Page 1: Table Of Contents
Introduction Instrument Cluster Warning lights and chimes Gauges Entertainment Systems AM/FM stereo AM/FM stereo with single CD AM/FM stereo with in-dash six CD Climate Controls Heater only Manual heating and air conditioning Lights Headlamps Turn signal control Bulb replacement Driver Controls Windshield wiper/washer control Steering wheel adjustment Power windows...
Page 2 Table of Contents Seating and Safety Restraints Seating Safety restraints Airbags Child restraints Tires, Wheels and Loading Tire information Tire inflation Tire Pressure Monitoring System (TPMS) Vehicle loading Trailer towing Recreational towing Driving Starting Brakes Traction Control™ Traction Control™/AdvanceTrac Transmission operation Roadside Emergencies Getting roadside assistance Hazard flasher switch...
Page 4: Introduction
– Special handling may apply for service or vehicle end of life disposal. See www.dtsc.ca.gov/hazardouswaste/perchlorate. CONGRATULATIONS Congratulations on acquiring your new Ford. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it.
Page 5: Safety And Environment Protection
SAFETY AND ENVIRONMENT PROTECTION Warning symbols in this guide How can you reduce the risk of personal injury to yourself or others? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol. These comments should be read and observed.
Page 6: Special Notices
• where the driver was positioning the steering wheel. To access this information, special equipment must be directly connected to the recording modules. Ford Motor Company and Ford of Canada do not access event data recorder information without obtaining consent,...
Page 7: Vehicle Modification Data Recording
Vehicle Modification Data Recording Some aftermarket products may cause severe engine and/or transmission damage; refer to the What is not covered section in The new vehicle limited warranty for your vehicle chapter of your vehicle’s Warranty Guide for more information. Some vehicles are equipped with Powertrain Control Systems that can detect and store information about vehicle modifications that increase horsepower and torque output;...
Page 8: Using Your Vehicle As An Ambulance
For additional information, please contact the Truck Body Builders Advisory Service at 1–877–840–4338. Use of your Ford light truck as an ambulance, without the Ford Ambulance Preparation Package voids the Ford New Vehicle Limited Warranty and may void the Emissions Warranties. In addition, ambulance...
Page 9: Cell Phone Use
Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The drivers primary responsibility is the safe operation of their vehicle.
Page 10 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert Fasten Safety Belt Airbag - Side Child Seat Tether Anchor Anti-Lock Brake System Brake Fluid - Non-Petroleum Based Stability Control System Master Lighting Switch Fog Lamps-Front Fuel Pump Reset Windshield...
Page 11 Vehicle Symbol Glossary Power Windows Front/Rear Child Safety Door Lock/Unlock Panic Alarm Engine Coolant Do Not Open When Hot Avoid Smoking, Flames, or Sparks Explosive Gas Power Steering Fluid Service Engine Soon Passenger Compartment Air Filter Check Fuel Cap 2008 Econoline (eco) Owners Guide (post-2002-fmt) USA (fus) Introduction...
Page 12: Instrument Cluster
Instrument Cluster WARNING LIGHTS AND CHIMES Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works.
Page 13 Under engine misfire conditions, excessive exhaust temperatures could damage the catalytic converter, the fuel system, interior floor coverings or other vehicle components, possibly causing a fire. Electronic throttle control: Illuminates when the engine has defaulted to a “limp-home” operation. Report the fault to a dealer at the earliest opportunity.
Page 14 Instrument Cluster Anti-lock brake system: If the ABS light stays illuminated or continues to flash, a malfunction has been detected, have the system serviced immediately by your authorized dealer. Normal braking is still functional unless the brake warning light also is illuminated. Airbag readiness: If this light fails to illuminate when the ignition is turned to ON, continues to flash or...
Page 15 Low tire pressure warning (if equipped): Illuminates when your tire pressure is low. If the light remains ON at start up or while driving, the tire pressure should be checked. Refer to Inflating Your Tires in the Tires, Wheels and Loading chapter.
Page 16 Instrument Cluster Overdrive off: Illuminates when the overdrive function of the transmission has been turned off, refer to the Driving chapter. If the light does not illuminate, have the transmission serviced soon, or damage may occur. Charging system: Illuminates when the battery is not charging properly.
Page 17: Gauges
GAUGES Speedometer: Indicates the current vehicle speed. Engine coolant temperature gauge: Indicates engine coolant temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine and let the engine cool.
Page 18 Instrument Cluster Trip odometer: Registers the miles (kilometers) of individual journeys. Press the SELECT/RESET control once to switch from the odometer to the trip odometer. Press the control again to select Trip A and Trip B features. To reset the trip, press and hold the control again until the trip reading is 0.0 miles.
Page 19: Entertainment Systems
AM/FM stereo (if equipped) Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The drivers primary responsibility is the safe operation of their vehicle.
Page 20 Entertainment Systems 3. AM/FM: Press to choose a frequency band in radio mode. 4. Memory preset buttons: To set a station: Select frequency band AM/FM1/FM2; tune to a station, press and hold a preset button until sound returns. 5. Power/volume: Press to turn ON/OFF;...
Page 21: Satellite Compatible Am/Fm Stereo In-Dash Single Cd/Mp3 Radio (If Equipped)
(if equipped) Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The drivers primary responsibility is the safe operation of their vehicle.
Page 22 Entertainment Systems TEXT is also available when equipped with Satellite radio. Your radio comes equipped with Satellite ready capability. The kit to enable Satellite reception is available through your dealer. Detailed Satellite instructions are included with the dealer installed kit. Check with your authorized dealer for availability.
Page 23 stored in preset 1 will begin playing. If there are less than six strong stations, the system will store the last one in the remaining presets. Setting the clock: Press MENU until SELECT HOUR or SELECT MINUTE is displayed. Use SEL to manually increase ( ) the hours/minutes.
Page 24 (12 cm) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 25: Premium Satellite Compatible Am/Fm Stereo In-Dash Six Cd/Mp3 Radio (If Equipped)
Radio (if equipped) Driving while distracted can result in loss of vehicle control, accident and injury. Ford strongly recommends that drivers use extreme caution when using any device that may take their focus off the road. The drivers primary responsibility is the safe operation of their vehicle.
Page 26 Entertainment Systems 2. TEXT: The filename (Fi), song title (So), artist text (Ar) or album text (AL) may be viewed while playing an MP3 selection. When MP3 selection text is shown on the message display, its corresponding text indicator (Fi, So, Ar, or AL) is shown in the elapsed time display.
Page 27 Entertainment Systems Fade: Press FADE; then press to shift sound to the rear/front speakers. 9. Menu: Press to access the following functions: Compression: Brings soft and loud CD passages together for a more consistent listening level when in CD mode. Press MENU until compression status is displayed.
Page 28 Entertainment Systems 14. FF(Fast forward): In CD/MP3 mode, press until desired selection is reached. 15. REW(Rewind): In CD/MP3 mode, press until desired selection is reached. 16. SAT (if equipped): Your radio comes equipped with Satellite Ready capability. The kit to enable the Satellite reception is available through your dealer.
Page 29: Accessory Delay
(12 cm) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 30 (12 cm) audio compact discs only. Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Dirty, warped or damaged CDs, irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 31: Climate Controls
HEATER ONLY SYSTEM (IF EQUIPPED) 1. Fan speed adjustment: Controls the volume of air circulated in the vehicle. 2. Temperature selection: Controls the temperature of the airflow in the vehicle. 3. Air flow selections: Controls the direction of the airflow in the vehicle.
Page 32: Manual Heating And Air Conditioning
Climate Controls MANUAL HEATING AND AIR CONDITIONING SYSTEM (IF EQUIPPED) 1. Fan speed adjustment: Controls the volume of air circulated in the vehicle. 2. Temperature selection: Controls the temperature of the airflow in the vehicle. 3. Air flow selections: Controls the direction of the airflow in the vehicle.
Page 33: Rear Fan Speed Adjustment (If Equipped)
To aid in side window defogging/demisting in cold weather: 1. Select MIX. 2. Set the temperature control to maintain comfort. 3. Set the fan speed to HI. Do not place objects on top of the instrument panel as these objects may become projectiles in a collision or sudden stop. REAR FAN SPEED ADJUSTMENT (IF EQUIPPED) The rear fan controls adjust the volume of air circulated in the rear...
Page 34: Lights
Lights HEADLAMP CONTROL • The first position turns on the parking, tail, license plate and side marker lamps. • The outer position turns on the headlamps. Battery saver The battery saver can be set to turn off the courtesy lamps within 2 or 10 minutes if a door is left open and the key is not in the ignition.
Page 35: Daytime Running Lamps (Drl) (If Equipped)
Daytime running lamps (DRL) (if equipped) Turns the headlamps on with a reduced output. To activate: • the ignition must be in the ON position and • the headlamp control is in the OFF or parking lamp position. Always remember to turn on your headlamps at dusk or during inclement weather.
Page 36: Panel Dimmer Control
Lights PANEL DIMMER CONTROL To adjust the brightness of the instrument panel, rotate the dimmer control clockwise/counterclockwise when the headlamp control is in the parking lamp or low-beam position. To turn on the interior lamps, rotate the dimmer control fully counterclockwise past the detent.
Page 37: Vertical Aim Adjustment (Aerodynamic Headlamps)
Lights 3. Turn on the low beam headlamps and open the hood. 4. Locate the high intensity area of the beam pattern and place the top edge of the intensity zone even with the horizontal reference line (4). If the top edge of the high intensity area is not even with the horizontal line, follow the next step to adjust 5.
Page 38 Lights • (1) 8 feet (2.4 meters) • (2) Center height of lamp to ground • (3) 25 feet (7.6 meters) • (4) Horizontal reference line 2. Measure the height from the center of your headlamp (indicated by a 3.0 mm circle on the lens) to the ground and mark an 8 foot (2.4 meter) horizontal reference line on the vertical wall or screen at this height (a piece of masking tape works...
Page 39: Turn Signal Control
TURN SIGNAL CONTROL • Push down to activate the left turn signal. • Push up to activate the right turn signal. INTERIOR LAMPS Cargo and dome lamps with rear headliner Rear cargo lamps equipped with an ON/OFF/DOOR control will light when: •...
