EcoPro G2
Cabinet & Counter Models
Controller & Display - Versions FD1-11 & FD1-14
English
00-556483 August 2016 Issue 7 GB
ISO 9001
Call: +44 (0)843 216 8800
ISO 14001
Fax: +44 (0)843 216 4700
www.fosterrefrigerator.co.uk
By Appointment to
Her Majesty Queen Elizabeth II
Suppliers of Commercial Refrigeration
Foster Refrigerator, King's Lynn
A Division of ITW Ltd
Foster Refrigerator
Oldmedow Road
King's Lynn
Norfolk, PE30 4JU
United Kingdom
Email: support@foster-uk.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Foster EP700F
Summary of Contents for Foster EP700F
- Page 1 By Appointment to Her Majesty Queen Elizabeth II Suppliers of Commercial Refrigeration Foster Refrigerator, King’s Lynn EcoPro G2 Cabinet & Counter Models Controller & Display - Versions FD1-11 & FD1-14 English 00-556483 August 2016 Issue 7 GB A Division of ITW Ltd...
- Page 2 Models Applicable to This Manual Single Cabinets Double Cabinets Broadway Counters EP700F EP820HU EP1/2G EP700G EP1440G EP820LU EP1/2H EP700H EP1440H EP1/2L EP700H2 EP1440H4 Workout EP1/2M EP700H2BK EP820MW EP1/2P EP700HBK EP820LW EP700HH EP1/3G EP700HL EP1/3H EP700HSTB EP1440HSTB EP1/3L EP700HU EP1440HU EP1/3M...
-
Page 3: Important Note To The Installer
General Electrical Safety Foster Refrigerator recommends that the equipment is electrically connected via a Residual Current Device; such as a Residual Current Circuit Breaker (RCCB) type socket, or through a Residual Current Circuit Breaker with Overload Protection (RCBO) supplied circuit. - Page 4 Display Icons and Switches Keypad Lock Warning/ Alarm Service Mode Temperature Setting Compressor Function Defrost Function Evaporator Fan Function Reduced Energy Mode Data Download Switch Light Switch Decrease Switch Increase Switch Power Switch (Cabinet Version) (Counter Version) (Some icons or switches are only visible during adjustment, when activated by parameters or through operation/ manual selection).
- Page 5 To exit this mode scroll back to the adjustment screen and press or wait for 30 seconds and the display will revert to the normal display showing the operating temperature. Set Point and Other Mode Adjustments Access the adjustment mode as described above. Using the switches to scroll to the mode that requires adjustments i.e ‘Set Point’...
-
Page 6: Cleaning And Maintenance
To lock the door or drawer insert the key and turn 90°, turn in the opposite direction to unlock. Defrost All Foster G2 cabinets are fitted with a fully automatic defrost system to ensure that the evaporator coil remains free from ice during normal use. Melt-water is evaporated using either the heat from the refrigeration system or a separate electric heater (dependent upon model and configuration) To activate a manual defrost - while the cabinet is in ‘run’... - Page 7 If there are any stubborn grease deposits left on or through the condenser call your supplier to carry out a full service (this is normally chargeable). Failure to maintain the condenser may invalidate the warranty of the condensing unit and cause premature failure of the motor/compressor. Do not use a wire brush to clean the condenser.
- Page 8 Fitting instructions for Rubber Feet The rubber feet are provided, enabling a shelf to be positioned on the floor of the cabinet. If this is required simply clip the feet onto the shelf as demonstrated below Rubber Foot Rear Rubber Foot Front Position Position After rubber feet are attached place shelf in the bottom of the unit...
-
Page 9: Troubleshooting
Troubleshooting Alarms/Warnings Low Temperature Alarm Condenser Clean Warning High Temperature Alarm Condenser High Temperature Alarm T1 Air Probe Failure High Pressure Alarm T2 Evaporator Probe Failure Door Open Alarm T3 Condenser Probe Failure Mains Power Failure only displayed if applicable to model and enabled through parameters. Power Failure Warning ‘... - Page 10 Require another language? This manual is also available for download in the following languages: Français Nederlands Deutsch Español Česky Pусский Magyar Nynorsk Íslenska Polski To download please visit and select the appropriate model of www.foster-spares.com refrigerator/ freezer.
- Page 11 >Page Left Blank Intentionally<...
- Page 12 UK Head Office Foster Refrigerator Oldmedow Road Kings Lynn Norfolk PE30 4JU a Division of ITW (UK) Ltd Tel: +44 (0)843 216 8833 Fax: +44 (0)843 216 4707 Email: support@foster-uk.com Website: www.fosterrefrigerator.co.uk...
