1 Introduction

1.1 About this manual

The aim with this user manual is to describe the control systems RCB15, RCB20 and RCB25 with focus
on:

Working principle descriptions

Safety

Maintenance

Troubleshooting
Next to this manual the following documentation is available:

RCB15 data sheet

RCB20 data sheet

RCB25 data sheet

RHC15 data sheet

REC20 data sheet

1.2 Symbols

The following symbols will be used in this document:
Failure to comply with these instructions may result in accidents involving personal injury.
Failing to follow these instructions can result in the product being damaged or destroyed.
Useful tips, recommendations and information for efficient, trouble-free use.

1.3 Product overview

REAC has three variants of control boxes, which each one together with a RCH15 hand control forms a
control system intended to be used in patient handling systems. The three boxes have different features
and functions:
RCB15: is a basic 2 channel control box designed to handle one lift actuator and one leg spread actuator.
RCB20: is a control box with up to 3 actuator channels and detachable lead batteries.
RCB25: is a light weight control box with a slim design. It can handle up to 3 actuator channels and has
detachable lithium batteries. Will be launched Q3 2017.

REC25 data sheet

RUT10 data sheet

RST10 data sheet

General Features in RST10
