R25/R25LR
Total Station
User Manual
(August 2018)-Ver.1-Rev.1 – Firmware Version: 1.1.8.9G (20180615)
www.stonex.it

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R25LR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for STONEX R25LR

Summary of Contents for STONEX R25LR

  • Page 1 R25/R25LR Total Station User Manual (August 2018)-Ver.1-Rev.1 – Firmware Version: 1.1.8.9G (20180615) www.stonex.it...
  • Page 2 Dear Customer, Congratulations! We, STONEX, are proud to present you with these series instrument. Your total station is a rugged and reliable instrument whose performance and design are not surpassed. To fully appreciate and protect your investment, we suggest that you take the necessary time to read and fully understand this manual.

  • Page 3: Table Of Contents

    7.3. Setting orientation ....................................47 Programs ................................50 8.1. Surveying ......................................... 50 8.2. Stake out ........................................52 8.3. Free station ......................................55 8.4. COGO ........................................58 8.5. Tie distance ......................................64 8.6. Area & volume ...................................... 67 Stonex R25/R25LR Total Station - User Manual...
  • Page 4 Appendix I: Atmospheric correction formula and chart ..................118 Appendix II: Correction for refraction and earth curvature ................120 Appendix III: Technical drawing ..........................121 Limited warranty standard ............................122 Environmental recycling ............................125 Stonex R25/R25LR Total Station - User Manual...

  • Page 5: Precautions For Safety

    And the central fixing screw should be tight. High temperature condition Don’t put the instrument in high temperature condition for a long time, it is bad for the instrument performance. Temperature changing sharply Stonex R25/R25LR Total Station - User Manual...

  • Page 6: Definition Of Indication

    WARNING: Do not perform disassembly or rebuilding. Fire, electric shock or burns could result. Only STONEX • authorized distributors can disassemble or rebuilt. Do not collimate the sun directly. The eye injury or blind could result.

  • Page 7: Safety Standards For Laser

    Do not put the battery in the fire or high temperature condition. Explosion, damage could result. • Do not use the battery which is not specified by STONEX. Fire, electric shock or burn could result. • Do not use the power cable which is not specified by STONEX. Fire could result.

  • Page 8: About User

    The manufacturer assumes no responsibility for any damage, and loss of profits due to a change of • data, loss of data, an interruption of business etc., caused by using the product or an unusable product. Stonex R25/R25LR Total Station - User Manual...
  • Page 9 The manufacturer assumes no responsibility for any damage, and loss of profits caused by usage • except for explained in the user manual. The manufacturer assumes no responsibility for damage caused by wrong transport, or action due to • connecting with other products. Stonex R25/R25LR Total Station - User Manual...

  • Page 10: Nomenclature

    2. Nomenclature 2.1. Parts of the instrument Handle Optical sight Handle screw Eyepiece Instrument height mark Focusing knob Vertical motion screw Plate level Battery Screen SD card slot Tribrach & USB port Keypad Stonex R25/R25LR Total Station - User Manual...
  • Page 11 Objective Instrument height mark Model label Vertical motion screw Measure button RS-232C port Horizontal motion screw Leveling screw Circular level Tribrach clamp Stonex R25/R25LR Total Station - User Manual...

  • Page 12: Keyboard

    Confirm an entry or selection Escape key Quit a screen or edit mode without saving changes. FUNC Function key Perform sorts of fast function settings defined by program screen POWER Power key Turn on/off the instrument Stonex R25/R25LR Total Station - User Manual...

  • Page 13: Preparation Before Measurement

    Confirm the instrument is leveling, then press the {Power} red key and it will be turned on in no time. The instrument will display the status screen. Power off Press the {Power} key again and the screen will remind whether to power off. Stonex R25/R25LR Total Station - User Manual...

  • Page 14: About Battery

    The symbol only indicates the supply power but not the instantaneous power change. And if the • measurement mode changes, the symbol will not show the power’s decrease or increase immediately. It is suggested to check every battery power before field work. • Stonex R25/R25LR Total Station - User Manual...
  • Page 15 It is recommended to continue charging for 1 or 2 hours after the light turns green. • Once the red-light flashes constantly after the charger is plugged into the outlet of 100V-240V AC • power supply, please remove the battery and reconnected it after 3 or 5 min. Stonex R25/R25LR Total Station - User Manual...

