- Page 1 USER MANUAL www.qtech.ru...
-
Page 2: Table Of Contents
2.2.1 Verify the Package Contents 2.2.2 Required Tools and Utilities 2.3 Installation Guide 2.3.1 Installing the Switch 2.3.2 Connecting Console 2.3.3 SFP Transceiver Installation 2.3.4 QSW-2SFP+ extended module Installation 2.3.5 QSW-2GB Extended module Installation 2.3.6 Copper Cable/Fiber Cable Connection www.qtech.ru... - Page 3 2.3.7 AC Power Supply Connection 2.3.8 DC Power Supply Connection 2.3.9 PoE Power Supply Connection www.qtech.ru...
-
Page 4: Chapter 1 Introduction
Chapter 1. Introduction Chapter 1 INTRODUCTION 1.1 Overview QSW-8200 series switches are ethernet switch. QSW-8200 series switches are intelligent network management switch used by the network environment which needs the high performance, the bigger port density and the convenient installation. -
Page 5: Introduction To Product
SFP ports/1000Mb copper ports) and 2 slots with the extended cards. Secure Power Supply QSW-8200 series switches provide DC power backup, support 220V AC input, 48V DC input or 220V AC, 48V DC input simultaneously. Support 10Gb Ethernet 10Gb Ethernet which adopts full-duplex technology instead of low-speed, half-duplex CSMA/CD protocol, is a big leap in the evolution of Ethernet. -
Page 6: Physical Specifications
User Manual Chapter 1. Introduction QSW-8200 series switches, users can simplify network structures and reduce cost of network construction. Networking Protocols QSW-8200 series switches support 802.1d/w/s, 802.1Q, 802.1p, 802.3ad, 802.3x, GVRP, DHCP and SNTP etc; support IPv6 protocol. All these protocols supported enable QSW-8200 series switches to meet the requirements of complex network constructions. - Page 7 2 interfaces with extended card Managemen 1 Console port t ports System QSW-8200 series support AC/DC power input: power AC input: The rating voltage range: 100V~240V AC; 50/60HZ The max voltage range: 90V~264V AC; 47HZ～63HZ DC input: 48V DC input, -48V～-60V/DC;...
-
Page 8: Description Of Hardware
Fig 1-1 Front Panel of QSW-8200-28T-AC Fig 1-2 Front Panel of QSW-8200-28T-AC-DC Fig 1-3 Front Panel of QSW-8200-28T-POE-AC-DC QSW-8200-52T-AC series Ethernet switches provide 44 100/1000Base-TX auto negotiation ehternet ports, 4 1000Mb Combo ports, 6 function indicators and 1 Console port. www.qtech.ru... -
Page 9: Back Panel
Fig 1-7 Front Panel of QSW-8200-28F-AC-DC Fig 1-8 Front Panel of QSW-8200-28F-AC QSW-8200-52F-AC-DC ehternet switch provides 44 1000Mb fiber ports, 4 1000Mb Combo ports, 8 function LEDs and 1 Console port. Fig 1-9 Front Panel of QSW-8200-52F-AC-DC 1.4.2 Back Panel www.qtech.ru... - Page 10 Fig 1-14 Back Panel of QSW-8200-52T-AC-DC Fig 1-15 Back Panel of QSW-8200-52T-POE-AC-DC QSW-8200-28F-AC-DC supplies 2 interfaces with the extended card, 1 interface with -48V DC power input and 1 interface with 220V AC power input. Fig 1-16 Back Panel of QSW-8200-28F-AC-DC www.qtech.ru...
-
Page 11: Dc Power/Poe Power Input
Fig 1-19 Pin-outs Distribution of DC Input and PoE Power Input for QSW-8200 DC power has 3 pin-outs: PIN1: GND Ground connection PIN2: -48V DC power cathode input PIN3: 0V DC power positive electrode input PoE has 5 pin-outs: PIN1: GND Ground connection PIN2: -52V DC power cathode input www.qtech.ru... -
Page 12: Status Leds
Send or receive the data Green Port in link state Port not in link state Blink Send or receive the data The other is system LEDs, they are used to show the work status of the system at the right of front panel. www.qtech.ru... - Page 13 LED with double colors, each port of SFP linker corresponds two LEDs, detailed descriptions are shown in the following tables. Table 1-4 RJ45 Port LEDs Status Description Green port is at link state port is not at link state Blink Send or receive the data www.qtech.ru...
- Page 14 DIAG On (Green) System is operating normally On (Green) System is malfunctioning System is operating normally On (Green) System is using DC power System does not use DC power On (Green) M1-1 Port1 of M1 is at link state www.qtech.ru...
