User Manual
User Manual IQ216
Please read the manual carefully before using this charger.
We thank you that you have decided to purchase our intelligent charger.
Please follow the safety and care instructions in this manual, to be able to use this device
efficiently and safely.
Included Delivery:
• Charger IQ216
• Power supply
• User Manual
1/9

Advertisement

loading
Need help?

Need help?

Do you have a question about the IQ216 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AccuPower IQ216

Summary of Contents for AccuPower IQ216

  • Page 1 English User Manual User Manual IQ216 Please read the manual carefully before using this charger. We thank you that you have decided to purchase our intelligent charger. Please follow the safety and care instructions in this manual, to be able to use this device efficiently and safely.
  • Page 2 User Manual Important Notes: • Use the IQ216 charger only with rechargeable NiCd, NiMH cells. NiMH/NiCd: AAA / Micro, AA / Mignon, 9V E-Block • Do not use the charger with other types of batteries (for example: Alkaline or other Systems).

  • Page 3: Button Functions

    English User Manual Input: DC 12V / 2,0A Min. / ca. 24W Min. Output: Sixteen independent slots Approx. 1.49V / AA 1000 or 500mA Max. / AAA 500mA Max., 9V 30mA Max. Button Functions: • „MODE“ Button Display: During the charging process, the following values are shown on the display: •...

  • Page 4: Charging Function

    Therefore, the AA batteries are the only one, that could get charged with a current up to 1000mA (max.) by the charger. The automatically chosen current is set by the IQ216 depending on how many of the by-four-paired slots are occupied. If one or two slots of a foursome are used by AA sized batteries, then the current is set to 1000mA (max.).
  • Page 5 AAA battery 9V E-Block: It is also possible to charge 9V blocks with the IQ216. Therefore, you need to insert one or two blocks on the left-hand side of the LCD. Information’s about the charging state you can get from the beside LED for each slot.
  • Page 6 English User Manual The IQ216 charger also features a discharge function that is available on the last four slots (slot 13, 14, 15 and 16). For using this function, simply insert the batteries into the slots and double press the “MODE” button.
  • Page 7 English User Manual With the help of the “MODE” button you can choose different functions by a: Short Single Press: If you press the “MODE” button once for a short time, you active the LCD backlight. To save energy, the backlight stays on for approximately 30s and turns off automatically afterwards.
  • Page 8 English User Manual The chargers are maintenance free but should be cleaned sometimes. The charger should be disconnected from the power supply before cleaning. Use only soft and dry tissues (like cotton textiles) do not use any liquid. Disclaimer: • The manufacturer and supplier are not responsible for incorrect or improper use and the resulting consequences.
  • Page 9 336g for charger unit without AC Power supply AC Power supply: AC Input: 100-240V; DC Output: 12V / 2A Min. AccuPower Forschungs-, Entwicklungs- und Vertriebsgesellschaft mbH Pirchäckerstrasse 27, A-8053 Graz, AUSTRIA Tel.: +43 (0) 316 26 29 11-10; Fax: +43 (0) 316 26 29 11-36 E-Mail: info@accupower.at...