  • Page 16: Setting Up The Instrument

    Move the foot screws A and B in opposite direction till the circular bubble is perpendicular to a line shaped with screw A and B. The direction of rotation in left thumb indicates the movement of the circular bubble. Stonex R25/R25LR Total Station - User Manual...
  • Page 17 Firstly, power on the instrument, press {FUNC} button, and then select “F1(Level/Plummet)”. The electronic level displays on screen. Secondly, level it by turning three-foot screws and ensure the bubble is in the plate level. Make sure that the black spot is in the center. Stonex R25/R25LR Total Station - User Manual...
  • Page 18 Repeat leveling and two steps until the instrument keeps leveling and the laser spot coincides with ground mark point when rotating alidade of instrument in any direction. After centering, please turn off laser plummet to save power. Stonex R25/R25LR Total Station - User Manual...

  • Page 19: Assembling And Disassembling For Three-Jaws Tribrach

    Screw out the fixed screw by driver to fix the clamp. NOTE: These designs, figures and specifications are subject to change without notice. We shall not be held liable for damages resulting from errors in this instruction manual Stonex R25/R25LR Total Station - User Manual...

  • Page 20: Basic Functions

    Level of the remaining battery The compensator is on Compensator mode The compensator is off Distance measurements with prism Long range distance measurements with prism Target type Distance measurements with sheet Distance measurements with no prism Stonex R25/R25LR Total Station - User Manual...

  • Page 21: Menu Diagram

    [HSET] Set the horizontal angle 4.2. Menu diagram Press the {MENU} key to enter the main menu. F1-F4 can be used to confirm menu selection. Scroll to next page with the {PAGE} key. Stonex R25/R25LR Total Station - User Manual...
  • Page 22 Auto-TP, Auto-Off Min. Reading, Angle Unit, Dist. Unit, Temp. Unit, Press. Unit, Code record Face I Definition, Data Output, Coord Format EDM Settings EDM Mode Prism Type Prism Constant Laser- Point Guide light Stonex R25/R25LR Total Station - User Manual...
  • Page 23 File Management Fixpoints Measurements Codes Initialize Memory Memory Statistic Mem Select File Copy Check & Adjust Hz-Collimation V-Index View-Adjustment- Value Tilt Offset Communication Parameters Baudrate Databits Parity Endmark Stopbits COMType Data Transfer Data Stonex R25/R25LR Total Station - User Manual...
  • Page 24 MENU Start-up sequence SystemI Battery Instrument Temperature Date Time SW_Info SoftWare, Inst. Type, Ins No. Stonex R25/R25LR Total Station - User Manual...

  • Page 25: System Information

    • YYYY.MM.DD. • Press F4[SET] to save. [TIME]: Press F2 to modify the time. Insert the time with the following format: HH:MM:SS. Then, press F4[SET]. [SW-Info]: Press F4 to see some instrument characteristics: Stonex R25/R25LR Total Station - User Manual...
  • Page 26 Here: Software: current software version; Inst. Type: indicates the specific type of this instrument; Ins No.: is the instrument serial number. Stonex R25/R25LR Total Station - User Manual...

  • Page 27: How To Input Number And Alphabet

    [CLEAR]: Place cursor on any position among character fields. Clear characters pressing F3 key. [ALF] / [NUM]: By pressing F4 key you can switch between numbers and letters .Here at entry status pressing F4 is equivalent to pressing {SHIFT} key. Stonex R25/R25LR Total Station - User Manual...

  • Page 28: Point Search

    PT*: All points of any length starting with "PT" are found (e.g.:PT1, PT12, PTAB). *1: All points of any length with a "1" as the second character are found (e.g.: A1, B12, A1C). Stonex R25/R25LR Total Station - User Manual...
  • Page 29 A*1: All points of any length with an "A" as the first character and a "1" as the third character are found. (e.g.: AB1, AA123, AT17). Stonex R25/R25LR Total Station - User Manual...

  • Page 30: Instrument Settings

    2-axis: the tilt correction is activated on both x and y axes direction; • Off: no tilt correction is activated. • Laser-Point: it turns on or off the laser beam for pointing target. Stonex R25/R25LR Total Station - User Manual...

