ZDSO400-ER1 User Manual
MERAWEX
MERAWEX
MERAWEX Sp. z o.o.
44-122 Gliwice
ul. Toruńska 8
POLAND
Phone: +48 32 23 99 400
Fax +48 32 23 99 409
e-mail:
merawex@merawex.com.pl
http://www.merawex.com.pl
Emergency power supply units for Voice Alarm Systems
EN-54-4:1997+A1:2002+A2:2:2006, EN-121001-10:2005, ISO 7240-4:2003
1.
TECHNICAL DESCRIPTION............................................................................... 2
2
PRINCIPLE OF OPERATION ............................................................................. 5
3.
INSTALLATION AND CONNECTION ................................................................. 7
4.
FIRST START ................................................................................................... 10
5.
OPERATION ..................................................................................................... 12
6.
SERVICING ....................................................................................................... 14
7.
ADDITIONAL INFORMATION .......................................................................... 14
Document No. 0717.00.95-02.0
o
Document N
. 0717.00.95-02.0
USER MANUAL
type
ZDSO400-ER1
compliant with standards:
16.02.2017
Page:1/14
Advertisement
Related Manuals for MERAWEX ZDSO400-ER1
Summary of Contents for MERAWEX ZDSO400-ER1
-
Page 1: Table Of Contents
ZDSO400-ER1 User Manual Document N . 0717.00.95-02.0 Page:1/14 MERAWEX MERAWEX MERAWEX Sp. z o.o. 44-122 Gliwice ul. Toruńska 8 POLAND Phone: +48 32 23 99 400 Fax +48 32 23 99 409 e-mail: merawex@merawex.com.pl http://www.merawex.com.pl USER MANUAL Emergency power supply units for Voice Alarm Systems... -
Page 2: Technical Description
Emergency power supply allows to connect maximum 6 amplifiers, controller and 5 routers, operating with one battery bank. 1.2 Design Metallic cassette of ZDSO400-ER1 with height 1U, designed to mount in typical rack 19”. Weight of power supply is 4,9kg. - Page 3 3. Set of 6 plugs for connecting continuous operation devices by output Aux, 4. Set of 3 plugs for connecting relay signalling outputs, 5. Plug for connecting external fault input signal, with preassembled jumper. Fig. 2. View of ZDSO400-ER1 front panel and back panels On a front panel we see: ...
- Page 4 ZDSO400-ER1 User Manual Document N . 0717.00.95-02.0 Page:4/14 c) erasing errors (see par. 5.5) USB socket for communication connection (type B). Marking and meaning of indication LEDs is as follows: (Green) (Green) Mains Charging Yellow) (Yellow) Battery ( Fault On the back panel there are following components: 1.
-
Page 5: Principle Of Operation
Power supply design is based on so called direct buffering operation. Mains power supply (which has also role of a battery charger) is connected in parallel to outputs of ZDSO400-ER1 and external battery. When mains power is present then it is delivering power to outputs and simultaneously charging the battery. - Page 6 It causes that there are two circuits with different character of current sourcing: 1. amplifiers of VAS, sourced from outputs Out: a. when mains is present they are not sourcing current from ZDSO400-ER1; b. after mains failure, when there’s no fire alarm, they source very low current from power supply’s battery for their own needs;...
-
Page 7: Installation And Connection
At the rear side of power supply, next to mains socket, there is DIP switch, allowing setting of: battery capacity Cap, which will operate with ZDSO400-ER1. Setting the slide of the switch should be done according to calculation of capacity by DSO system calculator and taking into account the time of operation during watchdog and total power of all foreseen loudspeakers to be installed. - Page 8 Fig. 4 Look of the DIP switch for selection of capacity and battery circuit resistance with settings description 3.3. Connection Below table shows the types of connectors used in power supply with their maximum ratings and wire diameters. Table 3. List of ZDSO400-ER1 connectors Model Output Type of plug used Mains power IEC C13 1 pc.
- Page 9 1500 < P ≤ 3000 3.3.3 Connecting the amplifiers of VAS system The ZDSO400-ER1 power supply is equipped with 6 high power outputs Out to connect amplifiers, with 2 models possible: Model 1 It has 6 connectors, allowing connection of amplifiers with power 500W each.
-
Page 10: First Start
4. First Start 4.1. The initial information The first start of the VAS system including the ZDSO400-ER1 and connected battery should be done by qualified service personnel of the Manufacturer or the properly trained authorized personnel. The tests during the first start of the system are necessary to ensure safe and reliable operation – both from the mains and battery backup power. - Page 11 VAS modules. Check the voltage presence and value by a voltmeter. In this state, the Mains LED on the front panel of the ZDSO400-ER1 should go dark and the Fault and Battery LEDs should be lit.
-
Page 12: Operation
ZDSO400-ER1 User Manual Document N . 0717.00.95-02.0 Page:12/14 5. Operation 5.1. The initial information Output voltages and signalling thresholds are preset as factory default values. Power supply after installing requires supervision by the service team as some emergency states may occur during the operation of the device. - Page 13 ZDSO400-ER1 User Manual Document N . 0717.00.95-02.0 Page:13/14 Table 6. LED indication on a front panel. DESCRIPTION COLOUR STATE EVENT DESCRIPTION Normal operation state when the mains power present. green Mains dark No mains power or rectifier fault. Battery operation (no mains or rectifier fault).
-
Page 14: Servicing
Most cases of malfunctions which can occur during device operation are indicated and handled by the microprocessor installed in the device. The ZDSO400-ER1 is equipped with 12 fuses for model 1 and 10 fuses for model 2. They can be replaced by qualified service personnel. These are fuses of output circuits –...