-
Page 15: Front Panel Interface Description
Port2 of M2 is not at link state, but M2 is in place 1.4.5 Front Panel Interface Description QSW-8200 series switches provide RJ-45 1000Mb copper port and the interface of SFP 1000Mb fiber transceivers. Each interface description is shown in the following: Table 1-7 QSW-8200 interface description www.qtech.ru... -
Page 16: Qsw-2Sfp+ / Qsw-2Gb Extended Module Description
SFP-GT SFP-GT module 1000Base-T SFP interface card module, RJ-45 interface 1.4.6 QSW-2SFP+ / QSW-2GB Extended Module Description QSW-8200 series switches provide 2 10GB extended slots to install 2 QSW-2SFP+ or QSW-2GB extended modules. Extended module model QSW-8200 series switch Extended module description... - Page 17 Figure 1-23 The back panel with extended modules for QSW-8200-28T-AC-DC / QSW-8200-52T-AC- Figure 1-24 The back panel with extended modules for QSW-8200-28T-POE-AC-DC / QSW-8200-52T- POE-AC-DC Figure 1-25 The back panel with extended modules for QSW-8200-28F-AC-DC / QSW-8200-28F-AC / QSW-8200-52F-AC-DC Extended module‘s LED description is the following: www.qtech.ru...
- Page 18 Ports are at the link state of 10G Blink(Green) Ports are at the active state of 10G No link or the link is failure QSW-8200 series switch supports the following SFP+ transceivers: Table 1-9 QSW-8200 series SFP+ transceivers description Spec SFP+-LR transceiver ...
-
Page 19: Chapter 2 Hardware Installation
The switch must be mounted to a standard 19’’ rack or placed on a clean level desktop. 2.1.1.1 Dust and Particles Dust is harmful to the safe operation of QSW-8200 series. Dust can lead to electrostatic adherence, especially likely under low relative humidity, causing poor contact of metal connectors or contacts. -
Page 20: Temperature And Humidity
The recommended temperature and humidity are shown below: Temperature: Relative humidity Long term Short term Long term Short term condition condition condition condition 15 ~ 30°C 0 ~ 50°C 40 ~ 65% 10 ~ 95% Table 2-3 Environmental Requirements: Temperature and Humidity www.qtech.ru... -
Page 21: Power Supply
Provide the system with a dedicated grounding, rather than sharing the grounding with the electronic equipment or lightning protection devices; Keep away from high power radio transmitters, radar transmitters, and high frequency strong circuit devices; Provide electromagnetic shielding if necessary. www.qtech.ru... -
Page 22: Rack Configuration
Caution！ If a standard 19’’ rack is not available, the QSW-8200 series can be placed on a clean level desktop, leave a clearance of 100mm around the switch for ventilation, and do not place anything on top of the switch. -
Page 23: Installation Preparation
Please unpack the shipping package and verify carefully the contents inside. 2.2.2 Required Tools and Utilities The required tools and utilities are shown below: Cross screwdrivers Flat-blade screwdriver ESD wrist strap Antistatic uniform Caution! Users should prepare the required tools and utilities by themselves. www.qtech.ru... -
Page 24: Installation Guide
User Manual Chapter 2. Hardware Installation 2.3 Installation Guide 2.3.1 Installing the Switch Fig 2-1 QSW-8200-28T-AC series installation sketch map on the rack series installation sketch map on the rack Fig 2-2 QSW-8200-52T-AC www.qtech.ru... -
Page 25: Connecting Console
Chapter 2. Hardware Installation Please mount QSW-8200 series on the 19’’ rack as below: 1. Attach the 2 brackets on the QSW-8200 series with screws provided in the accessory kit. 2. Put the bracket-mounted switch smoothly into a standard 19’’ rack. Fasten the QSW- 8200 series to the rack with the screws provided. -
Page 26: Sfp Transceiver Installation
2.3.4 QSW-2SFP+ extended module Installation QSW-8200 series provide 10Gb slots. The procedure for installing the QSW-2SFP+ module and the SFP+ 10Gb fiber transceiver is shown below: Step 1: Put on an ESD wrist strap (or antistatic gloves). -
Page 27: Copper Cable/Fiber Cable Connection
RX port of the corresponding device, and vice versa. Step 3: Check the fiber port status indicator, a lighted LED indicates that the link has been established; otherwise the link is not ready and should be examined. Caution! www.qtech.ru... - Page 28 3. When the switch is powered on, it executes self-test procedure and startups. Caution! The input voltage must be within the required range, otherwise the switch can be damaged or malfunction. Do not open the switch shell without permission. It can cause physical injury. www.qtech.ru...
- Page 29 The input voltage must be within the required range, otherwise the switch can be damaged or malfunction. PoE power supply of the front port is disabled when the switch is power-off or is not started. If there is any problem, do not open the switch shell without permission. It can cause physical injury. www.qtech.ru...