  • Page 31: Settings

    For more informations, see 5.4. Function key. V-Setting: the zero of the vertical angle can be set with the following options: Zenit: the 0 is set when the objective is turned upwards in the vertical direction. Zenith=0°, • Horizontal=90°; Stonex R25/R25LR Total Station - User Manual...
  • Page 32 Hz Incre.: it allows to set the measurement direction: Right: Set right Hz for “clockwise direction measurement”; • Left: Set left Hz for “anti-clockwise direction measurement” .“Anti-clockwise” directions are only • displayed but saved as "clockwise direction". Stonex R25/R25LR Total Station - User Manual...
  • Page 33 °C: Celsius Degree; • °F: Fahrenheit Degree. • Press. Unit: the pressure unit can be selected in: Mbar: millibar; • hPa: hectoPascal; • mmHg: millimeter mercury column; • inHg: inch mercury column. • Stonex R25/R25LR Total Station - User Manual...
  • Page 34 Intern: all data is recorded in the internal memory. • Coord Format: It is possible to choose between two coordinate formats: N-E-Z; • E-N-Z. • After selecting the options, press key F4[SET] to save. Stonex R25/R25LR Total Station - User Manual...

  • Page 35: Edm Settings

    Prism: choose between one of the default prism types (see table below) or select “User Define” to set • manually the prism constant STONEX Prisms Constants [mm] Circle Prism -34.4 MINI -17.2 JPMINI Stonex R25/R25LR Total Station - User Manual...
  • Page 36 (see Appendix II: Correction for refraction and earth curvature); Humidity: atmospheric humidity at instrument location. [TIMES]: in the EDM setting menu press F2 to input the distance measuring times. Stonex R25/R25LR Total Station - User Manual...
  • Page 37 ] to scroll the black bar at the bottom of the display and then press F2[SIGNAL]. The EDM signal intensity (reflection intensity) is displayed in steps of 1%. It permits optimal aiming at distant barely visible targets. Stonex R25/R25LR Total Station - User Manual...

  • Page 38: Function Key

    T_Off- MP: Measurement point L_Off- L_Off+ OP: Offset point T_Off+ T_Off: Length offset L_Off: Cross offset H_Offset+: Height offset Input the offset values according to the sketch above: Stonex R25/R25LR Total Station - User Manual...
  • Page 39 NOTE: Deleting, the last record is not reversible! Only records which were recorded in "Surveying" or in "Measuring" can be deleted. Height Transfer: this function determines the height of the instrument from measurements to a maximum of 5 known target points, in two faces. Stonex R25/R25LR Total Station - User Manual...
  • Page 40 [ADDP] to add another height of a known point; • [FACEII] to measure the same target in the second face; • [PREV] to turn to the previous page; • [ENT] to save and set the station. • Stonex R25/R25LR Total Station - User Manual...
  • Page 41 The program allows measuring a point that is not directly visible, using a special hidden point rod. E, N, H of hidden point Rod length Distance R1-R2 Start defining the rod and the EDM settings, using the F4[ROD/ED] key: Stonex R25/R25LR Total Station - User Manual...
  • Page 42 Check Tie: calculation and display of the slope and horizontal distance, height difference, azimuth, grade, and coordinate differences between the last two measured points. Valid distance measurements are required for the Stonex R25/R25LR Total Station - User Manual...

  • Page 43: Communication Port Setting

    8: Data transfer is realized with 8 data bits. It is set automatically if parity is "None". • Parity: choose between “Even” or “Odd” if data bits is set to 7, “None” if data bits is set to 8. Endmark: choose between: CRLF: Carriage return; line feed; • Stonex R25/R25LR Total Station - User Manual...

  • Page 44: Start-Up Sequence

    A maximum of 16 of the next key presses are stored. The sequence is ended with [ESC]. If the start sequence is modified, the stored key presses will be executed automatically when the instrument is switched on. Stonex R25/R25LR Total Station - User Manual...

  • Page 45: Measurement

    Use the F3[SHIFT=0] key to set the 1st target as 0° in the measure mode. Confirm pressing F4[Yes] Sight the 2nd target. The displayed Hz value is the included angle between two points. Stonex R25/R25LR Total Station - User Manual...

  • Page 46: Distance Measurement

    Press {PAGE} key and the display mode of basic measurement will change: slope ( ), vertical ( ), horizontal ) distances or coordinates (North, Easth, Height) are shown. Press {PAGE} key to change display status if it is in distance mode. Stonex R25/R25LR Total Station - User Manual...
  • Page 47 An angle is also able to be measured while distance measurement is in course. • Measurement will automatically stop after a single measurement if the EDM mode is single. • Stonex R25/R25LR Total Station - User Manual...

