QUICKSTART
KM 130/300 R D
Start up
1
A
C
2
A
3
A
4
A
Warning
These are only brief instructions! Please read and comply with these instructions prior to using or servicing your
appliance.
The non-compliance of the operating and safety instructions may lead to damages of the appliance and to dangers
for the operator and other persons.
B
D
B
B
B
C
C
A Tilt the driver's seat forward and secure it.
Opening and securing hood.
B Check oil level.
C Check cooler water level.
D Close cover.
A Check roller brush.
B Check side brush.
A Sit on the driver's seat.
B Turn the ignition key to position "I".
C Check fuel level via the tank indicator.
Fill in diesel.
A Pull seat adjustment lever outwards.
B Slide seat, release lever and lock in place.
Check that the seat is properly locked in
position by attempting to move it backwards
and forwards.
C Adjust the seat back.
5.964-137.0 03/12

Advertisement

loading

Related Manuals for Kärcher KM 130/300 R D

Summary of Contents for Kärcher KM 130/300 R D

  • Page 1 QUICKSTART KM 130/300 R D Warning These are only brief instructions! Please read and comply with these instructions prior to using or servicing your appliance. The non-compliance of the operating and safety instructions may lead to damages of the appliance and to dangers for the operator and other persons.

  • Page 2: Operation

    QUICKSTART Operation Starting the machine A Sit on the driver's seat. Do NOT press the accelerator pedal. B Lock parking brake. C Bring the direction selector switch into the middle position. D Engine speed adjustment - push forward by 1/3. E Insert the ignition key into the ignition lock.

  • Page 3: Finish Operation

    QUICKSTART Operation Cleaning the dust filter A Press the switch of the dust filter cleaning system. Operation with beacon lamp A Switch on the beacon lamp. Emptying waste container Danger Risk of injury! When emptying the waste container, care should be taken to ensure that no persons or animals are within its swivelling range.

  • Page 4: Maintenance And Care

    QUICKSTART Maintenance and care A Check fuel filter. A Check the centrifugal separator and the air filter, clean if required. A Check function of all operator control elements. B Check appliance for damages. A Check the hydraulic oil level. B Check brake fluid status. Danger Risk of injury! Always apply the safety bar when the waste container is raised.

  • Page 5: Troubleshooting

    QUICKSTART Troubleshooting Appliance cannot be started A Sit on the driver seat, the seat contact switch gets activated. B Bring the direction selector switch into the middle position. C Charging or replacing battery D Fill in fuel, deaerate the fuel system E Change fuel filter Engine is running erratically A Remove the air filter housing.
