Table 13: Maintenance Guidelines, Cont.

15.6 Condensate Drain Pan and Drain

Assembly

15.7 Dampers

Dampers
Damper Motor/Linkages
15.8 Electric Heater Wiring and Wiring Connections
Assembly
Control Panel
Heating Elements

15.9 Filters

Assemblies
RC/FC Series Installation, Operation, and Maintenance Manual
Check for blockages. Clean as necessary with mixture of 1/2 cup [0.1 L] bleach and 1
gallon [1.9 L] warm water if signs of mold or algae are present.
Check and clean blades.
Verify that all damper linkages move freely. Lubricate if necessary.
Check all wiring connections. Tighten as necessary.
Check internal wiring. Replace as necessary with type THHN 221°F (105°C), 600V, 16
gauge wire or equivalent.
Check heater control panel for dust/dirt and moisture. Clean as necessary.
Check heating elements for dust/dirt build-up and/or broken elements. Replace
elements and /or clean elements with low pressure air as necessary.
Check element male/female chassis insulators for breaks and/or cracks. Replace
as necessary.
Check element support frame insulators. Replace missing or broken insulators
as necessary.
Filters should be checked for dirt restriction on a monthly basis (or as required).
Replace filters with filters of equal specification when they appear dirty.
