Tekmar tekmarNet 402 Quick Setup Manual

tekmarNet ® 2 House Control 402
1.
Location
402
3.
Size Transformer
Zone
Thermostat Load
Zone Valve Load
Total Zone Load +
4.
Install Sensors
Outdoor Sensors
Sensor with rear
entry wiring
Pipe Sensors
Retaining Clip
Quick Setup Guide
402
1 2
+ +
Sensor with bottom
entry wiring
Universal
Sensor 082
Sensor Well
2.
Install Junction Box
3 4
Floating
Action (VA)
+ +
5.
Line Voltage Wiring
Sensor mounted
onto 2" x 4"
electrical box
N
L G
N
115 V (ac)
1 of 4
HVAC Systems Replaces: 06/09
OR
Control
Load (VA)
2
Back of House Control 402
Mix
(black)
Mix System Pump
Boil
(black)
Boil System Pump
DHW
(black)
DHW Pump
(red)
Pump Power L
L
Variable
(blue)
Speed Pump
Variable
Speed
to pump grounds
© 2010
Q 402
09/10
Transformer
must exceed:
VA
Strip wires
1/2 inch (13 mm).
Installed wires are
not removable.
12-18 AWG
Q 402 - 09/10
