Siemens SIMATIC RF630L Smartlabel Operating Instructions Manual

Sensors.
Hide thumbs

Advertisement

1
SIMATIC RF630L Smartlabel
SIMATIC Sensors
RFID systems
SIMATIC RF630L Smartlabel
Operating Instructions
06/2009
Siemens Hardware
J31069-D0186-U001-A4-7618

Advertisement

Table of Contents

   Summary of Contents for Siemens SIMATIC RF630L Smartlabel

  • Page 1 SIMATIC RF630L Smartlabel SIMATIC Sensors RFID systems SIMATIC RF630L Smartlabel Operating Instructions 06/2009 Siemens Hardware J31069-D0186-U001-A4-7618...
  • Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
  • Page 3: Table Of Contents

    Table of contents SIMATIC RF630L Smartlabel ........................5 Features ............................5 Minimum spacing between labels ....................6 Memory configuration for smart labels with MLFBs -00, -01, -02 ..........7 Memory configuration for smart labels with MLFB -03 ..............10 Ordering data ..........................12 Technical data..........................12 Dimension drawings........................15...
  • Page 4 Table of contents SIMATIC RF630L Smartlabel Operating Instructions, 06/2009, J31069-D0186-U001-A4-7618...
  • Page 5: Simatic Rf630l Smartlabel

    SIMATIC RF630L Smartlabel Features SIMATIC RF630L smart labels are passive, maintenance-free data carriers based on UHF Class 1 Gen2 technology that are used to store the "Electronic Product Code" (EPC). Smart labels offer numerous possible uses for a wide range of applications and support efficient logistics throughout the process chain.
  • Page 6: Minimum Spacing Between Labels

    SIMATIC RF630L Smartlabel 1.2 Minimum spacing between labels Minimum spacing between labels Figure 1-1 Minimum spacing between labels Table 1- 1 Minimum spacing Minimum spacing 6GT2810-2AB00 6GT2810-2AB01 6GT2810-2AB02 6GT2810-2AB03 50 mm 50 mm Please note that smart labels can also be attached one above the other. The spacing between the labels attached one above the other depends on the damping characteristics of the carrier material.
  • Page 7: Memory Configuration For Smart Labels With Mlfbs -00, -01, -02

    SIMATIC RF630L Smartlabel 1.3 Memory configuration for smart labels with MLFBs -00, -01, -02 Memory configuration for smart labels with MLFBs -00, -01, -02 Note Validity of the memory configuration Please note that the following memory configuration only applies to smart labels with the following MLFBs: •...
  • Page 8 SIMATIC RF630L Smartlabel 1.3 Memory configuration for smart labels with MLFBs -00, -01, -02 The graphic below illustrates the exact memory utilization: Each box in the right part of the graphic represents one word (16 bit) in the memory. Color...
  • Page 9 SIMATIC RF630L Smartlabel 1.3 Memory configuration for smart labels with MLFBs -00, -01, -02 Reserved memory bank: programming or modifying memory areas The memory areas of the reserved memory bank can be programmed using the SIMATIC RF660R reader: ● Using the "tagDataWrite" XML command (see "SIMATIC RF660R Function Manual", Section "Smart reader tag data writing")
  • Page 10: Memory Configuration For Smart Labels With Mlfb -03

    SIMATIC RF630L Smartlabel 1.4 Memory configuration for smart labels with MLFB -03 Memory configuration for smart labels with MLFB -03 Note Validity of the memory configuration Please note that the following memory configuration only applies to smart labels with the following MLFB: •...
  • Page 11 SIMATIC RF630L Smartlabel 1.4 Memory configuration for smart labels with MLFB -03 The graphic below illustrates the exact memory utilization: Each box in the right part of the graphic represents one word (16 bit) in the memory. Color Access by SIMATIC RF660R / SIMATIC RF610M...
  • Page 12: Ordering Data

    SIMATIC RF630L Smartlabel 1.5 Ordering data Ordering data RF630L transponder Order No. Type of delivery RF630L transponder, 6GT2810-2AB00 Minimum order amount 1600 items smart label (800 on one roll) 101.6 mm x 152.4 mm (4" x 6") RF630L transponder, 6GT2810-2AB01 Minimum order amount 1000 items smart label 101.6 mm x 50.8 mm (4"...
  • Page 13 SIMATIC RF630L Smartlabel 1.6 Technical data Table 1- 3 Electrical data 6GT2810-2AB00 6GT2810-2AB01 6GT2810-2AB02 6GT2810-2AB03 Air interface ISO 18 000-6 Type C Polarization type Linear Polarization direction The polarization The polarization The polarization direction is parallel with the direction is parallel...
  • Page 14 SIMATIC RF630L Smartlabel 1.6 Technical data Table 1- 4 Memory specifications 6GT2810-2AB00 6GT2810-2AB01 6GT2810-2AB02 6GT2810-2AB03 Type EPC Class 1 Gen2 Memory organization EPC code 96 bit 96 bits/240 bits Additional user memory No 64 bytes Listing ISO 18000-6C Data retention at 10 years +25 °C...
  • Page 15: Dimension Drawings

    SIMATIC RF630L Smartlabel 1.7 Dimension drawings Dimension drawings Figure 1-3 SIMATIC RF630L 6GT2810-2AB00 dimension drawing Figure 1-4 SIMATIC RF630L 6GT2810-2AB01 dimension drawing Figure 1-5 SIMATIC RF630L 6GT2810-2AB02 dimension drawing SIMATIC RF630L Smartlabel Siemens Hardware Operating Instructions, 06/2009, J31069-D0186-U001-A4-7618...
  • Page 16 SIMATIC RF630L Smartlabel 1.7 Dimension drawings Figure 1-6 SIMATIC RF630L 6GT2810-2AB03 dimension drawing SIMATIC RF630L Smartlabel Operating Instructions, 06/2009, J31069-D0186-U001-A4-7618...