Page 40: Bulb Replacement
Lights Front and rear courtesy/reading lamps The dome portion of the lamp, the center light, can be turned on when the headlamp control is rotated fully counterclockwise or when any door is opened. The reading lamp portion, the two outer lights, can only be toggled on and off at the lamp.
Page 41: Replacing Exterior Bulbs
Function Number of bulbs Side marker with sealed beam Back-up lamps License plate lamp Stop/tail/turn/side marker lamp High-mount brakelamp Cargo lamp Dome lamp (standard) Map/reading lamp All replacement bulbs are clear in color except where noted. To replace all instrument panel lights - see your authorized dealer Replacing exterior bulbs Check the operation of all the bulbs frequently.
Page 42: Replacing Headlamp Bulbs (Sealed Beam)
Lights 4. Remove the bulb assembly by turning it counterclockwise and pulling it straight out. Handle a halogen headlamp bulb carefully and keep out of children’s reach. Grasp the bulb only by its plastic base and do not touch the glass. The oil from your hand could cause the bulb to break the next time the headlamps are operated.
Page 43: Replacing Side Marker Bulbs
Lights Aerodynamic Sealed beam 3. Rotate the bulb socket counterclockwise and remove. 4. Carefully pull the bulb straight out of the socket. To complete installation, follow the removal procedures in reverse order. Replacing side marker bulbs 1. Make sure the headlamp control is in the OFF position. 2.
Page 44: Replacing High-Mount Brakelamp Bulbs
Lights Sealed beam 3. Rotate the bulb socket counterclockwise and remove. 4. Carefully pull the bulb straight out of the socket. To complete installation, follow the removal procedures in reverse order. Replacing high-mount brakelamp bulbs The interior cargo lamp (if equipped), on vehicles without a rear headliner, will have to be removed from under the high-mount brakelamp assembly located inside the vehicle.
Page 45: Replacing License Plate Lamp Bulbs
Lights Replacing license plate lamp bulbs 1. Turn the headlamp switch to OFF and then remove the two screws and the license plate lamp assembly from the rear door. 2. Remove bulb socket from lamp assembly by turning counterclockwise. 3. Pull the bulb out from socket and push in the new bulb.
Page 46: Driver Controls
Driver Controls MULTI-FUNCTION LEVER Windshield wiper: Rotate the end of the control away from you to increase the speed of the wipers; rotate towards you to decrease the speed of the wipers. Windshield washer: Push the end of the stalk: •...
Page 47: Tilt Steering Wheel
Driver Controls TILT STEERING WHEEL To adjust the steering wheel: 1. Pull and hold the steering wheel release control toward you. 2. Move the steering wheel up or down until you find the desired location. 3. Release the steering wheel release control.
Page 48: Storage Compartment (If Equipped)
Driver Controls Storage compartment (if equipped) Press the release on the door to open the storage compartment. The storage compartment may be used to secure sunglasses or a similar object. Installing a garage door opener (if equipped) The storage compartment can be converted to accommodate a variety of aftermarket garage door openers: 1.
Page 49: Compass Zone Adjustment
Electronic compass/temperature display (if equipped) Outside air temperature The outside temperature display is contained in the overhead console. The temperature display can be turned off and on by pressing the SELECT control on the overhead console. The temperature can be displayed in Centigrade or Fahrenheit by pressing the SELECT control.
Page 50: Compass Calibration Adjustment
Driver Controls 3. Press and hold the SELECT control until VAR appears in the display, then release. The display should show the current zone number. 4. Press the SELECT control until the desired zone number appears. The display will flash and then return to normal operation.
Page 51: Power Windows
To prevent the fuse from being blown, do not use the power point(s) over the vehicle capacity of 12 VDC/180W. If the power point or cigar lighter socket is not working, a fuse may have blown. Refer to Fuses and relays in the Roadside Emergencies chapter for information on checking and replacing fuses.
Page 52: Interior Mirror
Driver Controls Press and hold the bottom part of the rocker switch to open the window. Press and hold the top part of the rocker switch to close the window. Accessory delay With accessory delay, the window switches and radio may be used for up to ten minutes after the ignition switch is turned to the OFF position, or until any door is opened.
Page 53: Fold-Away Mirrors
Driver Controls Spotter mirror on standard mirror (if equipped) The spotter mirror only can be tilted from top to bottom. Move the lower mirror manually up/down to increase side and rear visibility. Apply pressure only in the center of the spotter mirror along the top or bottom edges to adjust the tilt feature.
Page 54: Speed Control
Driver Controls The telescoping feature (if equipped) allows the mirror to extend approximately 3.15 inches (80 mm). This feature is especially useful to the driver when towing a trailer. SPEED CONTROL (IF EQUIPPED) With speed control set, you can maintain a set speed without keeping your foot on the accelerator pedal.
Page 55 Resuming a set speed Press the RES (resume) control and release it. This will automatically return the vehicle to the previously set speed. Increasing speed while using speed control There are two ways to set a higher speed: • Press and hold the SET ACCEL control until you get to the desired speed, then release the control.
Page 56 Driver Controls • Depress the brake pedal until the desired vehicle speed is reached, press the SET ACCEL control. Turning off speed control There are two ways to turn off the speed control: • Depress the brake pedal. This will not erase your vehicle’s previously set speed.
Page 57: Keys
KEYS The key operates all locks on your vehicle. You should always carry a second key with you in a safe place in case you require it in an emergency. If your vehicle is equipped with the SecuriLock™ Passive Anti-theft system, your keys are electronically coded to your vehicle;...
Page 58: Deactivating/Activating Autolock Feature
Locks and Security Deactivating/activating autolock feature Your vehicle comes with the autolock feature disabled; there are two methods to enable/disable this feature: • Through your authorized dealer, or • by using a power door unlock/lock procedure. Power door lock switch autolock enable/disable procedure Before starting, ensure the ignition is in the 3 (OFF) position and all vehicle doors are closed.
Page 59 Back cargo door lock (if equipped) The passenger side rear cargo door has a power door lock control mounted on the inside of the door. When this lock is pressed, all doors will lock/unlock. E-Guard Cargo Protection System™ (if equipped) The E-Guard Cargo Protection System™...
Page 60: Emergency Lock Release
Locks and Security For vehicles equipped with manual door locks: • The front door locks can be locked by using either the key or the manual door lock. • In order to activate the E-Guard Cargo Protection System™, use the key or the manual door lock to lock the side and back cargo doors.
Page 61: Remote Entry System (If Equipped)
Locks and Security • The rear door handle is located in the rear door below the glass. To open the side or back cargo doors from the inside: 1. Unlock the E-Guard Cargo Protection System™ using the emergency handle. 2. Unlatch the door using the inside release handle. REMOTE ENTRY SYSTEM (IF EQUIPPED) This device complies with part 15 of the FCC rules and with RSS-210 of Industry Canada.
Page 62: Two Step Door Unlocking
Locks and Security The remote entry system allows you to lock or unlock all vehicle doors without a key. Note: • The lock and unlock features work when the ignition is in any position. • The panic feature is active when the ignition is in either the 1 (ACCESSORY), 2 (LOCK) or 3 (OFF) positions.
Page 63 flash twice to indicate that the vehicle has switched to one step unlocking. Repeat the procedure to switch back to two-step unlocking. Locking the doors 1. Press and release to lock all the doors. 2. Press and release again within three seconds to confirm that all the doors are closed and locked.
Page 64: Replacing Lost Remote Entry Transmitters
Locks and Security 2. Do not wipe off any grease on the battery terminals on the back surface of the circuit board. 3. Remove the old battery. Note: Please refer to local regulations when disposing of transmitter batteries. 4. Insert the new battery. Refer to the diagram inside the remote entry transmitter for the correct orientation of the battery.
Page 65: Illuminated Entry
Locks and Security Note: Ensure the brake pedal is not depressed during this sequence. To reprogram the remote entry transmitters: 1. Ensure the vehicle is electronically unlocked. 2. Place the key in the ignition and turn from the (2) LOCK position to (3) OFF.
Page 66: Securilock™ Passive Anti-Theft System (If Equipped)
Note: The SecuriLock™ passive anti-theft system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection. Note: Large metallic objects, electronic devices that are used to purchase gasoline or similar items, or a second coded key on the same key chain may cause vehicle starting issues.
Page 67: Automatic Arming
Locks and Security • When the igniton is in the 4 (ON) position, the indicator will glow for 3 seconds to indicate the engine is enabled. Automatic arming The vehicle is armed immediately after switching the ignition to the 2 (LOCK) position.
Page 68 Locks and Security 1. Insert the first previously programmed coded key into the ignition and turn the ignition from the 3 (OFF) position to the 4 (ON) position (maintain ignition in the 4 (ON) position for at least one second, but no more than ten seconds).
Page 69: Seating And Safety Restraints
Seating and Safety Restraints SEATING Notes: Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. Do not pile cargo higher than the seatbacks to reduce the risk of injury in a collision or sudden stop.
Page 70: Using The Manual Lumbar Support (If Equipped)
Seating and Safety Restraints Pull lever up to adjust seatback. Before returning the seatback to its original position, make sure that cargo or any objects are not trapped behind the seatback. After returning the seatback to its original position, pull on the seatback to ensure that it has fully latched.
Page 71: Rear Seats
Seating and Safety Restraints Press to raise or lower the rear portion of the seat cushion. Press the control to move the seat forward, backward, up or down. REAR SEATS Rear captains chair adjust — passenger side only Pull the lever forward to adjust the seat forward or backward.
Page 72 Seating and Safety Restraints Quick release captains chair (7 passenger configuration second row only) To remove the seat: 1. Disengage the lap/shoulder belt from the seat by inserting a key or small screwdriver into the slot in the detachable anchor and lifting upward.
Page 73 Seating and Safety Restraints 1. Position the seat to the floor mount. 2. Pull the seat latch handle downward to lock the seat in position. 3. Make sure the safety belt is not twisted, then insert the safety belt tongue into detachable anchor until you hear a “click” and feel the latch engage.
