SMART-PULP
• When re-installing the sensor, make sure that it is
exactly parallel to the direction of flow. Check the
alignment with a ruler placed against the bottom of
the sensor's alignment slot.
A special tool is available for aligning the sensor.
The alignment accuracy must be better than +1°.
5 PARTS LIST
When ordering spares, please quote this document's number (BCs160VA) and date (Nov. 15. 1997), the
transmitter's name (SMART-PULP), type (sensor/material options, e.g. RL/SS), model code (M1), serial
number and 2-W/3-W, and the number and name of the required part.
Example: BCs160VA, Nov. 15. 1997, SMART-PULP, RL/SS, M1 No. 960720690, 2-W, 116 RL sensor
(serial number is constructed as follows: 96 = year, 07 = week, 20690 = ordinal number).
Part
Part name
No.
Cover
22
Operator terminal
27
O-ring 64.5x3
31
O-ring 66x2
32
36
Inlet cone
Gasket seat
37
Diaphragm
38
O-ring 18.2x3
39
Taper pin
42
76
Special nut
O-ring 47.29x2.62
80
Gland packing (transmitter/
81
remote operator terminal)
Plug
82
Gasket PTFE
90
Retaining ring with fin
91
Deflector plate
93
O-ring 16x4
94
96
O-ring 65.09x3.53
O-ring 18x1.5
103
Retaining ring
105
Smart Consistency Transmitter
Qty
1
1
1
1
1
1
1
2
1
1
1
2
1
1
1
1
1
1
3
1
• Finally secure the sensor's retaining nut with
Loctite 270. Ensure that none of the locking medium
is allowed to run to the sensor's taper assembly. Use
20 Nm torque to tighten the nut.
Part
Part name
No.
106
Retaining ring HL
112
UL sensor
113
JL sensor
114
LS sensor
115
GL sensor
116
RL sensor
117
WS sensor
118
HL sensor
120
LL sensor
122
Inlet gland
123
Cover with window
124
Remote operator terminal
case and cover
125
Mounting clamp assy.
126
Coupling
127
WS coupling
128
Blow line coupling
129
JL coupling, titanium
130
Plug
131
Gland packing, conn. to
control system
132
Remote operator terminal
TOOLS
Sensor mounting tool
Sensor removing tool
Taper pin removing tool
Calibration stand
Diagnostics weight set
1, 2 and 3 kg
275 HART® user interface
Diskette/Operating and
Installation Instructions
35
BCs160VA
Nov. 15, 1997
Qty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