  • Page 48: Pre-Setting Application

    Each coordinate computation relates to the set station. At least plan coordinates (E, N) are required for the station; the station height can be entered if required. The coordinates can be entered either manually or read from the internal memory. Stonex R25/R25LR Total Station - User Manual...

  • Page 49: Setting Orientation

    Known Point: press F1[FIND] or F2[LIST] to select a PtID stored in internal memory. • Input the instrument height and press F4[ENT] to finish station setting. 7.3. Setting orientation With the orientation, horizontal direction can be input manually or points with known coordinates can be set. Stonex R25/R25LR Total Station - User Manual...
  • Page 50 Press F2[ENH] to input backsight PointID and coordinate, after confirming this input continue entering reflector height and meantime sighting the target. At last press [ALL] to start trigger measurement, data saved and orientation set. Stonex R25/R25LR Total Station - User Manual...
  • Page 51 At the end of these procedures, press F4 in the start-up programs menu. Stonex R25/R25LR Total Station - User Manual...

  • Page 52: Programs

    Edit the individual point ID and press F1[ALL] key to measure and record it. Then, it will return to the PtID mode, with the name point as the one left before changing the mode. Three coding methods are available: Stonex R25/R25LR Total Station - User Manual...
  • Page 53 Quick coding: press the [Q-Code] softkey and enter the shortcut to the code. The code is selected, • and the measurement starts. Stonex R25/R25LR Total Station - User Manual...

  • Page 54: Stake Out

    To start staking out, in order to have enough time to find the point, it useful to change the EDM setting, applying a higher number of measurements. Press [EDM] softkey, then F2[TIMES] and set the number you prefer (refer to 5.3. EDM settings for more details). Stonex R25/R25LR Total Station - User Manual...
  • Page 55 Angle offset (positive if point to stake out is to the right of the actual direction) dHD: Distance offset (positive if point to stake out is further away) dVD: Height offset (positive if point to stake out is higher than measured point) Stonex R25/R25LR Total Station - User Manual...
  • Page 56 Stake out is based on a coordinate system and the offset is divided into a north and east element. 1: Actual point 2: Point to stake out dE: Easting offset between stake out and actual point. dN: Northing offset between stake out and actual point. dH: Offset height Stonex R25/R25LR Total Station - User Manual...

  • Page 57: Free Station

    The final height (H) is computed from averaged height differences based on the original • measurements. Before starting, in the start-up program menu it is required to set an accuracy limit: press F2 to enter the accuracy setting. Here: Stonex R25/R25LR Total Station - User Manual...
  • Page 58 [REC]: Save horizontal direction and vertical angle (resection); • [AddPt]: Input another backsight point; • [COMPUTE]: It’ll calculate and display the station coordinates, if • at least 2 points and a distance are measured. Stonex R25/R25LR Total Station - User Manual...
  • Page 59 Target points with 0.000 height are discarded for height processing. If target points have a valid height • of 0.000 m, use 0.001 m to enable it for height processing. Stonex R25/R25LR Total Station - User Manual...

  • Page 60: Cogo

    The explanation for the softkeys given below are valid for all pages, unless otherwise stated. Depending on the selected method, it will be required to input the following data: Point: it is possible to: • Measure a new point: press F1[MEASURE] to enter the measure mode; Stonex R25/R25LR Total Station - User Manual...
  • Page 61 Line: input the horizontal distance from the baseline start point • After having filled all the fields, press F3[CALC] to start the calculations. Use the {PAGE} key to see all the results on the screen. Press F4[REC] to save. Stonex R25/R25LR Total Station - User Manual...
  • Page 62 Unknown: C/D points with offset Bearing – Bearing Known: A First known point B Second known point α Direction from A to C β Direction from B to C Unknown: C Unknown point Stonex R25/R25LR Total Station - User Manual...
  • Page 63 Unknown: C First unknown point D Second unknown point By points Known: A First known point B Second known point C Third known point D Fourth known point Unknown: E Cross road point Stonex R25/R25LR Total Station - User Manual...
  • Page 64 BP: use the keys to select the baseline point from which start the extension. • ◄/► HD: edit the horizontal distance. To find a point inside the baseline, negative HD values are also • editable. Stonex R25/R25LR Total Station - User Manual...
  • Page 65 Known: A Baseline start point B Baseline end point d Distance Unknown: C Extended point Stonex R25/R25LR Total Station - User Manual...