Page 74 Seating and Safety Restraints 2. Find the clips attached near the ends of the lap/shoulder belts. 3. Clip the end of the belt to the stationary portion of the shoulder belt coming out of the trim panel. The end of the shoulder belt must be clipped in order to keep it from striking anything during vehicle operation.
Page 75 Seating and Safety Restraints 4. With assistance, pull the LH/RH seat latch release straps (1) (located behind the latch mechanisms) to release the latch from the rear strikers. 5. Lift the rear end of seat upward and rearward by pushing on the seatback (2) and lifting the seat cushion (3) to disengage the front seat hook and the rear seat latch from the striker.
Page 76: Safety Restraints
Seating and Safety Restraints 5. After the front LH/RH hooks are engaged to the LH/RH front striker pins, pull LH/RH seat latch release straps to allow engagement of the latch to the striker pins. Refer to the illustration in To remove the rear seats above.
Page 77: Combination Lap And Shoulder Belts
Seating and Safety Restraints In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a safety belt. Each seating position in your vehicle has a specific safety belt assembly which is made up of one buckle and one tongue that are designed to be used as a pair.
Page 78: Vehicle Sensitive Mode
Seating and Safety Restraints • Front and rear seats All safety restraints in the vehicle are combination lap and shoulder belts. All of the passenger combination lap and shoulder belts have two types of locking modes described below: Vehicle sensitive mode This is the normal retractor mode, which allows free shoulder belt length adjustment to your movements and locking in response to vehicle movement.
Page 79: How To Disengage The Automatic Locking Mode
Seating and Safety Restraints How to use the automatic locking mode • Buckle the combination lap and shoulder belt. • Grasp the shoulder portion and pull downward until the entire belt is pulled out. • Allow the belt to retract. As the belt retracts, you will hear a clicking sound.
Page 80: Safety Belt Pretensioner
Seating and Safety Restraints BELT AND RETRACTOR ASSEMBLY MUST BE REPLACED if the safety belt assembly “automatic locking retractor” feature or any other safety belt function is not operating properly when checked by an authorized dealer. Failure to replace the Belt and Retractor assembly could increase the risk of injury in collisions.
Page 81: Safety Belt Warning Light And Indicator Chime
Seating and Safety Restraints Safety belt warning light and indicator chime The safety belt warning light illuminates in the instrument cluster and a chime sounds to remind the occupants to fasten their safety belts. Conditions of operation If... The driver’s safety belt is not buckled before the ignition switch is turned to the ON position...
Page 82 Seating and Safety Restraints If... The driver’s safety belt is not buckled approximately 5 seconds after the safety belt warning light has turned off... The driver’s safety belt is buckled while the safety belt indicator light is illuminated and the safety belt warning chime is sounding...
Page 83: One Time Disable
Seating and Safety Restraints Reasons given... “I was in a hurry” “Safety belts don’t work” “Traffic is light” “Belts wrinkle my clothes” “The people I’m with don’t wear belts” “I have an airbag” “I’d rather be thrown clear” Do not sit on top of a buckled safety belt or insert a latchplate into the buckle to avoid the Belt-Minder chime.
Page 84: Deactivating/Activating The Belt-Minder Feature
Seating and Safety Restraints Deactivating/activating the Belt-Minder feature Read Steps 1 - 5 thoroughly before proceeding with the deactivation/activation programming procedure. The Belt-Minder feature can be deactivated/activated by performing the following procedure: Before following the procedure, make sure that: • the parking brake is set •...
Page 85: Safety Belt Extension Assembly
(if equipped), shoulder belt guide on seatback (if equipped), child safety seat LATCH and tether anchors, and attaching hardware, should be inspected after a collision. Ford Motor Company recommends that all safety belt assemblies in use in vehicles involved in a collision be replaced.
Page 86: Airbags
Seating and Safety Restraints Failure to inspect and if necessary replace the safety belt assembly under the above conditions could result in severe personal injuries in the event of a collision. For proper care of soiled safety belts, refer to Interior in the Cleaning chapter.
Page 87 Seating and Safety Restraints Always transport children 12 years old and under in the back seat and always properly use appropriate child restraints. Never place a rear-facing child seat in front of an active airbag. If you must transport a forward-facing child in the front seat, move the seat all the way back and use appropriate restraints.
Page 88 Seating and Safety Restraints Children and airbags Children must always be properly restrained. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in the front seating position. Failure to follow these instructions may increase the risk of injury in a collision.
Page 89 Seating and Safety Restraints The airbags inflate and deflate rapidly upon activation. After airbag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder or sodium compounds which may irritate the skin and eyes, but none of the residue is toxic.
Page 90 Seating and Safety Restraints Determining if the system is operational The SRS uses a readiness light in the instrument cluster or a tone to indicate the condition of the system. Refer to Airbag readiness section in the Instrument Cluster chapter. Routine maintenance of the airbag is not required.
Page 91: Turning The Passenger Airbag Off
If the light fails to illuminate when the passenger air bag switch is in the OFF position and the ignition switch is in ON, have the passenger air bag switch serviced at your Ford or Lincoln-Mercury dealer immediately. 2008 Econoline (eco)
Page 92: Turning The Passenger Airbag Back On
Seating and Safety Restraints In order to avoid inadvertent activation of the switch, always remove the ignition key from the passenger air bag ON/OFF switch. An infant in a rear-facing seat faces a high risk of serious or fatal injuries from a deploying passenger airbag. Rear facing infant seats should NEVER be placed in the front seats, unless the passenger airbag is turned off.
Page 93: Child Restraints
Seating and Safety Restraints If your vehicle has rear seats, always transport children who are 12 and younger in the rear seat. Always use safety belts and child restraints properly. DO NOT place a child in a rear facing infant seat in the front seat unless your vehicle is equipped with an airbag ON/OFF switch and the passenger airbag is turned OFF.
Page 94 Seating and Safety Restraints • the child has a medical condition which, according to the child’s physician, makes it necessary for the child to ride in the front seat so that the driver can constantly monitor the child’s condition. 3. Medical condition. A passenger has a medical condition which, according to his or her physician: •...
Page 95: Safety Restraints For Children
Seating and Safety Restraints • the child has a medical condition that, according to the child’s physician, makes it necessary for the child to ride in the front seat so that the driver can monitor the child’s condition. 3. Medical condition: A passenger has a medical condition that, according to his or her physician: •...
Page 96: Children And Safety Belts
If you install a forward-facing child safety seat using the vehicle safety belts: • use only seats equipped with lap-shoulder belts; • Ford recommends placing forward-facing safety seats in the 2nd row and using top tether straps for added protection. For more information on top tether straps, see Attaching safety seats with tether straps in this section.
Page 97: Child Booster Seats
To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster. Booster seats position a child so that safety belts fit better. They lift the child up so that the lap belt rests low across the hips and the knees bend comfortably.
Page 98: Types Of Booster Seats
Seating and Safety Restraints Types of booster seats There are two types of belt-positioning booster seats: • Those that are backless. If your backless booster seat has a removable shield, remove the shield and use the lap/shoulder belt. If a seating position has a low seat back and no head restraint, a backless booster seat may place your child’s head (top...
Page 99: The Importance Of Shoulder Belts
Seating and Safety Restraints Children and booster seats vary widely in size and shape. Choose a booster that keeps the lap belt low and snug across the hips, never up across the stomach, and lets you adjust the shoulder belt to cross the chest and rest snugly near the center of the shoulder.
Page 100: Safety Seats For Children
Seating and Safety Restraints Never use pillows, books, or towels to boost a child. They can slide around and increase the likelihood of injury or death in a collision. SAFETY SEATS FOR CHILDREN Child and infant or child safety seats Use a safety seat that is recommended for the size and weight of the child.
Page 101: Installing Child Safety Seats With Combination Lap And Shoulder Belts
Seating and Safety Restraints Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position with LATCH and tether anchors. For more information on top tether straps and anchors, refer to Attaching safety seats with tether straps in this chapter.
Page 102 Seating and Safety Restraints 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together. 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions.
Page 103 Seating and Safety Restraints 5. To put the retractor in the automatic locking mode, grasp the shoulder portion of the belt and pull downward until all of the belt is extracted. 6. Allow the belt to retract. The belt will click as it retracts to indicate it is in the automatic locking mode.
Page 104: Attaching Safety Seats With Tether Straps
Seating and Safety Restraints Attaching safety seats with tether straps Children should be placed in the rear in an appropriate child safety seat that is properly secured to the vehicle. When using forward-facing child safety seats in vehicles with only two seating positions so the forward-facing child safety seat cannot be placed in the rear of the vehicle, move the passenger seat as far back from the instrument panel as possible.
Page 105 Seating and Safety Restraints 1. Position the child safety seat on the front right-hand passenger seat. 2. Adjust the front right-hand passenger seat full forward. 3. Route the child safety seat tether strap over the back of the front right-hand passenger seat as shown. 4.
Page 106 Seating and Safety Restraints 5. Adjust the front right hand passenger seat to the full rearward position. 6. Install the child safety seat tightly using the LATCH anchors or safety belts. Follow the instructions in this chapter. 7. Tighten the child safety seat tether strap according to the manufacturer’s instructions.
