if it is desired that the events be reported to the SMS phone connected
to the communicator then program tel. number 001 into the memory
SMS report text consists of: installation name, event name, number and
name of the event source (device or code), date and time. Example:
"Report from your alarm: setting 47: device Time 01.08. 11:27"
if other events or texts should be reported to a particular number,
change the communicator settings (see 5.4 and 5.5)
when storing tel. numbers, if you key in ∗7 after the last digit of the
phone number (the symbol ∗ is also stored) and continue with one
more digit (1, 2, 3, 8 or 9), then if this tel. number calls the system, the
system will behave as if "∗ digit" had been keyed in just after the first
ring, i.e. as if it had been entered manually on the system keypad –
see section 3.5. Example: entering 81 5 777 777 777
authorizes calls from tel. number 777777777 to trigger output PGY for
2 seconds (after the first ringing signal from this number the ∗9
5. Programming sequences
Function
Language setting
GSM signal strength
measurement
Tel. number programming for
reporting to telephones
Selection of events to report by
SMS
Selection of events to report by
phone call
SMS text editing*
Enable reporting to phones
Remote access
Forwarding of incoming SMSes
SMS instruction confirmation
Reaction to incoming calls
Simulated phone line function
Emergency tel. number
GSM signal dropout indication
Phone microphone sensitivity
Phone speaker loudness
Number to be periodically called
to maintain SIM card validity
Using an SMS instruction to
configure automatic SIM card
credit interrogation *
Getting your www.GSMLink.cz
registration code sent to your
mobile phone
The JA-80Y GSM communicator
∗
79
Sequence
xx=01 to 17 where:
01=EN,02=CZ,03=SK,04=NL,05=DE,06=PL,07
981 xx
=DA,08=IT,09=PT,10=FI,11=NO,12=SV,
13=FR, 14=HU, 15=RU, 16=TR, 17=SP
On keypad or in ComLink software range 0/4 to 4/4
922
In reply to STATUS SMS: range 0/9 to 9/9
exit by pressing #
M = memory 1 to 8
xx..x = tel. number (max.20 digits)
81 M xx..x ∗0
keying in ∗9 = + and ∗7 = ∗
81 M ∗0 erases the number in memory M
82 M ec x
M = tel. number memory from 1 to 8
ec = event code (see 5.4)
x=1 report, x=0 no report
83 M ec x
Texts can be edited by Comlink software or by SMS instruction:
code TXT n,text,n,text... or by
x=0 disabled
x=1 enabled (all programmed by 82.. & 83..)
x=2 enabled without reporting
80 x
setting/unsetting by users 41 to 50 (codes,
cards & key-fobs) and master code
setting/unsetting
x=0 disabled
903 x
x=1 enabled (by phone and Internet)
x=0 no, x=1 yes = if the incoming text is not an
926 x
SMS instruction it will be forwarded to the first
programmed number in memories M1 to M8
927 x
x=0 no, x=1 yes (by SMS reply)
x=0: no reaction
904 x
x=1 to 8: answers after 1 to 8 rings
x=9: answers after the 2
x=0 tel. line (GSM gateway)
x=1 alarm system keypad
951 x
x=2 off
x=3 automatically calls an emergency tel.
number when the tel. receiver is picked up
952 xx..x ∗0
xx..x = tel. number (max.20 digits)
921 x
x=0 no, x=1 yes (15min. dropout =Fault)
953 x
x=1 to 9 (9 = maximum)
954 x
924 xx..x ∗0
xx..x = tel. number (max.20 digits), 924∗0=erase
Via an SMS instruction to the alarm system: code CREDIT uu..u xx yyy zz where code = master or service
code, uu..u = GSM network command string to ascertain the credit (e.g. ∗104#) , xx=auto-interrogation
frequency in days, yyy=minimum acceptable balance, zz= the textual position at which the number showing the
balance starts in the reply message from the GSM provider. If the credit is lower than the minimum, the
provider's SMS will be auto-forwarded to numbers M1 and M8 for someone to top up the pre-paid SIM card.
910 xx...x ∗0
xx..x = your mobile phone number
command will be executed. The PGY output should be programmed for
a 2 sec. pulse function. This setting is suitable for opening an electric
door lock, automatic gate etc.
4.1.
Programming
The most convenient programming is best done by a PC running
Comlink software or via the Internet and website:
programming SMS – PRG sequence
Programming is also possible via the system keypad:
The control panel must be in Service mode - if it is not, enter ∗0 Service
code (factory default: 8080) while the system is unset.
Enter the relevant programming sequences – see the following description
∗
0
To exit service mode press the # key
Options
www.GSMLink.cz
via Internet
nd
call
- 3 -
www.GSMLink.cz
Factory default
English
-
all M1 to M8 erased
M1 & 2 alarms by SMS
M3 & 4 alarms by SMS and call
M5 & 6 alarms by SMS and call +
Set/Unset by SMS
M7 alarms by call
M8 technical faults by SMS (to installer)
see 5.5
enabled
enabled
yes
yes
answers after 5 rings (25s)
tel. line
erased
no
5
erased
-
or by
MFJ55304