  • Page 66: Tie Distance

    The instrument can accomplish this in two ways: Polygonal method: Measurement is A-B, B-C, C-D, etc... • Press F2[POLY] to select it Radial (A-B, A-C): Measurement is A-B, A-C, A-D, etc. • Press F3[RADIAL] to select it. Stonex R25/R25LR Total Station - User Manual...
  • Page 67 Select F1[ALL] to start measuring the target point or F2[FIND] to search for certain entered point from memory. Determine the second target point. Proceed as for the first target point. Results are displayed: Here: Stonex R25/R25LR Total Station - User Manual...
  • Page 68 [NEWP]: point 2 is set as starting point of a new missing line. Program starts from the second target point; [RADIAL]: switch to radial method. In radial method: • [CentPt]: determine new central point; [RadPt]: determine new radial point; [POLY]: switch to polygonal method. Stonex R25/R25LR Total Station - User Manual...

  • Page 69: Area & Volume

    Perimeter (2D), polygonal length from the start point to the current measured point of the area (2D) f: Area (2D), projected onto the horizontal plane g: Volume (2D) �� = �� • �� Stonex R25/R25LR Total Station - User Manual...
  • Page 70 [Def. 3D]: Define the sloped reference plane by measuring ([ALL] or [DIST]+[REC] softkeys), selecting • ([LIST] softkey) or editing ([ENH] softkey) three points. [FIND]/[LIST]: Search for point from internal memory. • [ENH]: Input the coordinates manually. • Stonex R25/R25LR Total Station - User Manual...

  • Page 71: Remote Height

    In the remote height main page press F4[ ] key to scroll the softkeys. Then, F1[Hr?] key to start the program that determines an unknown prism height. Start measuring base point with F1[ALL] or F2[DIST]+F3[REC]. Stonex R25/R25LR Total Station - User Manual...
  • Page 72 H which, as dVD, is the height difference between the ground and the inaccessible remote point. Edit the remote point name and save the measured data pressing F4[SAVE]. Otherwise, press F1[BasePt] to input and start measuring a new base point. Stonex R25/R25LR Total Station - User Manual...

  • Page 73: Reference Line/Arc

    F1[ALL] or F2[DIST]+F3[REC]; Input coordinates manually: Press [ENH] to input; • Find points from memory: Press [FIND] to search for PtID • entered or press [LIST] to choose from a series of points. Stonex R25/R25LR Total Station - User Manual...
  • Page 74 Then, decide to measure or stake out. Press F2[MEASURE] key to activate Line & Offset measuring or press F3[STAKE] key to start the application to stake out. Use F1[NewBL] to change the base line. Stonex R25/R25LR Total Station - User Manual...
  • Page 75 The program calculates the difference between a measured point and the calculated point. The program displays the orthogonal (Line, Offset, dVD) and the polar (dHz, dHD, dVD) differences. Press F2[MEASURE] key from the line-main menu. It will be required to input the orthogonal stake out elements. Stonex R25/R25LR Total Station - User Manual...
  • Page 76 Line is the longitudinal offset. If it is positive (arrow up), the stake out point is further away than the reference point; Offset is the transversal offset. If it is positive (arrow right), the stake out point is on the right of the reference point. Stonex R25/R25LR Total Station - User Manual...
  • Page 77 Measured points: Input PtID and measure base points with [ALL] or [DIST]+[REC]; • Input coordinates manually: Press [ENH] to input; • Find points from memory: Press [FIND] to search for entered PtID or press [LIST] to choose from a • series of point. Stonex R25/R25LR Total Station - User Manual...
  • Page 78 Notably there are four ways available for this application: Stake Out Point, Stake Out Arc, Stake Out Chord and Stake Out Angle. Stake Out Point This allows to stake out a point by entering a line and an offset value. Also negative values are editable. Stonex R25/R25LR Total Station - User Manual...
  • Page 79 Offset: Vertical distance from arc Here: Misclosure: if the input arc length is not an integer of the whole arc, there will be a closure. And three distribution ways are provided: Start Point, End Point and Average. Stonex R25/R25LR Total Station - User Manual...
  • Page 80 "Stake Out Arc" section. Offset SP: Start point of arc EP: End point of arc CP: Centre point of circle P: Point(s) to stake out CL: Chord length R: Radius Offset: Vertical distance from arc Stonex R25/R25LR Total Station - User Manual...
  • Page 81 Offset SP: Start point of arc EP: End point of arc CP: Centre point of circle P: Point(s) to stake out α R: Radius α α: Angle α Off: Vertical distance from arc Stonex R25/R25LR Total Station - User Manual...