Page 107 Seating and Safety Restraints 1. Position the child safety seat on the second row left hand or right hand bucket seat. 2. Route the child safety tether strap over the back of the left hand or right hand second row bucket seat.
Page 108: Attaching Safety Seats With Latch (Lower Anchors And Tethers For Children) Attachments For Child Seat Anchors
Seating and Safety Restraints 2. Route the child safety tether strap over the back of the bench seat. 3. Clip the center tether strap hook to the tether bracket mounted under rear rail of seat cushion frame. Clip the outboard tether strap hooks to the tether bracket slot provided on the left side of each seat pedestal.
Page 109 Seating and Safety Restraints • Five passenger crew van • Seven passenger wagon • Eight passenger wagon • Twelve passenger wagon 2008 Econoline (eco) Owners Guide (post-2002-fmt) USA (fus)
Page 110 Seating and Safety Restraints • Fifteen passenger wagon represents LATCH anchors. represents tether strap anchors. Never attach two LATCH child safety seats to the same anchor. In a crash, one anchor may not be strong enough to hold two child safety seat attachments and may break, causing serious injury or death.
Page 111 Seating and Safety Restraints Each time you use the safety seat, check that the seat is properly attached to the lower anchors and tether anchor. Try to tilt the child seat from side to side. Also try to tug the seat forward. Check to see if the anchors hold the seat in place.
Page 112: Tires, Wheels And Loading
Tires, Wheels and Loading NOTICE TO UTILITY VEHICLE AND TRUCK OWNERS Utility vehicles and trucks handle differently than passenger cars in the various driving conditions that are encountered on streets, highways and off-road. Utility vehicles and trucks are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed...
Page 113: Vehicle Characteristics
VEHICLE CHARACTERISTICS How your vehicle differs from other vehicles SUV and trucks can differ from some other vehicles in a few noticeable ways. Your vehicle may • Higher – to allow higher load carrying capacity and to allow it to travel over rough terrain without getting hung up or damaging underbody components.
Page 114: Information About Uniform Tire Quality Grading
Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford Motor Company to give you the following information about tire grades exactly as the government has written it.
Page 115: Glossary Of Tire Terminology
The traction grade assigned to this tire is based on straight-ahead braking traction tests, and does not include acceleration, cornering, hydroplaning or peak traction characteristics. Temperature A B C The temperature grades are A (the highest), B and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 116: Inflating Your Tires
At least once a month and before long trips, inspect each tire and check the tire pressure with a tire gauge (including spare, if equipped). Inflate all tires to the inflation pressure recommended by Ford Motor Company. Use a tire gauge to check the tire inflation pressure, including the spare (if equipped), at least monthly and before long trips.
Page 117 Always inflate your tires to the Ford recommended inflation pressure even if it is less than the maximum inflation pressure information found on the tire. The Ford recommended tire inflation pressure is found on the Safety Compliance Certification Label or Tire Label which is located on the B-Pillar or the edge of the driver’s door.
Page 118 Tires, Wheels and Loading Note: If you have to drive a distance to get air for your tire(s), check and record the tire pressure first and add the appropriate air pressure when you get to the pump. It is normal for tires to heat up and the air pressure inside to go up as you drive.
Page 119: Tire Inflation Information
Tire inflation information All tires with Steel Carcass Plies (if equipped): This type of tire utilizes steel cords in the sidewalls. As such, they cannot be treated like normal light truck tires. Tire service, including adjusting tire pressure, must be performed by personnel trained, supervised and equipped according to Federal Occupational Safety and Health Administration (OSHA) regulations.
Page 120: Tire Care
Tires, Wheels and Loading Stay out of the trajectory (1) as indicated in the illustration. TIRE CARE Inspecting your tires Periodically inspect the tire treads for uneven or excessive wear and remove objects such as stones, nails or glass that may be wedged in the tread grooves.
Page 121 Improper or inadequate vehicle maintenance can cause tires to wear abnormally. Inspect all your tires, including the spare, frequently, and replace them if one or more of the following conditions exist: Tire wear When the tread is worn down to 1/16th of an inch (2 mm), tires must be replaced to help prevent your vehicle from skidding and...
Page 122: U.s. Dot Tire Identification Number (Tin)
(such as P-metric versus LT-metric or all-season versus all-terrain) as those originally provided by Ford. The recommended tire and wheel size may be found on either the Safety Compliance Certification Label or the Tire Label which is located on the B-Pillar or edge of the driver’s door.
Page 123: Safety Practices
4. Use both eye and ear protection. For a mounting pressure more than 20 psi greater than the maximum pressure, a Ford Dealer or other tire service professional should do the mounting. Always inflate steel carcass tires with a remote air fill with the person inflating standing at a minimum of 12 ft.
Page 124: Highway Hazards
Tires, Wheels and Loading • Do not run over curbs or hit the tire against a curb when parking If your vehicle is stuck in snow, mud, sand, etc., do not rapidly spin the tires; spinning the tires can tear the tire and cause an explosion.
Page 125 • Rear Wheel Drive (RWD) vehicles/Four Wheel Drive (4WD)/ All Wheel Drive (AWD) vehicles (front tires at top of diagram) Sometimes irregular tire wear can be corrected by rotating the tires. Note: If your tires show uneven wear ask an authorized dealer to check for and correct any wheel misalignment, tire imbalance or mechanical problem involved before tire rotation.
Page 126: Information Contained On The Tire Sidewall
Tires, Wheels and Loading • DRW – Six tire rotation If your vehicle is equipped with dual rear wheels it is recommended that the front and rear tires (in pairs) be rotated only side to side. We do not recommend splitting up the dual rear wheels.
Page 127 Tires, Wheels and Loading Information on “P” type tires P215/65R15 95H is an example of a tire size, load index and speed rating. The definitions of these items are listed below. (Note that the tire size, load index and speed rating for your vehicle may be different from this example.) 1.
Page 128 Tires, Wheels and Loading Note: You may not find this information on all tires because it is not required by federal law. Letter rating Note: For tires with a maximum speed capability over 149 mph (240 km/h), tire manufacturers sometimes use the letters ZR. For those with a maximum speed capability over 186 mph (299 km/h), tire manufacturers always use the letters ZR.
Page 129 12. Treadwear, Traction and Temperature Grades • Treadwear: The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 course as a tire graded 100.
Page 130 Tires, Wheels and Loading Additional information contained on the tire sidewall for “LT” type tires “LT” type tires have some additional information beyond those of “P” type tires; these differences are described below: 1. LT: Indicates a tire, designated by the Tire and Rim Association (T&RA), that is intended for service on light trucks.
Page 131 Tires, Wheels and Loading Information on “T” type tires “T” type tires have some additional information beyond those of “P” type tires; these differences are described below: T145/80D16 is an example of a tire size. Note: The temporary tire size for your vehicle may be different from this example.
Page 132: Tire Pressure Monitoring System (Tpms)
Tires, Wheels and Loading TIRE PRESSURE MONITORING SYSTEM (TPMS) (IF EQUIPPED) Each tire, including the spare (if provided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehicle manufacturer on the vehicle placard or tire inflation pressure label. (If your vehicle has tires of a different size than the size indicated on the vehicle placard or tire inflation pressure label, you should determine the proper tire inflation pressure for those tires.)
Page 133 The Tire Pressure Monitoring System complies with part 15 of the FCC rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Page 134: Understanding Your Tire Pressure Monitoring System (Tpms)
Tires, Wheels and Loading Understanding your Tire Pressure Monitoring System (TPMS) The Tire Pressure Monitoring System measures pressure in your four road tires and sends the tire pressure readings to your vehicle. The Low Tire Warning Lamp will turn ON if the tire pressure is significantly low. Once the light is illuminated, your tires are under inflated and need to be inflated to the manufacturer’s recommended tire pressure.
Page 135 Low Tire Possible Pressure Warning cause Light Solid Warning Light Tire(s) under-inflated Spare tire in TPMS malfunction Tire rotation without sensor training 2008 Econoline (eco) Owners Guide (post-2002-fmt) USA (fus) Tires, Wheels and Loading Customer Action Required 1. Check your tire pressure to ensure tires are properly inflated;...
Page 136: When Inflating Your Tires
Tires, Wheels and Loading Low Tire Possible Pressure Warning cause Light Flashing Warning Spare tire in Light TPMS malfunction When inflating your tires When putting air into your tires (such as at a gas station or in your garage), the Tire Pressure Monitoring System may not respond immediately to the air added to your tires.
Page 137 tires are flat, repair as necessary. Check air pressure in the road tires. If any tire is under-inflated, carefully drive the vehicle to the nearest location where air can be added to the tires. Inflate all the tires to the recommended inflation pressure.
Page 138 To reduce the chances of interference from another vehicle, TPMS reset should be performed at least three feet (one meter) away from another Ford Motor Company vehicle undergoing the TPMS reset procedure at same time. Do not wait more than two (2) minutes between resetting each tire sensor or the system will timeout and the entire procedure will have to be repeated on all four wheels.
Page 139: Tpms Reset Sequence
Tires, Wheels and Loading 3. Press and hold the brake pedal for two (2) seconds, then release. 4. Turn the ignition to OFF/LOCK (DO NOT remove the key.) 5. Cycle the ignition from OFF/LOCK to RUN three (3) times ending in RUN.
Page 140 Tires, Wheels and Loading 1. Left front tire: Place the TPMS reset tool against the left front tire where the tire meets the rim, opposite from the valve stem (1) as shown. This is where the sensor is located inside the rim. The tool needs to be held against the tire sidewall opposite the valve stem as illustrated with the arrow on the tool pointing towards the rim;...
Page 141: Rotation, Pressure Adjustment And Tpms Reset Example
Tires, Wheels and Loading Rotation, pressure adjustment and TPMS reset example The following example describes all the major steps involved in rotating tires on a vehicle with different front and rear tire pressures. It illustrates that the TPMS reset procedure needs to follow tire rotation and pressure adjustment to avoid a possible false low tire warning.
