Table 8: Hot Water Heating Coil Flow
Rate and Pressure Drop
Air Handler Model
042 - 072
096 - 120
150 - 210
240 - 360
420

Table 9: Superheat and Subcooling - 100% OA

Ambient Air
95°F
Temperature
Subcooling
Subcooling
Superheat
Note: Subcooling and superheat readings must be taken with the reheat circuit disabled and in the cooling mode.
Table 10: Superheat and Subcooling - Recirculating
Ambient Air
95°F
Temperature
Subcooling
Superheat
Note: Subcooling and superheat readings must be taken with the reheat circuit disabled and in the cooling mode.

Table 11: Superheat and Subcooling - Heat Pump

Ambient Air
95°F
Temperature
Subcooling
Superheat
Note: Subcooling and superheat readings must be taken with the reheat circuit disabled and in the cooling mode.
Page 54 of 80
Nominal GPM
Cabinet
(Water Only)
A 5.0
B 10.0
C 16.0
D 25.0
E 40.0
85°F
10° - 12°F
No Reheat
10 - 12°F
With Reheat
8°F - 15°F
85°F
10° - 12°F
8°F - 15°F
85°F
8° - 12°F
6°F - 15°F
Pressure Drop
(FT, H2O)
1.72
5.96
2.10
3.20
5.80
75°F 65°F
8° - 10°F
8°F - 12°F
6°F - 15°F
75°F 65°F
8° - 10°F
6°F - 15°F
75°F 65°F
8° - 10°F
55°F 45°F
In Heating Mode
In Heating Mode
In Heating Mode
55°F 45°F
6°F - 10°F
6°F - 10°F
55°F 45°F
In Heating Mode
In Heating Mode
