FP Mailing Solutions Optimail Operator's Manual page 56

56
Optimail Operator Manual
Step 5: Connecting the Optimail
Power connection
Power cable
Warning! Only use power and phone cables pro-
vided with the Optimail or approved by Francotyp-
Postalia.
Make sure that connecting cables are not damaged.
Connect the Optimail to a grounded single-phase
power socket only. Make sure your office power
supply conforms to the power requirements shown
on the serial number plate of the Optimail.
Postage scale connection
Phone cable
Power cable
• Plug the power cable plug into the mains socket.
The mains socket is at the rear of the Optimail.
• Plug the mains plug into a grounded single-phase
power socket.
Modem connection
Spring