Page 142 Tires, Wheels and Loading Sensor position following tire rotation Sensor 1: 50 psi Sensor 2: 50 psi Sensor 3: 80 psi Sensor 4: 80 psi Pressure adjustment without the required TPMS reset procedure Sensor 1: 80 psi Sensor 2: 80 psi Sensor 3: 50 psi Sensor 4: 50 psi In this situation, the TPMS warning...
Page 143: Snow Tires And Chains
Rotation, pressure adjustment and successful completion of the TPMS reset procedure Sensor 1: 80 psi Sensor 2: 80 psi Sensor 3: 50 psi Sensor 4: 50 psi Tire rotation and air pressure adjustment followed by sensor resetting will ensure the system is properly programmed for vehicles with different front and rear tire pressures and reduce the risk of a false low tire warning.
Page 144: Vehicle Loading
Tires, Wheels and Loading VEHICLE LOADING – WITH AND WITHOUT A TRAILER This section will guide you in the proper loading of your vehicle and/or trailer, to keep your loaded vehicle weight within its design rating capability, with or without a trailer. Properly loading your vehicle will provide maximum return of vehicle design performance.
Page 145 Payload – is the combined weight of cargo and passengers that the vehicle is carrying. The maximum payload for your vehicle can be found on the Tire Label on the B-Pillar or the edge of the driver’s door (vehicles exported outside the US and Canada may not have a Tire Label).
Page 146 Tires, Wheels and Loading Example only: Cargo Weight – includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load or king pin weight is also part of cargo weight. GAW (Gross Axle Weight) – is the total weight placed on each axle (front and rear) –...
Page 147 GAWR (Gross Axle Weight Rating) – is the maximum allowable weight that can be carried by a single axle (front or rear). These numbers are shown on the Safety Compliance Certification Label located on the B-Pillar or the edge of the driver’s door. The total load on each axle must never exceed its GAWR.
Page 148 Tires, Wheels and Loading GCW (Gross Combined Weight) – is the weight of the loaded vehicle (GVW) plus the weight of the fully loaded trailer. GCWR (Gross Combined Weight Rating) – is the maximum allowable weight of the vehicle and the loaded trailer – including all cargo and passengers –...
Page 149 Exceeding any vehicle weight rating limitation could result in serious damage to the vehicle and/or personal injury. Steps for determining the correct load limit: 1. Locate the statement “The combined weight of occupants and cargo should never exceed XXX kg or XXX lb.” on your vehicle’s placard. 2.
Page 150: Special Loading Instructions For Owners Of Pickup Trucks And Utility-Type Vehicles
Tires, Wheels and Loading to transport the cement to your home? If you and your friend each weigh 220 lb. (99 kg), the calculation would be: 1400 - (2 x 220) - (12 x 100) = 1400 - 440 - 1200 = - 240 lb. No, you do not have enough cargo capacity to carry that much weight.
Page 151 GCWR (Gross Combined Weight Rating)/Trailer Weights Rear Maximum Engine axle GCWR - lb. ratio (kg) E-150 Regular/RV Van (8520 GVWR) 4.6L 3.73 11500 (5216) 4.6L 4.10 12000 (5443) E-150 Van (Crew) (8520 GVWR) 4.6L 3.73 11500 (5216) 4.6L 4.10 12000 (5443) E-150 Regular Wagon (7–passenger) (8520 GVWR) 4.6L 4.10...
Page 152 Tires, Wheels and Loading GCWR (Gross Combined Weight Rating)/Trailer Weights Rear Maximum Engine axle GCWR - lb. ratio (kg) E-250 Extended/RV Van (8900 GVWR) 4.6L 3.73 11500 (5216) 4.6L 4.10 12000 (5443) E-250 Extended Van (Crew) (8900 GVWR) 4.6L 3.73 11500 (5216) 4.6L 4.10...
Page 153 GCWR (Gross Combined Weight Rating)/Trailer Weights Rear Maximum Engine axle GCWR - lb. ratio (kg) E-350 Extended/RV Van (9500 GVWR) 5.4L 3.73 13000 (5897) 5.4L 4.10 13000 (5897) 6.8L 3.73 15000 (6804) 6.8L 4.10 18500 (8391) E-350 Extended Van (Crew) (9500 GVWR) 5.4L 3.73 13000 (5897)
Page 154 Tires, Wheels and Loading GCWR (Gross Combined Weight Rating)/Trailer Weights Rear Maximum Engine axle GCWR - lb. ratio (kg) E-350 Cutaway (158” wheelbase, dual rear wheel) (10000 5.4L 4.10 13000 (5897) 6.8L 4.10 18500 (8391) E-350 Cutaway (138” wheelbase, dual rear wheel) (11500 5.4L 4.10 13000 (5897)
Page 155 GCWR (Gross Combined Weight Rating)/Trailer Weights Rear Maximum Engine axle GCWR - lb. ratio (kg) E-350 Stripped Chassis (158” wheelbase, single rear wheel) (9600 GVWR) 5.4L 3.73 13000 (5897) 5.4L 4.10 13000 (5897) E-350 Stripped Chassis (138” wheelbase, dual rear wheel) (10000 GVWR) 5.4L 4.10...
Page 156 Tires, Wheels and Loading GCWR (Gross Combined Weight Rating)/Trailer Weights Rear Maximum Engine axle GCWR - lb. ratio (kg) E-450 Cutaway (158” wheelbase, dual rear wheel) (14050 5.4L 4.56 14050 (6373) E-450 Cutaway (176” wheelbase, dual rear wheel) (14050 5.4L 4.56 14050 (6373) E-450 Cutaway (158”...
Page 157: Preparing To Tow
GCWR (Gross Combined Weight Rating)/Trailer Weights Rear Maximum Engine axle GCWR - lb. ratio (kg) For high altitude operation reduce GCWR by 2% per 1,000 ft. (300 meters) elevation. To determine the maximum trailer weight designed for your particular vehicle as equipped, follow the section Vehicle loading earlier in this chapter.
Page 158: Trailer Brakes
Tires, Wheels and Loading If you use a rental trailer, follow the instructions that the rental agency gives to you. Do not attach safety chains to the bumper. Trailer brakes Electric brakes and manual, automatic or surge-type trailer brakes are safe if installed properly and adjusted to the manufacturer’s specifications.
Page 159: Servicing After Towing
• Consult your local motor vehicle speed regulations for towing a trailer. • To eliminate excessive shifting, use a lower gear. This will also assist in transmission cooling. • Anticipate stops and brake gradually. When descending long, steep downhill grades, always use a lower gear to provide engine braking to save wear on brakes.
Page 160: Recreational Towing
If a distance of 50 miles (80 km) or a speed of 35 mph (56 km/h) must be exceeded, the drive shaft will have to be removed. Ford recommends the driveshaft be removed/installed only by a qualified technician at an authorized dealer. See your authorized dealer for driveshaft removal/installation.
Page 161: Driving
STARTING Positions of the ignition 1. ACCESSORY, allows the electrical accessories such as the radio to operate while the engine is not running. 2. LOCK, locks the automatic transmission gearshift lever and allows key removal. 3. OFF, shuts off the engine and all accessories without locking the steering wheel.
Page 162: Important Safety Precautions
Driving If you smell exhaust fumes inside your vehicle, have your dealer inspect your vehicle immediately. Do not drive if you smell exhaust fumes. Important safety precautions When the engine starts, the idle RPM runs faster to warm the engine. If the engine idle speed does not slow down automatically, have the vehicle checked.
Page 163: Starting The Engine
• Turn the key to 4 (ON) without turning the key to 5 (START). Some warning lights will briefly illuminate. See Warning lights and chimes in the Instrument Cluster chapter for more information regarding the warning lights. Starting the engine 1.
Page 164: Important Ventilating Information
Driving Important ventilating information If the engine is idling while the vehicle is stopped for a long period of time, open the windows at least one inch (2.5 cm) or adjust the heating or air conditioning to bring in fresh air. ENGINE BLOCK HEATER (IF EQUIPPED) An engine block heater warms the engine coolant which aids in starting and allows the heater/defroster system to respond quickly.
Page 165: Brakes
• To reduce the risk of electrical shock, do not use your heater with ungrounded electrical systems or two pronged (cheater) adapters. Also ensure that the block heater, especially the cord, is in good condition before use. • Make sure that when in operation, the extension cord plug /engine block heater cord plug connection is free and clear of water in order to prevent possible shock or fire.
Page 166 Driving Refer to Brake system warning light in the Instrument Cluster chapter for information on the brake system warning light. Four-wheel anti-lock brake system (ABS) Your vehicle is equipped with an Anti-lock Braking System (ABS). This system helps you maintain steering control during emergency stops by keeping the brakes from locking.
Page 167: Parking Brake
Parking brake To set the parking brake (1), press the parking brake pedal down until the pedal stops. To release, pull the lever (2). Always set the parking brake fully and make sure that the gearshift is securely latched in P (Park). The BRAKE warning lamp will illuminate and will remain illuminated until the parking brake...
Page 168: Advancetrac With Roll Stability Control™ (Rsc) Stability Enhancement System (If Equipped)
Driving Aggressive driving in any road conditions can cause you to lose control of your vehicle increasing the risk of severe personal injury or property damage. The occurrence of a Traction Control™ event is an indication that at least some of the tires have exceeded their ability to grip the road;...
Page 169 If the AdvanceTrac with RSC system is activated excessively in a short period of time, the brake portion of the system will shut down to allow the brakes to cool down. A limited AdvanceTrac with RSC function using only engine power reduction will still help control the wheels from over-spinning.
Page 170 Driving • Cornering while towing a heavily loaded trailer (refer to Trailer towing in the Tires, Wheels and Loading chapter.) The RSC system works in conjunction with the AdvanceTrac system to further enhance the vehicle’s overall stability during aggressive maneuvers. The system helps maintain roll stability of the vehicle during aggressive maneuvers by applying brake force to one or more wheels.
Page 171 vehicle is stuck in snow or mud or when driving in deep sand, switching off the AdvanceTrac with RSC system may be beneficial so the wheels are allowed to spin. If your vehicle seems to lose engine power while driving in deep sand or very deep snow and the vehicle speed is 20 mph (32 km/h) or below, switching off the AdvanceTrac with RSC stability enhancement feature will restore full engine power and will enhance momentum through the obstacle.
Page 172: Traction-Lok Axle (If Equipped)
Driving • Heavy or uneven steering efforts may be caused by low power steering pump fluid level. Check for low power steering pump fluid level before seeking service by your authorized dealer. • Do not fill the power steering pump reservoir above the MAX mark on the reservoir, as this may result in leaks from the reservoir.
Page 173: Vehicle Stability And Handling
Loaded vehicles, with a higher center of gravity, may handle differently than unloaded vehicles. Do not overload your vehicle and use extra precautions, such as driving at slower speeds, avoiding abrupt steering changes and allowing for increased stopping distance, when driving a heavily loaded vehicle. Over-loading or loading the vehicle improperly can deteriorate handling capability and contribute to loss of vehicle control and vehicle rollover.
Page 174: Transmission Operation
