- Page 1 Moisture Pro Moisture Meter MP100 User Manual...
- Page 2 Moisture Pro Model：MP100 Introduction MP100 moisture meter measures the moisture content by detecting the electrical resistivity of the target material using two pins. The unit has adopted low consumption single chip smart design, the moisture content is displayed by LCD. The MP100 has the advantages of portable size, easy to operate and rapid measuring.
- Page 3 TOOLS COMPONENTS A．Protection cover B．Pins C．LCD screen D．Mild moisture indication LED E．Dry indication LED F．Measuring mode button G．Power button H．Excessive moisture indication LED I．Data hold button, keep pressing this button to close the buzzer sound J．At the back, it is battery compartment K．Protection cap for pins...
- Page 4 LCD Screen Illustration A：Low battery indication B：Measuring result C：Wood mode indication D：Data hold indication E：Building material mode indication Operation Notes ● Install battery Remove the battery lid on the back of the unit, place one 9V block battery（6F22 or 6LR61） according to the correct sign marked in the compartment, then put back the lid.
- Page 5 5、Under building material mode, reading of the target material is displayed on LCD screen, available range is 1.5%～33%. When it is lower than 1.5%, the screen shows” __ __ __”, when it is higher than 33%, the screen shows “￣ ￣ ￣”. 6、...
- Page 6 Notice: The warranty does not apply to the following conditions: Disassembling the laser tool will void the warranty. • Any damage resulting from, but not limited to wear, water, being dropped or repairs • attempted by others. www.imexlasers.com Copyright © Imex Group International 2017...
