CHIEF PAC-Y1 Instruction Manual

Speaker mount adapter

I N S T R U C T I O N

Speaker Mount Adapter

(PAC-Y1)

The Speaker Mount Adapter (PAC-Y1) includes five inches of height

adjustment and adds ten pounds to the installation. The adapter is

designed for below display installation only. The combined weight of

the adapter, speakers and display must not exceed the weight

capacity of the mount.

BEFORE YOU BEGIN

• CAUTION: To prevent damage to the adapter, which could affect or void the Factory warranty, thoroughly

study all instructions and illustrations before you begin to install or operate the unit. Pay particular atten-

tion to the "Important Precautions" on Page 1.

• The maximum weight to be installed on the PAC-Y1 is limited by the weight specification of the mount.

• If you have any questions about this assembly, contact Chief Manufacturing at 1-800-582-6480.

CHIEF MANUFACTURING INC.

1-800-582-6480 952-894-6280 FAX 952-894-6918

8401 EAGLE CREEK PARKWAY, STE. 700

SAVAGE, MINNESOTA 55378 USA

M A N U A L

PART NO. 8800-000055 (Rev. A)

www.chiefmfg.com

08-05