Driving • In the event of an emergency stop, avoid skidding the tires and do not attempt any sharp steering wheel movements. Vehicles with a higher center of gravity such as utility and four-wheel drive vehicles handle differently than vehicles with a lower center of gravity.
Page 175: Understanding The Gearshift Positions Of The 4-Speed Automatic Transmission
Always set the parking brake fully and make sure the gearshift is latched in P (Park). Turn the ignition to the LOCK position and remove the key whenever you leave your vehicle. If the parking brake is fully released, but the brake warning lamp remains illuminated, the brakes may not be working properly.
Page 176 Driving Always set the parking brake fully and make sure the gearshift is latched in P (Park). Turn the ignition to the LOCK position and remove the key whenever you leave your vehicle. R (Reverse) With the gearshift lever in R (Reverse), the vehicle will move backward. Always come to a complete stop before shifting into and out of R (Reverse).
Page 177 2 (Second) This position allows for second gear only. • Provides engine braking. • Use to start-up on slippery roads. • To return to (Overdrive), move the gearshift lever into the (Overdrive) position. • Selecting 2 (Second) at higher speeds will cause the transmission to downshift to second gear at the appropriate vehicle speed.
Page 178 Driving P (Park) This position locks the transmission and prevents the rear wheels from turning. To put your vehicle in gear: • Start the engine • Depress the brake pedal • Move the gearshift lever into the desired gear To put your vehicle in P (Park): •...
Page 179 The TOW HAUL indicator light will illuminate in the instrument cluster. Tow/Haul delays upshifts to reduce frequency of transmission shifting. Tow/Haul also provides engine braking in all forward gears when the transmission is in the D (Overdrive) position; this engine braking will slow the vehicle and assist the driver in controlling the vehicle when descending a grade.
Page 180 Driving • Depress the accelerator to the floor. • Allows transmission to select an appropriate gear. Understanding the shift positions of the 5–speed automatic transmission (if equipped - diesel engines only) P (Park) This position locks the transmission and prevents the rear wheels from turning.
Page 181 D (Drive) without Overdrive D (Drive) without Overdrive can be activated by pressing the transmission control switch (TCS) on the end of the gearshift lever. • This position allows for all forward gears except overdrive. • The O/D OFF lamp will illuminate in the instrument cluster.
Page 182: Reverse Sensing System (If Equipped)
Driving If your vehicle goes off the edge of the pavement • If your vehicle goes off the edge of the pavement, slow down, but avoid severe brake application, ease the vehicle back onto the pavement only after reducing your speed. Do not turn the steering wheel too sharply while returning to the road surface.
Page 183 To help avoid personal injury, always use caution when in reverse and when using the RSS. This system is not designed to prevent contact with small or moving objects. The system is designed to provide a warning to assist the driver in detecting large stationary objects to avoid damaging the vehicle.
Page 184 Your vehicle is qualified for use as a stationary power source, within limits detailed in the Ford Truck Body Builders Layout Book, found at www.fleet.ford.com/truckbbas, and through the Ford Truck Body Builders Advisory Service.
Page 185: Driving Through Water
Driving DRIVING THROUGH WATER If driving through deep or standing water is unavoidable, proceed very slowly especially when the depth is not known. Never drive through water that is higher than the bottom of the wheel rims (for cars) or the bottom of the hubs (for trucks).
Page 186: Roadside Emergencies
Roadside Emergencies ROADSIDE ASSISTANCE Getting roadside assistance To fully assist you should you have a vehicle concern, Ford Motor Company offers a complimentary roadside assistance program. This program is separate from the New Vehicle Limited Warranty. The service is available: •...
Page 187: Using Roadside Assistance
Motorhome customers in the U.S and Canada should contact 1–800–444–3311. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount for towing to the nearest dealership within 35 miles. To obtain reimbursement information, U.S.
Page 188: Hazard Flasher Control
Roadside Emergencies HAZARD FLASHER CONTROL The hazard flasher is located on the steering column, just behind the steering wheel. The hazard flashers will operate when the ignition is in any position or if the key is not in the ignition. Push in the flasher control and all front and rear direction signals will flash.
Page 189 Roadside Emergencies Except for commercial stripped chassis vehicles, this switch is located in the front passenger’s footwell, by the kick panel. On commercial stripped chassis vehicles, this switch is located on a bracket above the brake pedal. To reset the switch: 1.
Page 190: Fuses And Relays
Roadside Emergencies FUSES AND RELAYS Fuses If electrical components in the vehicle are not working, a fuse may have blown. Blown fuses are identified by a broken wire within the fuse. Check the appropriate fuses before replacing any electrical components. Note: Always replace a fuse with one that has the specified amperage rating.
Page 191 To remove a fuse use the fuse puller tool provided on the fuse panel cover. The fuses are coded as follows. Fuse/Relay Fuse Amp Location Rating — 2008 Econoline (eco) Owners Guide (post-2002-fmt) USA (fus) Roadside Emergencies Passenger Compartment Fuse Panel Description Not used Remote Keyless Entry (RKE),...
Page 192 Roadside Emergencies Fuse/Relay Fuse Amp Location Rating — — — — — 2008 Econoline (eco) Owners Guide (post-2002-fmt) USA (fus) Passenger Compartment Fuse Panel Description Radio capacitor(s), Ignition coils, PCM (Powertrain Control Module) relay Wiper control module Main light switch, Park lamps, License lamp (external lamps), Multi-function switch (flash-to-pass), BSM...
Page 193: Power Distribution Box
Fuse/Relay Fuse Amp Location Rating — — — 20A circuit breaker — 30A circuit breaker Power distribution box The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. Always disconnect the battery before servicing high current fuses.
Page 194 Roadside Emergencies If the battery has been disconnected and reconnected, refer to the Battery section of the Maintenance and Specifications chapter. The high-current fuses are coded as follows. Fuse/Relay Fuse Amp Location Rating — — 15A* 15A* 60A** 40A** 50A** 2008 Econoline (eco) Owners Guide (post-2002-fmt) USA (fus)
Page 195 Fuse/Relay Fuse Amp Location Rating 30A** 60A** 40A** 60A** 20A** 50A** 30A** 40A** 50A** 60A** 50A** 60A** 30A** 60A** 10A* 20A* 20A* — 20A* 10A* 2008 Econoline (eco) Owners Guide (post-2002-fmt) USA (fus) Roadside Emergencies Power Distribution Box Description Trailer tow electric brake controller 4-Wheel Anti-lock Brake System (4WABS)
Page 196: Relay Modules
Roadside Emergencies Fuse/Relay Fuse Amp Location Rating — — — — — — — — — — — * Mini fuses ** Maxi fuses Relay modules Instrument panel relay module The instrument panel relay module is located behind the radio in the center of the instrument panel.
Page 197 The relays are coded as follows: Relay location Description Interior lamps Open Open Battery saver Engine compartment relay module The engine compartment relay module is located in one of two places depending on which type of engine your vehicle is equipped with: •...
Page 198: Changing Tires
Ford. If the dissimilar spare tire or wheel is damaged, it should be replaced rather than repaired.
Page 199 When driving with one of the dissimilar spare tires listed above, do not: • Exceed 50 mph (80 km/h) • Load the vehicle beyond maximum vehicle load rating listed on the Safety Compliance Label • Tow a trailer • Use snow chains on the end of the vehicle with the dissimilar spare tire •...
Page 200: Full-Size Matching Spare Tire/Wheel Information
Roadside Emergencies When driving with the full-size dissimilar spare tire/wheel additional caution should be given to: • Towing a trailer • Driving vehicles equipped with a camper body • Driving vehicles with a load on the cargo rack Drive cautiously when using a full-size dissimilar spare tire/wheel and seek service as soon as possible.
Page 201: Tire Change Procedure
To remove the spare tire: 1. Open the rear doors and remove the thumb screw and anti-theft bracket. If finger pressure will not remove the thumb screw, use the lug wrench to loosen the screw. 2. Remove the access plug under the left door.
Page 202: Replacing The Tire
Roadside Emergencies 1. Block the wheel that is diagonally opposite the tire you are changing. On E-450 vehicles, the parking brake is on the transmission. Therefore, the vehicle will not be prevented from moving when a rear wheel is lifted, even if the parking brake is applied. Be sure to block both directions of the wheel that is diagonally opposite to the wheel that is being lifted.
Page 203 To lessen the risk of personal injury, do not put any part of your body under the vehicle while changing a tire. Do not start the engine when your vehicle is on the jack. The jack is only meant for changing the tire.
Page 204 Roadside Emergencies Front axle jacking points: Place the jack under the pin on the front surface of the front axle. Do not place the jack under or on the steering linkage. • Raise the jack until the wheel is completely off the ground. (Turn jack handle clockwise if your vehicle is equipped with a screw-type jack or pump the jack...
Page 205: Stowing The Flat/Spare Tire
Never use wheels or lug nuts different than the original equipment as this could damage the wheel or mounting system. This damage could allow the wheels to come off while the vehicle is being driven. 6. Install any wheel covers, ornaments or hub caps. Make sure they are snapped in place.
Page 206: Wheel Lug Nut Torque Specifications
9/16 x 18 two-piece lug nut * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. On all two-piece flat wheel nuts, apply one drop of motor oil between the flat washer and the nut. Do not apply motor oil to the wheel nut threads or the wheel stud threads.
Page 207: Jump Starting
When a wheel is installed, always remove any corrosion, dirt or foreign materials present on the mounting surfaces of the wheel or the surface of the wheel hub, brake drum or brake disc that contacts the wheel. Ensure that any fasteners that attach the rotor to the hub are secured so they do not interfere with the mounting surfaces of the wheel.
Page 208: Preparing Your Vehicle
Roadside Emergencies Preparing your vehicle When the battery is disconnected or a new battery is installed, the automatic transmission must relearn its shift strategy. As a result, the transmission may have firm and/or soft shifts. This operation is considered normal and will not affect function or durability of the transmission.
Page 209 Roadside Emergencies 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery. 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 2008 Econoline (eco) Owners Guide (post-2002-fmt) USA (fus)
Page 210: Jump Starting
