Memory configuration for smart labels with MLFBs -00, -01, -02

Note
Validity of the memory configuration
Please note that the following memory configuration only applies to smart labels with the
following MLFBs:
• 6GT2810-2AB00
• 6GT2810-2AB01
• 6GT2810-2AB02
Memory banks
The memory is divided logically into three different memory banks:
Memory bank (decimal)
MemBank 10
2
MemBank 01
2
MemBank 00
2
SIMATIC RF630L Smartlabel
Siemens Hardware
Operating Instructions, 06/2009, J31069-D0186-U001-A4-7618
1.3 Memory configuration for smart labels with MLFBs -00, -01, -02
Memory type
Description
TID
Is defined by the manufacturer, contains the class identifier of a tag.
EPC
Contains the EPC UID, the protocol and the CRC of a tag
You can write to the EPC memory area. In the delivery condition,
the memory contents can have the following states:
RESERVED
Contains the access and kill password.
empty
containing the same data
containing different data
