2 Technical data

2.1 System and compatibility

All three variants can be combined with one RE7000 actuator (intended for lift function), one RE2000
(intended for leg spread) and a hand control. RCB20 and RCB25 have a 3
which can be used with for example an RE2000.
Figure 1. System and compatibility

2.2 Basic characteristics

Output voltage
No of actuator channels
IP-class
Battery type
Cycles/charge
Charge time
Weight
Flammability rating
Color
Expected service life
1
Provided that service schedule described in the user manuals are followed
RCB15 RCB20
24V DC 24V DC
2 3
IP24 IP26
Lead Lead
80 80
6 h 6 h
3 kg 3,5 kg
UL94 V-0 UL94 V-0
RAL 9016 RAL 9016
1
8 years 8 years
rd additional actuator output,
RCB25
24V DC
3
IP26
Lithium
150
3 h
2 kg
UL94 V-0
RAL 9016
1 1
8 years
2