Roadside Emergencies 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system. Do not use fuel lines, engine rocker covers or the intake manifold as grounding points. Do not connect the end of the second cable to the negative (-) terminal of the battery to be jumped.
Page 211 Roadside Emergencies Removing the jumper cables Remove the jumper cables in the reverse order that they were connected. 1. Remove the jumper cable from the ground metal surface. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2.
Page 212 Roadside Emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 213: Wrecker Towing
Ford recommends your vehicle be towed with a wheel lift or flatbed. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure.
Page 214: Customer Assistance
Center at 1-800-392-3673 (FORD). Away from home If you own a Ford or Mercury vehicle and are away from home when your vehicle needs service, or if you need more help than the authorized dealer could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealer to help you.
Page 215: Away From Home-Motorhome Service
Away from home–motorhome service If you own a motorhome built on a Ford Chassis and are away from home when your vehicle needs service, or if you need more help than the authorized dealer could provide, after following the steps above, contact the Ford Motorhome Customer Assistance Center to find an authorized dealer or service location to help you.
Page 216: In California (U.s. Only)
In the case of 1 or 2 above, the consumer must also notify the manufacturer of the need for the repair of the nonconformity at the following address: Ford Motor Company 16800 Executive Plaza Drive Mail Drop 3NE-B Dearborn, MI 48126...
Page 217: The Better Business Bureau (Bbb) Auto Line Program
You are not bound by the decision but may choose to accept it. If you choose to accept the BBB AUTO LINE decision then Ford must abide by the accepted decision as well. If the arbitrator has decided in...
Page 218: Ford Extended Service Plan
(CANADA ONLY) For vehicles delivered to authorized Canadian dealers. In those cases where you continue to feel that the efforts by Ford of Canada and the authorized dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 219: Getting Assistance Outside The U.s. And Canada
Customer Assistance If you did not take advantage of the Ford Extended Service Plan at the time of purchasing your vehicle, you may still be eligible. Since this information is subject to change, please ask your authorized dealer for complete details about Ford Extended Service Plan coverage options, or visit the Ford ESP website at www.ford-esp.com.
Page 220: Ordering Additional Owner's Literature
However, NHTSA cannot become involved in individual problems between you, your dealer, or Ford Motor Company. 2008 Econoline (eco)
Page 221: Reporting Safety Defects (Canada Only)
Customer Assistance To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1–888–327–4236 (TTY: 1–800–424–9153); go to http://www.safercar.gov; or write to: Administrator NHTSA 400 Seventh Street, SW Washington, D.C. 20590 You can also obtain other information about motor vehicle safety from http://www.safercar.gov.
Page 222: Cleaning
Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral pH shampoo, such as Motorcraft Detail Wash (ZC-3-A), which is available from your authorized dealer. • Never use strong household detergents or soap, such as dish washing or laundry liquid.
Page 223: Paint Chips
• After polishing chrome bumpers, apply a coating of Motorcraft Premium Liquid Wax (ZC-53-A), available from your authorized dealer, or an equivalent quality product to help protect from environmental effects. WAXING • Wash the vehicle first. • Do not use waxes that contain abrasives; use Motorcraft Premium Liquid Wax (ZC-53-A), which is available from your authorized dealer, or an equivalent quality product.
Page 224 Cleaning • Some automatic car washes may cause damage to the finish on your wheel rims or covers. Chemical-strength cleaners, or cleaning chemicals, in combination with brush agitation to remove brake dust and dirt, could wear away the clearcoat finish over time. •...
Page 225: Plastic (Non-Painted) Exterior Parts
PLASTIC (NON-PAINTED) EXTERIOR PARTS Use only approved products to clean plastic parts. These products are available from your authorized dealer. • For routine cleaning, use Motorcraft Detail Wash (ZC-3-A). • If tar or grease spots are present, use Motorcraft Bug and Tar Remover (ZC-42).
Page 226: Instrument Panel/Interior Trim And Cluster Lens
Cleaning INSTRUMENT PANEL/INTERIOR TRIM AND CLUSTER LENS Clean the instrument panel, interior trim areas and cluster lens with a clean and damp white cotton cloth, then with a clean and dry white cotton cloth; you may also use Motorcraft Dash & Vinyl Cleaner (ZC-38-A) on the instrument panel and interior trim areas.
Page 227: Leather Seats (If Equipped)
FORD AND LINCOLN MERCURY CAR CARE PRODUCTS Your Ford or Lincoln Mercury authorized dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs;...
Page 228 Cleaning Motorcraft Multi-Purpose Cleaner (Canada only) (CXC-101) Motorcraft Custom Bright Metal Cleaner (ZC-15) Motorcraft Custom Clear Coat Polish (ZC-8-A) Motorcraft Custom Vinyl Protectant (U.S. only) (ZC-40-A) Motorcraft Dash and Vinyl Cleaner (ZC-38-A) Motorcraft Deluxe Leather and Vinyl Cleaner (U.S. only) (ZC-11-A) Motorcraft Leather Care Kit (ZC-11-D) Motorcraft Detail Wash (ZC-3-A) Motorcraft Dusting Cloth Mitt (ZC-47)
Page 229: Maintenance And Specifications
Maintenance and Specifications SERVICE RECOMMENDATIONS To help you service your vehicle, we provide scheduled maintenance information which makes tracking routine service easy. If your vehicle requires professional service, your authorized dealer can provide the necessary parts and service. Check your Warranty Guide to find out which parts and services are covered.
Page 230: Opening The Hood
Maintenance and Specifications OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located under the bottom left corner of the instrument panel. HOOD 2. Go to the front of the vehicle and push the auxiliary latch, located in the center top of the grill, to the left to release the hood.
Page 231: Identifying Components In The Engine Compartment
Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT Engine compartment component locations Refer to the 6.0L and 6.4L Power Stroke Direct Injection Turbo Diesel Owner’s Guide Supplement for diesel engine component locations. 1. Windshield washer fluid reservoir 2. Engine oil filler cap 3.
Page 232: Windshield Washer Fluid
In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specification WSB-M8B16-A2. Do not use any special washer fluid such as windshield water repellent type fluid or bug wash. They may cause squeaking, chatter noise, streaking and smearing.
Page 233: Engine Oil
Maintenance and Specifications Poor wiper quality can be improved by cleaning the wiper blades and the windshield, refer to Windows and wiper blades in the Cleaning chapter. To prolong the life of the wiper blades, it is highly recommended to scrape off the ice on the windshield before turning on the wipers.
Page 234: Adding Engine Oil
Maintenance and Specifications • If the oil level is below the lower hole or the MIN mark, add enough oil to raise the level within the lower and upper holes or within the MIN-MAX range. • Oil levels above the upper hole or the MAX mark may cause engine damage.
Page 235: Engine Oil And Filter Recommendations
Change your engine oil and filter according to the appropriate schedule listed in scheduled maintenance information. Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced.
Page 236: Battery
Maintenance and Specifications BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which normally does not require additional water during its life of service. If your battery has a cover/shield, make sure it is reinstalled after the battery has been cleaned or replaced. For longer, trouble-free operation, keep the top of the battery clean and dry.
Page 237 Maintenance and Specifications When lifting a plastic-cased battery, excessive pressure on the end walls could cause acid to flow through the vent caps, resulting in personal injury and/or damage to the vehicle or battery. Lift the battery with a battery carrier or with your hands on opposite corners.
Page 238: Engine Coolant
Maintenance and Specifications If the battery has been disconnected or a new battery has been installed, the clock and radio settings must be reset once the battery is reconnected. • Always dispose of automotive batteries in a responsible manner. Follow your local authorized standards for disposal.
Page 239: Adding Engine Coolant
Maintenance and Specifications When the engine is cold, check the level of the engine coolant in the reservoir. • The engine coolant should be at the “FULL COLD” level or within the “COLD FILL RANGE” as listed on the engine coolant reservoir (depending upon application).
Page 240 Motorcraft Premium Gold Engine Coolant from yellow to golden tan. • Do not add/mix an orange-colored, extended life coolant such as Motorcraft Specialty Orange Engine Coolant, meeting Ford specification WSS-M97B44-D, or DEX-COOL brand with the factory-filled coolant. Mixing Motorcraft Specialty Orange Engine...
Page 241 Maintenance and Specifications coolant degas system with a pressurized cap, or if it is necessary to remove the coolant pressure relief cap on the radiator of a vehicle with an overflow system, follow these steps to add engine coolant. To reduce the risk of personal injury, make sure the engine is cool before unscrewing the coolant pressure relief cap.
Page 242: Recycled Engine Coolant
Maintenance and Specifications Recycled engine coolant Ford Motor Company does NOT recommend the use of recycled engine coolant in vehicles originally equipped with Motorcraft Premium Gold Engine Coolant since a Ford-approved recycling process is not yet available. Used engine coolant should be disposed of in an appropriate manner.
Page 243: What You Should Know About Fail-Safe Cooling (If Equipped)
Maintenance and Specifications • Refer to the chart on the coolant container to ensure the coolant concentration in your vehicle will provide adequate protection at the temperatures in which you drive. Vehicles driven year-round in non-extreme climates should use a 50/50 mixture of engine coolant and distilled water for optimum cooling system and engine protection.
Page 244: When Fail-Safe Mode Is Activated
Maintenance and Specifications When fail-safe mode is activated You have limited engine power when in the fail-safe mode, so drive the vehicle with caution. The vehicle will not be able to maintain high-speed operation and the engine will run rough. Remember that the engine is capable of completely shutting down automatically to prevent engine damage, therefore: 1.
Page 245 Maintenance and Specifications If you do not use the proper fuel filler cap, excessive vacuum in the fuel tank may damage the fuel system or cause the fuel cap to disengage in a collision, which may result in possible personal injury. Automotive fuels can cause serious injury or death if misused or mishandled.
Page 246 Maintenance and Specifications • Be particularly careful if you are taking “Antabuse” or other forms of disulfiram for the treatment of alcoholism. Breathing gasoline vapors, or skin contact could cause an adverse reaction. In sensitive individuals, serious personal injury or sickness may result. If fuel is splashed on the skin, promptly wash skin thoroughly with soap and water.
