BlueMod+S42/Central Software User Guide
1VV0301318 Rev. 3 – 2018-08-31
BlueMod+S42/Central
Software User Guide
1VV0301318 Rev. 3 – 2018-08-31
Reproduction forbidden without written authorization from Telit Communications S.p.A.- All Rights Reserved.
Page 1 of 66