  • Page 82: Construction

    Line is the longitudinal offset. If it is positive (arrow up), the target point is further away than the line; d Off is the transversal offset. If it is positive (arrow right), the target point is on the right of the line; Stonex R25/R25LR Total Station - User Manual...
  • Page 83 Press F1[RESET] if you want to set to 0 all the values Press F2[REVERE] to switch from positive to negative (and vice versa) the values. Press F4[ENT] to save the settings and turn to the stake out interface. Stonex R25/R25LR Total Station - User Manual...

  • Page 84: Lead Measure

    Closed traverse: coordinates of the first traverse point (point 1) and the last one (point 5) on the lead are known Closed traverse with a branch: coordinates of the first traverse point (point 1) and another point (point 0) are known. Stonex R25/R25LR Total Station - User Manual...
  • Page 85 First Stn: enter the name of the first survey station, from which the first observations will be done Lead Bs Pt: enter the name of the lead backsight point Start Brg: input the initial azimuth Stonex R25/R25LR Total Station - User Manual...
  • Page 86 • “SET”, otherwise the buzzer sounds and proceeding operation is impossible. If mistake is found after station setting succeeds, you need to press {ESC} key to quit the entire program • and reenter. Stonex R25/R25LR Total Station - User Manual...
  • Page 87 I and press F1[ALL] or F2[DIST]+F3[REC] to measure and save. After having measured the backsight and the foresight points, the following popup dialog displays: Turn the instrument to face II and repeat the measures: the following popup dialog displays: Stonex R25/R25LR Total Station - User Manual...
  • Page 88 Press {PAGE} key to switch to page 2, as shown. dX/N: misclosure of X coordinate increment dY/E: misclosure of Y coordinate increment dH: Vertical elevation closure P_Precision: Plane precision V_Precision: Vertical elevation precision Stonex R25/R25LR Total Station - User Manual...
  • Page 89 To use this data transfer option, it is necessary to have installed a proper software on your computer, • able to receive data from a RS232 port; Be sure that the communication port settings are set in the same way as on your computer; • Stonex R25/R25LR Total Station - User Manual...
  • Page 90 It is always possible, as alternative, to transfer data to PC using the USB or the external SD memory: on • the PC open the “LEAD” folder to see results. Stonex R25/R25LR Total Station - User Manual...

  • Page 91: Road

    In the input reference point dialog, press F1[SAVE] to save the new input of reference point; F4[PREV] to return to road define menu. NOTE: under input reference point mode, press the {ESC} fixed key to withdraw and return to reference point view menu. Stonex R25/R25LR Total Station - User Manual...
  • Page 92 Radius: except the end point of route, the “Radius” of any point represents the radius of curvature (“R” in the below figure) of one side preceding main point (Big stake mark direction). When route turns left, Stonex R25/R25LR Total Station - User Manual...
  • Page 93 F4[DELETE] to delete current displayed intersection point and other intersection points whose mileage • is larger than the current one, the erased data can’t resume. It's worth noting that, different from main point method, pressing DELETE key may lead to erase of several intersection points. Stonex R25/R25LR Total Station - User Manual...
  • Page 94 No matter what kind of method (main point or intersection point) you choose, normal stake out and • measuring can be executed based on the requirement of input of at least two valid records (two valid main points or intersection points). Stonex R25/R25LR Total Station - User Manual...
  • Page 95 Off.Back is the direction where prism worker faces the instrument as reference direction. And if the value is positive, prism worker should be aloof from the instrument. Conversely, prism worker should be close to the instrument; Stonex R25/R25LR Total Station - User Manual...
  • Page 96 [REC] to save stake out result and make stake mark increase by stake distance. • [ReStake] to make stake mark decreased by stake distance. • [ENH] to access “Stake Out Point Coordinates” dialog, and view design coordinates of point to be • stake out. Stonex R25/R25LR Total Station - User Manual...
  • Page 97 Remark: it can be used when saved as reference point, and its simple description of the reference point to be stored; Stn Milelage is the stake mark of current occupied station point (pressing [SaveAs], this field will made as point number); Stonex R25/R25LR Total Station - User Manual...
  • Page 98 Under Road Menu, press F3 key, and then display “Road Data View” dialog. As shown, this function is to realize data view of peg stake out and transect measure. All the results can be available for scan and deletion but not edit and modification. Peg data view Stonex R25/R25LR Total Station - User Manual...
  • Page 99 On “Road data view” menu, press F2 key to access “Transect data view” menu. Here: Mileage is the mileage corresponding to the transect; Wide is the offset distance that cross-sectional point deviates from centerline; H is the actual elevation of this measured point. Stonex R25/R25LR Total Station - User Manual...
  • Page 100 No: it won’t delete the same types of existed data. It is only selectable with “Download” transfer type. • Press F4[ENT] to save the new settings or F1[PREV] to go back to the Road menu. Stonex R25/R25LR Total Station - User Manual...

