RC/FC Series Installation, Operation, and Maintenance Manual
Figure 7: Lineset Piping with the Air Handler Below the Condensing Unit
Slope Down Towards Condensing Unit 1" - 10'
Page 28 of 80
Liquid
Suction
Note: Add Additional Trap
for Each 20ft of Riser
Condensate Trap And Pipe
Slope Down From Air Handler
