1. Introduction
TRT products are a cost effective comprehensive
range of thermostats and timers designed for
internal use only.
The TRT034 is a single channel programmer,
with automatic summer winter time changeover
(which can be cancelled), 5 day plus 2 or 7
(individual) day programming with 3 on and
off operations per day, holiday mode, boost
function, advance to next program and
permanent on/off over ride.
The unit is fitted with a factory installed
battery which gives up to 24 hours back up
of time, date and programmes in the event of
a mains failure.
It is designed to be surface mounted on its
supplied wall plate.
The electrical supply must be isolated before
removing the thermostat from the wall plate.
TRT034 7 Day Digital Programmer
(normal position)
Shows when Time of day Day of
heat is programme, week
demanded flashes during
setting
Blue electro- Pull down Blue illuminated
luminescent flap for boost button
screen programming
Fig. 1
TRT034 7 Day Digital Programmer
(programming cover lowered)
Blue illuminated Advance/mode
light/holiday button
button
Stylish
design
Initiates programme
setting sequence and in
conjunction with the select
button initiates time and
date setting sequence
Fig. 1a
Up and down Border illuminates
buttons when +/- buttons
(used in are pressed and
programming) for 15 seconds
after release
select
Advance Mode
set
reset
Reset Selects time,
button temperature or
date to be changed