  • Page 101: Data Management

    F1[DELETE] to delete it; • F3[ADD] to start a new job; • F4[ENT] to set it. • NOTE: Deleting, the job can’t be undone. After confirming the message all data will be lost permanently. Stonex R25/R25LR Total Station - User Manual...
  • Page 102 ◄/► “Search” space. Code, Q-Code (which is an ID for the code), corresponding description and its maximum of 8 attributes (from Info1 to Info8) with up to 16 characters are shown. Here, press: Stonex R25/R25LR Total Station - User Manual...
  • Page 103 Press F4[DELETE] and F4[YES] to confirm. All data: press F1[ALL]. All data will be lost! • NOTE: Deleting, the memory can’t be undone. After confirming the message all data will be lost permanently. Stonex R25/R25LR Total Station - User Manual...
  • Page 104 Two methods of memory selecting are available: Inside SD and Extern SD. Select the former using F1 key, the latter using F2 key. 9.1.8. USB Press F4 in the second page of the file management menu. Stonex R25/R25LR Total Station - User Manual...

  • Page 105: Data Transfer

    “CASSMEAS” folder; the converted known point are in the “CASSCORD” folder. 9.2. Data transfer Press the {MENU} key and F3[DOWNL] at the second page of the menu to transfer data via RS232 port. Stonex R25/R25LR Total Station - User Manual...
  • Page 106 • to receive data from a RS232 port; be sure that the communication port settings are set in the same way as on your computer. • Stonex R25/R25LR Total Station - User Manual...

  • Page 107: Check And Adjustment

    If the difference is over ±3mm after the preceding operations, it is necessary to reset the instrument constant. Adjustment If it is necessary to reset the instrument constant, please contact STONEX service representative to perform that. Stonex R25/R25LR Total Station - User Manual...

  • Page 108: Plate Level

    Mount the instrument on a stable device and fix it. Level it accurately by the plate level. Observe the bubble of the circular level, if it is centered, no adjustment Circular Level is necessary, if not, you have to adjust it. Lever Stonex R25/R25LR Total Station - User Manual...

  • Page 109: The Optical Sight

    Mount the instrument on the tripod and fix it. Set a cross mark target which apart from the instrument about 50m. Take the telescope sight the cross mark. Loosen two fixing screws, adjust and fix the two screws again. Stonex R25/R25LR Total Station - User Manual...

  • Page 110: Laser Plummet

    Set a point A front the instrument 50m apart. Collimate the point A and adjust the vertical tangent screw; If the point appears to move continuously on the hair, adjustment is not required. Otherwise, adjust it. Stonex R25/R25LR Total Station - User Manual...

  • Page 111: Tilt Sensor

    Rotate the instrument 180°/200 gon. Wait a few seconds for the display to stabilize, then read the automatically compensated angles X2 and Y2. Calculate the following offset values (tilt zero-point error): ��1 + ��2 �������������� = ( Stonex R25/R25LR Total Station - User Manual...

