- Page 59 4.4.1.3 Wireless This section introduces the wireless LAN and some basic configurations. Wireless LANs can be as complex as a number of computers with wireless LAN cards communicating through access points which bridge network traffic to the wired LAN.
-
Page 60: Time Schedule
Access Point Settings Access Point: Default setting is set to Activated. If you want to close the wireless interface, select Deactivated. AP MAC Address: The MAC address of wireless AP. Wireless Mode: The default setting is 802.11b+g+n (Mixed mode). If you do not know or have both 11g and 11b devices in your network, then keep the default in mixed mode.
