Valmet SMART-PULP Operating And Installation Instructions page 39

Smart consistency transmitter
Table of Contents

Advertisement

SMART-PULP
100
SMART-PULP with
local operator
terminal
Sensor
Dimension H
(from edge of coupling)
LL
95
LS
70
UL
95
GL
95
RL
95
JL
95 Standard coupling
JL
57 Plastic-pipe coupling
HL
60 Standard coupling
HL
38 Blow line coupling
WS
75
Smart Consistency Transmitter
78
85
SMART-PULP without operator
unit. Used with remote operator
terminal
Figure 6 Dimensions
226
198
23
M OD E
ENT ER
C O M M
C O M M
110
TE S T -
TE S T +
80
140
SMART-PULP's remote operator terminal.
Length of connecting cable: 9.75 m.
39
BCs160VA
Nov. 15, 1997
242
HL: 50
WS: 355
H
126
72