Page 247: Fuel Filler Cap
The customer warranty may be void for any damage to the fuel tank or fuel system if the correct genuine Ford or Motorcraft fuel filler cap is not used. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
Page 248: Choosing The Right Fuel
Maintenance and Specifications If you do not use the proper fuel filler cap, excessive vacuum in the fuel tank may damage the fuel system or cause the fuel cap to disengage in a collision, which may result in personal injury. Choosing the right fuel Use only UNLEADED fuel or UNLEADED fuel blended with a maximum of 10% ethanol.
Page 249: Fuel Quality
Ask your fuel supplier about gasolines that meet the World-Wide Fuel Charter. Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality, per the recommendations in the Choosing the Right Fuel section. Running out of fuel Avoid running out of fuel because this situation may have an adverse effect on powertrain components.
Page 250: Essentials Of Good Fuel Economy
Maintenance and Specifications ESSENTIALS OF GOOD FUEL ECONOMY Measuring techniques Your best source of information about actual fuel economy is you, the driver. You must gather information as accurately and consistently as possible. Fuel expense, frequency of fill-ups or fuel gauge readings are NOT accurate as a measure of fuel economy.
Page 251: Calculating Fuel Economy
Maintenance and Specifications Calculating fuel economy 1. Fill the fuel tank completely and record the initial odometer reading (in miles or kilometers). 2. Each time you fill the tank, record the amount of fuel added (in gallons or liters). 3. After at least three to five tank fill-ups, fill the fuel tank and record the current odometer reading.
Page 252: Epa Window Sticker
Maintenance and Specifications • You may want to turn off the speed control in hilly terrain if unnecessary shifting between the top gears occurs. Unnecessary shifting of this type could result in reduced fuel economy. • Warming up a vehicle on cold mornings is not required and may reduce fuel economy.
Page 253: Emission Control System
If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
Page 254: On Board Diagnostics (Obd-Ii)
Maintenance and Specifications Exhaust leaks may result in entry of harmful and potentially lethal fumes into the passenger compartment. Do not make any unauthorized changes to your vehicle or engine. By law, vehicle owners and anyone who manufactures, repairs, services, sells, leases, trades vehicles, or supervises a fleet of vehicles are not permitted to intentionally remove an emission control device or prevent it from working.
Page 255: Readiness For Inspection/Maintenance (I/M) Testing
Maintenance and Specifications If the Service engine soon serviced at the first available opportunity. Although some malfunctions detected by the OBD-II may not have symptoms that are apparent, continued driving with the Service engine soon result in increased emissions, lower fuel economy, reduced engine and transmission smoothness, and lead to more costly repairs.
Page 256: Power Steering Fluid
Maintenance and Specifications POWER STEERING FLUID Check the power steering fluid. Refer to the scheduled maintenance guide for the service interval schedules. Check the fluid level when it is at ambient temperature, 20° – 80° F (-7° – 25° C): 1.
Page 257: Brake Fluid
Maintenance and Specifications BRAKE FLUID • E-150–E-350 Single Rear Wheel • E-350–E-450 Dual Rear Wheel The fluid level will drop slowly as the brakes wear, and will rise when the brake components are replaced. Fluid levels between the “MIN” and “MAX”...
Page 258: Transmission Fluid
Maintenance and Specifications TRANSMISSION FLUID Checking automatic transmission fluid (if equipped) Refer to your scheduled maintenance information for scheduled intervals for fluid checks and changes. Your transmission does not consume fluid. However, the fluid level should be checked if the transmission is not working properly, i.e., if the transmission slips or shifts slowly or if you notice some sign of fluid leakage.
Page 259: Low Fluid Level
Maintenance and Specifications Low fluid level Do not drive the vehicle if the fluid level is at the bottom of the dipstick and the ambient temperature is above 50°F (10°C). COLD DO NOT ADD Correct fluid level The transmission fluid should be checked at normal operating temperature 150°F-170°F (66°C-77°C) on a level surface.
Page 260: High Fluid Level
Maintenance and Specifications COLD The transmission fluid should be in this range if at ambient temperature (50°F-95°F [10°C-35°C]). High fluid level COLD Fluid levels above the safe range may result in transmission failure. An overfill condition of transmission fluid may cause shift and/or engagement concerns and/or possible damage.
Page 261: Automatic Transmission Fluid Filter
Maintenance and Specifications DON'T ADD IF IN CROSSHATCHED AREA • CHECK WHEN HOT IDLING IN PARK COLD DO NOT ADD If an overfill occurs, excess fluid should be removed by an authorized dealer. An overfill condition of transmission fluid may cause shift and/or engagement concerns and/or possible damage.
Page 262: Changing The Air Filter Element
Maintenance and Specifications When changing the air filter element, use only the Motorcraft air filter element listed. Refer to Motorcraft part numbers in this chapter. To reduce the risk of vehicle damage and/or personal burn injuries do not start your engine with the air cleaner removed and do not remove it while the engine is running.
Page 263: Motorcraft Part Numbers
PCV valve. Replace the PCV valve with one that meets Ford material and design specifications for your vehicle, such as a Motorcraft or equivalent replacement part. The customer warranty may be void for any damage to the emissions system if such a PCV valve is not used.
Page 264: Maintenance Product Specifications And Capacities
Maintenance and Specifications 2008 Econoline (eco) Owners Guide (post-2002-fmt) USA (fus)
Page 265 Maintenance and Specifications 2008 Econoline (eco) Owners Guide (post-2002-fmt) USA (fus)
Page 266 Maintenance and Specifications 2008 Econoline (eco) Owners Guide (post-2002-fmt) USA (fus)
Page 267 Maintenance and Specifications 2008 Econoline (eco) Owners Guide (post-2002-fmt) USA (fus)
Page 268: Engine Data
Maintenance and Specifications ENGINE DATA 4.6L V8 Engine engine Cubic inches Required fuel 87 octane Firing order 1-3-7-2-6-5-4-8 Ignition system Coil on plug 0.052–0.056 Spark plug gap inch (1.32–1.42mm) Compression 9.4:1 ratio *Refer to the 6.0L and 6.4L Power Stroke Direct Injection Turbo Diesel Owner’s Guide Supplement for diesel engine information.
Page 269: Vehicle Identification Number
• 4.6L V8 and 5.4L V8 Engines with A/C • 6.8L V10 Engine VEHICLE IDENTIFICATION NUMBER Complete Ford built vehicles The vehicle identification number is attached to your vehicle in the following places: • The top of the instrument panel on the driver’s side.
Page 270: Certification Label For Incomplete Vehicles
Maintenance and Specifications • On the certification label. This label is required by the National Highway Traffic Safety Administration and is made of special material. If it is tampered with, it will be destroyed or a destruction pattern will appear. The Vehicle Identification Number (VIN) contains the following information: 1.
Page 271: Transmission/Transaxle Code Designations
Maintenance and Specifications TRANSMISSION/TRANSAXLE CODE DESIGNATIONS You can find a transmission/transaxle code on the Safety Compliance Certification Label. The following table tells you which transmission or transaxle each code represents. Description Five-speed automatic TorqShift-diesel engine with overdrive cancel Four-speed automatic overdrive (4R75E) Five-speed automatic TorqShift-gasoline engine with Tow/Haul 2008 Econoline (eco)
Page 272: Accessories
GENUINE FORD ACCESSORIES FOR YOUR VEHICLE A wide selection of Genuine Ford Accessories are available for your vehicle through your local Ford or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
Page 273: Peace Of Mind
Peace of mind Mobile-Ease™ hands-free communication system Remote start Vehicle security systems For maximum vehicle performance, keep the following information in mind when adding accessories or equipment to your vehicle: • When adding accessories, equipment, passengers and luggage to your vehicle, do not exceed the total weight capacity of the vehicle or of the front or rear axle (GVWR or GAWR as indicated on the Safety Compliance Certification label).
Page 274: Index
Index Accessory delay ...52 AdvanceTrac ...168 Air cleaner filter ...261–263 Airbag supplemental restraint system ...86 and child safety seats ...88 description ...86 disposal ...90 driver airbag ...88 indicator light ...90 operation ...88 passenger airbag ...88 passenger deactivation switch ...91 Ambulance packages ...8 Antifreeze (see Engine coolant) ...238 Anti-lock brake system...
Page 275 ...238 refill capacities ...242, 264 specifications ...264 Cruise control (see Speed control) ...54 Customer Assistance ...186 Ford Extended Service Plan ...218 Getting assistance outside the U.S. and Canada ...219 Getting roadside assistance ...186 Getting the service you need ...214...
Page 276 Index Exhaust fumes ...163 Fail safe cooling ...243 Fluid capacities ...264 Four-Wheel Drive vehicles preparing to drive your vehicle ...172 Fuel ...244 calculating fuel economy ...250 cap ...247 capacity ...264 choosing the right fuel ...248 comparisons with EPA fuel economy estimates ...252 detergent in fuel ...249 filling your vehicle with fuel ...244, 247, 250...
Page 277 positions of the ignition ...161 Lamps bulb replacement specifications chart ...40 daytime running light ...35 headlamps ...34 headlamps, flash to pass ...35 instrument panel, dimming ...36 interior lamps ...39 replacing bulbs ...41 Lane change indicator (see Turn signal) ...39 Lights, warning and indicator ...12 anti-lock brakes (ABS) ...166 Load limits ...144 Loading instructions ...150...
Page 278 Index Belt-Minder ...81 extension assembly ...85 for adults ...77–79 for children ...95–96 safety belt maintenance ...85 warning light and chime ...81 Safety seats for children ...100 Seats ...69 child safety seats ...100 front seats ...69 SecuriLock passive anti-theft system ...66–67 Servicing your vehicle ...229 Setting the clock AM/FM stereo ...20...
Page 279 Washer fluid ...232 Water, Driving through ...185 Windows power ...51 2008 Econoline (eco) Owners Guide (post-2002-fmt) USA (fus) Index Windshield washer fluid and wipers ...46 checking and adding fluid ...232 replacing wiper blades ...232 Wrecker towing ...213...

This manual is also suitable for:

2008 econoline

Ford 2008 E-150 Owner's Manual

Introduction

Instrument Cluster

Entertainment Systems

Climate Controls

Lights

Driver Controls

Locks and Security

Seating and Safety Restraints

Tires, Wheels and Loading

Driving

Roadside Emergencies

Customer Assistance

Cleaning

Maintenance and Specifications

Accessories

Index

Quick Links

Table of Contents

Need help?

Questions and answers

Related Manuals for Ford 2008 E-150

Summary of Contents for Ford 2008 E-150
