SMART-PULP
Type specification chart
SMART-PULP
Sensor type
LL
LS
JL
UL
GL
RL
HL
WS
Construction and wetted materials
SS
TI
HC
SB
Output signal
2W
Display and operator unit
RD
ID
Process coupling and its material
NO
SS
TI
HC
SB
SW
TJ
Smart Consistency Transmitter
AISI316 (std)
Titanium (std)
Hastelloy C276 (std)
AISI316L (blow line installation, only HL sensor)
2-wire system: 4-20 mA + HART®
SMART-PULP with remote operator unit
SMART-PULP with local operator unit
No process coupling
Standard, AISI316L (LL,LS,UL,GL,RL,HL)
Standard, Titanium (LL,LS,UL,GL,RL,HL)
Standard, Hastelloy C276 (LL,LS,UL,GL,RL,HL)
Blow line installation for HL sensor, AISI316L
For WS sensor, AISI316L
For JL sensor, Titanium. Laminated on fiberglass-reinforced pipe.
