2.6.1 Detachable batteries
RCB20 and RCB25 have a detachable battery pack, which can easily be removed when it's time for
charging or change to another battery pack.
Figure 4. Detachable battery
By pressing the release latch (A), holding the handle (B) and pulling the battery half upwards to detach the
batteries.
The removable batteries are not interchangeable between RCB20 and RCB25. They use different battery
types, having different specifications. Therefor a mechanical protection will make sure there is no mix up
between the two battery types (marked with red circles in the figure below).
Figure 5. Battery keying
The battery must be mounted while charging, if failing to do so will expose the charger poles
to the user and touching them can be unpleasant.
The battery keying must not be manipulated with. Wrong battery type will cause malfunction.
