- Page 1 Vision VE810 Engraver S5 Installation Guide © 2018 Vision Engraving & Routing Systems Part number 12-1085-01 Revised: 11/5/2018...
- Page 2 Vision VE810 Engraver S5 Installation Guide © 2018 Vision Engraving & Routing Systems All rights reserved. No parts of this work may be reproduced in any form or by any means - graphic, electronic, or mechanical, including photocopying, recording, taping, or information storage and retrieval systems - without the written permission of the publisher.
-
Page 3: Table Of Contents
2 General Electrical and Facility Requirements ........................... 6 3 VE810 Engraver Installation Layout ........................... 6 Part II Vision Software Installation Part III Machine Setup 1 Direct Connection to Computer ........................... 21 2 Network Connection ........................... 27 © 2018 Vision Engraving & Routing Systems... -
Page 4: Part I Introduction
Vision VE810 Engraver S5 Installation Guide Introduction This guide contains information to prepare the new owner of a Vision Express for the proper installation of their machine. It is the customer's responsibility to read through this guide and make sure the work area, electrical and computer requirements are met. -
Page 5: Computer Requirements
Operating System: Windows 10 (32/64 bit) Windows 8 (32/64 bit) Windows 7 SP.1 (32/64 bit) ***Requires Service Pack 1 Ports USB port for security dongle Local or network Ethernet port to connect machine © 2018 Vision Engraving & Routing Systems... -
Page 6: General Electrical And Facility Requirements
Optional Equipment One 110 VAC 15 Amp Engraving Vacuum Chip Removal System NOTE: In addition to the above requirements, a standard outlet is required for the computer. VE810 Engraver Installation Layout VE810 Layout Diagram © 2018 Vision Engraving & Routing Systems... -
Page 7: Part Ii Vision Software Installation
Introduction Vision Software Installation Insert the Vision USB dongle into the USB port on the computer. Navigate to the Devices and Drives area on your PC. Double click on the Vision icon to open the files on the USB dongle. - Page 8 Vision VE810 Engraver S5 Installation Guide The Vision S5 Software Wizard will guide you through the process of installing the software. Press Next to continue. Press Install to continue © 2018 Vision Engraving & Routing Systems...
- Page 9 Vision Software Installation Setup wizard will install the program. Select Finish to continue the software installation. Choose your preferred language and click ok. © 2018 Vision Engraving & Routing Systems...
- Page 10 Vision VE810 Engraver S5 Installation Guide The Vision 10 Setup Screen will appear. Press Next. After accepting the license agreement, click on the Next button. © 2018 Vision Engraving & Routing Systems...
- Page 11 Vision Software Installation Select Next (or change the destination folder - not recommended). Select Next to create the folder. © 2018 Vision Engraving & Routing Systems...
- Page 12 Vision VE810 Engraver S5 Installation Guide The installation will continue. © 2018 Vision Engraving & Routing Systems...
- Page 13 Vision Software Installation Select the VE810 S5 by placing a check mark in the box to the left of VE810 in the Manufacturer list, then select Next. If you purchase another engraving system from Vision, it can be added to the machine list at a later date from within the Vision software.
- Page 14 Vision VE810 Engraver S5 Installation Guide Select Continue to install True Type fonts and Vision Engraving Fonts on your computer. © 2018 Vision Engraving & Routing Systems...
- Page 15 Vision Software Installation Click yes to install all additional fonts from your C:\ Drive. All system fonts will be installed. © 2018 Vision Engraving & Routing Systems...
- Page 16 Vision VE810 Engraver S5 Installation Guide Press OK Press on the Finish button. © 2018 Vision Engraving & Routing Systems...
- Page 17 Vision Software Installation Press the Exit button . The Vision manuals icon should now appear on your computer's desktop along with an icon for your version of Vision 10 software. © 2018 Vision Engraving & Routing Systems...
-
Page 18: Part Iii Machine Setup
If the emergency stop screen appears on the LCD when the machine is powered on, then the emergency stop button is pressed in. Release the button twisting it until it "pops up". This will clear the emergency stop screen. © 2018 Vision Engraving & Routing Systems... - Page 19 The two options for connecting the VE810 to the computer are: - Direct connection to the computer or direct connection using a network hub or switch. Both of these methods require the same setup. - Connection through a company network © 2018 Vision Engraving & Routing Systems...
- Page 20 Vision VE810 Engraver S5 Installation Guide Follow the steps from one of the two sections below to configure the IP address depending on the connection type above. © 2018 Vision Engraving & Routing Systems...
-
Page 21: Direct Connection To Computer
Ethernet cable, power the machine on. The power switch for the VE810 is located on the power supply box for the machine. Once the machine has initialized, the home screen will appear on the LCD screen. Select the Settings Screen icon. © 2018 Vision Engraving & Routing Systems... - Page 22 Select the Connectivity Screen icon. Confirm that the LCD shows the Mode is set to static. If the Mode displays DHCP, press the mode icon. This will change the Mode to display Static. © 2018 Vision Engraving & Routing Systems...
- Page 23 The Mask value will be blank. Press the green check mark a second time and the mask will change to 255.255.255.0. If the Mask does not change to this value, enter it with the numbers on the LCD. © 2018 Vision Engraving & Routing Systems...
- Page 24 To set the computer's IP address, right click on the network icon in the lower right corner of the Windows desktop screen. Select "Open Network & Internet settings". (In Windows 7 and Windows 8 select "Open Network and Sharing Center") © 2018 Vision Engraving & Routing Systems...
- Page 25 Machine Setup Select "Change adaptor options". (In Windows 7 and Windows 8 select "Change adapter settings") Right click on the Ethernet adapter shown and select "Properties". © 2018 Vision Engraving & Routing Systems...
- Page 26 Select "Internet Protocol Version 4 (TCP/IPv5) and select "Properties". Select "Use the following IP address:" and enter 192.168.5.100 for the IP address and enter 255.255.255.0 for the Subnet mask. Select OK. The Windows network settings are the machine are now configured. © 2018 Vision Engraving & Routing Systems...
-
Page 27: Network Connection
VE810 is located on the power supply box for the machine. Once the machine has initialized, the home screen will appear on the LCD screen. Select the Settings Screen icon. Select the Connectivity Screen icon. © 2018 Vision Engraving & Routing Systems... - Page 28 Make a note of the address that is displayed. This will be needed at a later step in the setup. NOTE: If an IP address is not displayed, check with your network administrator to confirm that your network is configured for DHCP. Press the green check mark button. © 2018 Vision Engraving & Routing Systems...
- Page 29 Press the X to exit the connection screen. Press the X to return to the home screen. Open the Vision 10 Software by selecting the Vision Expert 10, Vision Express 10 or Vision Pro 10 icon from the Windows desktop.
- Page 30 Vision VE810 Engraver S5 Installation Guide In the Engraving defaults window select the setup button. Select the port tab. © 2018 Vision Engraving & Routing Systems...
- Page 31 Machine Setup In the "IP address" box, enter the IP address that was displayed on the Vision Express in a previous step. You can see this address from the machine home screen by pressing settings icon and then the connectivity screen icon.
- Page 32 Vision VE810 Engraver S5 Installation Guide Next, press Apply and OK to save the settings. The machine and Vision software are now configured. © 2018 Vision Engraving & Routing Systems...
- Page 33 Machine Setup © 2018 Vision Engraving & Routing Systems...