  • Page 112: Horizontal Collimation Error C

    F4[NO] to give up this adjustment, 10.8. Horizontal collimation error C If the telescope’s sight line isn’t perpendicular to the horizontal axis, the collimation error will appear. The assembling, transportation and operation will cause this error. Check Stonex R25/R25LR Total Station - User Manual...
  • Page 113 The software will calculate the new collimation error and vertical index error automatically. press F3[YES] to renew the correction, or press F4: [NO] to give up this adjustment, Stonex R25/R25LR Total Station - User Manual...

  • Page 114: Vertical Index Error

    Because of the close relationship between vertical index and compensator zero position, it is necessary to check and adjust compensator zero position before adjusting vertical circle, the value should be stable when reading. Stonex R25/R25LR Total Station - User Manual...
  • Page 115 Press F3[ENT] to take face I. Aim at the cross-hair of collimator at telescope right, and it’ll display the horizontal and vertical angles. Press F3[ENT] to take face II. Stonex R25/R25LR Total Station - User Manual...

  • Page 116: Edm Optical Axis And The Telescope Sighting Axis Error

    Install the instrument at the tripod or a stable device and level it accurately, then power on the instrument. Set a reflective sheet about 5m-20m far away from the instrument. Aim at the sheet cross-mark with telescope reticle. Stonex R25/R25LR Total Station - User Manual...
  • Page 117 Observe the laser spot, if the laser spot coincides with the cross-mark of reflective sheet, adjustment is unnecessary. NOTE: Laser radiation—Avoid direct eye exposure. • If the instrument needs adjustment, please contact your local dealer. • Stonex R25/R25LR Total Station - User Manual...

  • Page 118: Technical Features

    Standard deviation based on ISO 17123-3 Good condition: no haze, visibility about 40km, no heat shimmer, breeze. Under optimal conditions on Kodak Grey Card (90% reflective) Class 1 Class 3R R25LR Model Standard deviation based on ISO 17123-4 Stonex R25/R25LR Total Station - User Manual...

  • Page 119: Kit Components

    USB communication cable • Lens cap • Tools kit • Cleaning cloth • User Manual • Reflective sheet/RP30 x4 • Reflective sheet/RP60 • Laser caution sign board • Silica gel • Certification • Stonex R25/R25LR Total Station - User Manual...

  • Page 120: Appendix I: Atmospheric Correction Formula And Chart

    The atmospheric value is obtained easily with the atmospheric correction chart. Find the measured temperature in horizontal axis, and pressure in vertical axis on the chart. Read the value from the diagonal line, which is the required atmospheric correction value. Stonex R25/R25LR Total Station - User Manual...
  • Page 121 Stonex R25/R25LR Total Station - User Manual...

  • Page 122: Appendix Ii: Correction For Refraction And Earth Curvature

    Refer to the 5.3. EDM setting to change the value. • These designs, figures and specifications are subject to change without notice. We shall not be held • liable for damages resulting from errors in this instruction manual. Stonex R25/R25LR Total Station - User Manual...

  • Page 123: Appendix Iii: Technical Drawing

    Appendix III: Technical drawing Stonex R25/R25LR Total Station - User Manual...

  • Page 124: Limited Warranty Standard

    STONEX® sales document or advice that may be provided to Customer by any STONEX® representative in connection with Customer’s purchase of the Product. No change to the conditions of this Limited Warranty is valid unless it is made in written form and signed by an authorized STONEX® supervisor. STONEX ® warrants that: Products are free from defects in materials or workmanship for generally 1/2 year except for accessories or specific parts for which different limited warranty period shall apply.
  • Page 125 In no event will STONEX®, its affiliates or suppliers be liable to customer or any third party for any damage in excess of the purchase price of the product.
  • Page 126 If dealer wants to repair an instrument under warranty period on their site: If dealers (don’t) have the part in stock they have to send an official order to STONEX® and pay for it and then so STONEX® will send the new part to them so they can repair the instrument.

  • Page 127: Environmental Recycling

    FOR COUNTRIES OUTSIDE EUROPEAN UNION (EU) The treatment, recycling, collection and disposal of electric and electronic devices may vary in accordance with the laws in force in the Country in question. Stonex R25/R25LR Total Station - User Manual...
  • Page 128 STONEX® SRL Via Cimabue, 39 - 20851 Lissone (MB) Tel : +390392783008 ; +390392785575 | Fax :+390392789576 www.stonex.it | info@stonex.it Stonex R25/R25LR Total Station - User Manual...

This manual is also suitable for:

R25

Table of Contents

Save PDF
