Ford ECOSPORT Owner's Manual page 161

E246989
3. Disconnect the electrical connector.
4. Release the clip and remove the bulb.
Glove box lamp
1
E247620
1. Press the compartment.
2. Remove the box.
EcoSport (CBW) India, Vehicles Built From: 14-08-2017, GN15-19G219-ZCA enIND, Edition date: 201708, First Printing
Maintenance
(If Equipped)
2
1
E247786
3. Disconnect the electrical connector.
4. Press the buttom.
5. Remove the bulb.
Front Fog Lamps
Note: Do not separate the fog lamp bulb
from the bulb holder.
157
5
4
3
(If Equipped)
