RC/FC Series Installation, Operation, and Maintenance Manual

4.3 Hardware

Unless otherwise specified, all hardware (except sheet
metal screws) must be torqued to settings from Table 1.

4.4 Ship-With Parts

Some options (if selected) may include parts that will
require field installation. These parts are included loose
with the shipment of the unit, inside the control panel.
• Motor starter – Starter may include phase monitor
or VFD
• OA damper
• Over the blower electric heater are field-mounted at
least 5" above the air handler discharge
• SAT/RH Duct Sensor
• DPT Duct Sensor
Page 14 of 80

Table 1: Recommended Torque Settings

Bolt Head
Grade Marking
Nut
Grade Marking
Bolt Size: Grade 2:
10-24 27 in-Lb
1/4-20 65 in-Lb
5/16-18 11 ft-Lb
3/8-16 19 fl-Lb
8.8
8.8
Bolt Head
Grade Marking
8.8
8.8
Nut
Grade Marking
Bolt Size: Grade 2:
M5 6Nm
M6 10Nm
M8 25Nm
M10 50Nm
M12 85Nm
M16 215Nm
Grade 5:
42 in-Lb
101 in-Lb
17 ft-Lb
30 ft-Lb
10.9
10.9
10.9
10.9
Grade 5:
9Nm
15Nm
35Nm
75Nm
130Nm
315Nm
