DECT IP Phone
W53P & W53H
Quick Start Guide(V83.X)
For W60B firmware: 77.83.0.X or later
For W53H firmware: 88.83.0.X or later

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W53P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Yealink W53P

Summary of Contents for Yealink W53P

  • Page 1 DECT IP Phone W53P & W53H Quick Start Guide(V83.X) For W60B firmware: 77.83.0.X or later For W53H firmware: 88.83.0.X or later...
  • Page 2 Handset Protective Case Belt Clip Ethernet Cable Quick Start Guide Rechargeable Battery (Optional) Note: Yealink W53P DECT IP phone consists of one W60B base station and one W53H handset. W53H Package Contents 2 Power Adapters USB Charger Cradle Belt Clip...
  • Page 3 PoE (Power Over Ethernet) Option Note • If you choose Method a, use Yealink-supplied power adapter (5V/600mA). A third-party power adapter may damage the base station. • If you choose Method b, you do not need to connect the power adapter.
  • Page 4 2b. (Wall-Mount Installation) Attach the base station. 3. Insert the battery into the handset. 4. Attach the Belt Clip. 5. (Optional) Mount the charger cradle to the wall. 40mm...

  • Page 5: Getting Started

    6. Connect the charger cradle and charge the handset. Note • Use Yealink-supplied power adapter (5V/600mA). A third-party power adapter may damage the handset. • Check the charging status on the top right corner of the LCD screen. Getting Started Shortcut Keys Shortcut keys help you quickly access to frequently used phone features.

  • Page 6: Handset Registration

    Handset Registration You can register up to 8 handsets to one W60B base station. Each handset can be registered to 4 different base stations. When the handset LCD screen prompts “Unregistered!”, long press on the base station till the registration LED flashes. There are two methods to register a new handset: Easy Registration: 1.

  • Page 7: Basic Operations

    To configure the network parameters for the base station manually: 1. Press the OK key to enter the main menu, and then select Settings->System Settings ->Network (default PIN: 0000)->Basic. 2. Select the desired IP addressing mode from the IP Mode field. 3.

  • Page 8: Handset Settings

    Handset Settings Handset Name To rename the handset: 1. Press the OK key to enter the main menu, and then select Settings->Handset Name. 2. Edit the value in the Rename field. 3. Press the Save soft key to accept the change. Volume Adjustment •...

  • Page 9: Speed Dial

    To delete a contact: 1. Press the OK key to enter the main menu, and then select Directory->Local Directory. 2. Press or to highlight the desired entry. 3. Press the Options soft key, and then select Delete to delete the selected entry. Speed Dial 1.

  • Page 10: Answering Calls

    2. Press or to highlight the desired entry, and then press to dial out using the default line. To place a call from the redial list: 1. Press when the handset is idle. 2. Press or to highlight the desired entry, and then press To place a call using the speed dial key: Long press the speed dial key to call the preset number directly.

  • Page 11: Call Transfer

    Call Transfer You can transfer a call in the following ways: Blind Transfer 1. Press the Options soft key during a call, and then select Transfer. 2. Enter the number you want to transfer the call to. 3. Press the Transfer soft key. Semi-Attended Transfer 1.

  • Page 12: Technical Support

    The company’s high-quality UC terminal solutions enhance the work efficiency and competitive advantages of its customers in over 100 countries. Yealink is the world’s second-largest SIP phone provider and is number one in the China market. Technical Support Visit Yealink WIKI (http://support.yealink.com/) for the latest firmware, guides,...
  • Page 13 FCC CAUTION: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
