IEC 61000-4-4 (2012)
IEC 61000-4-5 (2006)
IEC 61000-4-6 (2014)
IEC 61000-4-8 (2009)
IEC 61000-4-11 (2004)
RCB15, RCB20 and RCB25 are all designed to withstand electromagnetic interference. If
they are exposed to electromagnetic interference exceeding what is expected corrupted
behavior and permanent failures can occur.
Usage closely adjacent to or stacked with other equipment may result in improper operation.
During such use both the RCBS and the other equipment should be observed to verify that
they are operating normally.
Use of accessories other than those specified or provided by REAC, may result in increased
electromagnetic emissions or decreased electromagnetic immunity and result in improper
operation.
Portable RF communications equipment (including peripherals such as antenna cables and
external antennas) should be used no closer than 30 cm to any part of the RCBs, since this
may lead to degradation and improper performance.
Immunity to fast transients/burst
Test levels on AC Power input port: AC
input/output power input port ± 2,0 kV ncies in
ISM bands)
Surge immunity test
Test levels on AC Power input port: AC Power
input port, ±0,5 kV and ±1,0 kV differential
mode.
Immunity to conducted disturbances in the
frequency range 0,15 – 80 MHz
Test levels on AC Power input port: 6 Vrms
with 80 % AM @ 2 Hz.
Immunity to power frequency magnetic fields
Test level: 30 A/m, 50 Hz and 60 Hz
Voltage Dips and Interruptions
Test levels on AC Power input port:
Test frequency: 50 Hz.
Test voltages: 100 and 230 V.
100 % for ½ cycle positive and negative half
period.
60 % for 10 cycles.
30 % for 25 cycles.
100 % for 250 s.
