Air Handler Section Nomenclature Example - Addison RC/FC Series Installation Operation & Maintenance

2.4 - Air Handler Section Nomenclature Example

Digit: Description:
1 - 2 Product Family
3 Application
4 Operation Type
5 - 7 Nominal Capacity
8 Cabinet Size
9 Controls
10 Voltage
11 Vintage
12 Air Flow Orientation
Note: See unit data plate for specific configuration and options.
RC/FC Series Installation, Operation, and Maintenance Manual
FC = Air Handler
O = Dedicated Outdoor Air
R = Recirculating
A = Air Cooled
H = Air Source Heat Pump
042 = 3.5 Tons
048 = 4.0 Tons
060 = 5.0 Tons
072 = 6.0 Tons
096 = 8.0 Tons
120 = 10.0 Tons
150 = 12.5 Tons
180 = 15.0 Tons
210 = 17.5 Tons
240 = 20.0 Tons
300 = 25.0 Tons
360 = 30.0 Tons
420 = 35.0 Tons
A = A Cabinet
B = B Cabinet
C = C Cabinet
D = D Cabinet
E = E Cabinet
A = ALC, Standard Program, DOAS
B = ALC, Standard Program, Recirculating
C = ALC, Standard Program, DOAS with LON
D = ALC, Standard Program, Recirculating with LON
E = Controls by Others, Factory Mounted
F = Terminal Strip, Controls Provided and Mounted by Others
G = Remote Thermostat
H = Compressor Lockout Thermostat
2 = 208/60/3
3 = 230/60/3
4 = 460/60/3
H = Current
A = Vertical Cabinet, Vertical Supply
B = Horizontal Cabinet, Horizontal Supply
Feature:
