- Page 1 HARDWARE INSTALLATION AND REFERENCE GUIDE QSW-6200 Series Switch Hardware Installation and Reference V1.0 www.qtech.ru...
- Page 2 This document is provided “as is”. The contents of this document are subject to change without any notice. Please obtain the latest information through the QTECH website. QTECH endeavors to ensure content accuracy and will not shoulder any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.
- Page 3 It is intended for the users who have some experience in installing and maintaining network hardware. At the same time, it is assumed that the users are already familiar with the related terms and concepts. Obtaining Technical Assistance QTECH Website: http://www.qtech.ru Technical Support: https://helpdesk.qtech.ru/ Related Documents...
-
Page 4: Product Overview
Series Switch Hardware Installation and Reference Guide 1 Product Overview QTECH QSW-6200 series switches are the next-generation Layer 3 switches. Featuring high performance, reliable security, and multiple services, QSW-6200 series switches are mainly applicable to the convergence layer of large-scale networks to provide full line-rate exchanging. - Page 5 When installing the unit, always make the ground connection first and disconnect it last. The device must be connected permanently to the protection ground before an operation. The cross sectional area of protective ground conductor shall be at least 0.75 mm². 1.1 QSW-6200-32T Technical Specifications Model QSW-6200-32T...
- Page 6 Product Appearance The QSW-6200-32T Ethernet switch provides 28 10/100/1000Base-T Ethernet ports, 4 GE SFP combo ports, 4 10GE SFP+ ports, 1 MGMT port, 1 USB port, 1 Mini USB port, and 1 Console port on the front panel, as well as 2 power module slots and 2 expansion module slots on the back panel (The Console and Mini USB ports are a combo Console port.
- Page 7 QSW-6200 Series Switch Hardware Installation and Reference Guide Figure 1-1 Appearance of QSW-6200-32T Front Panel Figure 1-2 Front Panel of QSW-6200-32T Note: 1. System status LED 7. Switch port status LED 2. Power status LED (PWR1) 8. USB port 3. Power status LED (PWR2) 9.
- Page 8 Heat Dissipation The QSW-6200-32T is designed with left and right fans for heat dissipation, thereby ensuring the normal function of the device in the specified environment. Maintain a minimum clearance of 10cm around the chassis to allow air circulation.
- Page 9 The port is connected at 10/100 Mbps. Blinking yellow The port is receiving or transmitting traffic at 10/100 Mbps. 10GE SFP+ port 29F-32F The port is not connected. status LED Solid green The port is connected at 1/10 Gbps. www.qtech.ru...
- Page 10 2 slots Slot Power Module 2 slots Slot AC input Rated voltage: 100V to 240V Maximum voltage: 90V to 264V Frequency : 50/60 Hz Rated current per input: 2A HVDC input Rated voltage: 120V to 340V www.qtech.ru...
- Page 11 1 USB port, 1 Mini USB port, and 1 Console port on the front panel, as well as 2 power module slots and 2 expansion module slots on the back panel (The Console and Mini USB ports are a combo Console port. When they are connected meanwhile, the Mini USB port takes the precedence). www.qtech.ru...
- Page 12 8. USB port 3. Power status LED (PWR1) 9. Mini USB port 4. MGMT port status LED 10. MGMT port 5. Console port 11. 10GE SFP+ port 6. 10/100/1000Base-T auto-sensing Ethernet port Back Panel Figure 1-7 Back Panel of QSW-6200-52T www.qtech.ru...
- Page 13 QSW-6200-52T adopts left and right fans for heat dissipation, thereby ensuring the normal function of the device in the specified environment. Sufficient space (10 cm distance from both sides and the back panel of the cabinet) should be reserved around the cabinet to allow air circulation. Figure 1-8 Flow Scheme of Heat Dissipation Panel Identification State Meaning www.qtech.ru...
- Page 14 The port is receiving or transmitting traffic at 10/100 Mbps. 10GE SFP+ port 49F-52F The port is not connected. status LED Solid green The port is connected at 1/10 Gbps. Blinking green The port is receiving or transmitting traffic at 1/10 www.qtech.ru...
- Page 15 Rated current per input: 2 A HVDC input: Rated voltage: 120V to 340V Maximum voltage: 110V to 380V Rated current per input: 2A DC input: Rated voltage: -36V to -72V Rated current per input: 3.15A SFP Port 100Base-X 1000Base-X SFP+ Port 10GBbase-R www.qtech.ru...
- Page 16 1 MGMT port, 1 USB port, 1 Mini USB port, and 1 Console port on the front panel, as well as 2 power module slots and 2 expansion module slots on the back panel. Figure 1-9 Appearance of QSW-6200-32F Front Panel www.qtech.ru...
- Page 17 The QSW-6200-32F is designed with left and right fans for heat dissipation, thereby ensuring the normal function of the device in the specified environment. Sufficient space (10 cm distance from both sides and the back panel of the cabinet) should be reserved to allow air circulation. www.qtech.ru...
- Page 18 Check the working environment of the switch and power supplies immediately. Solid red The switch is faulty. For details, see the chapter “Troubleshooting”. Power status LED PWR1/PWR2 The power module is not in place or not receiving power. www.qtech.ru...
- Page 19 The port is connected at 1000 Mbps. Ethernet port status Blinking green The port is receiving or transmitting traffic at 1000 Mbps. Solid yellow The port is connected at 10/100 Mbps. Blinking yellow The port is receiving or transmitting traffic at 10/100 Mbps. www.qtech.ru...
-
Page 20: Expansion Modules
1.4 Expansion Modules The QSW-6200-52T series switches support the following modules: QSW-M-6200-4SFP+ and QSW-M-6200-STACK. QSW-M-6200-4SFP+ is only supported on the expansion module slot 1 of QSW-6200-52T. The QSW-6200-32T and QSW-6200-32F series switches support the QSW-M-6200-STACK module. Module Description External port... - Page 21 Power Supply Alarm Alarms power supply faults through the power status LED. Panel Identification State Meaning Status LED DC OK There is no power input or input under voltage. Solid green The module is operational. www.qtech.ru...
- Page 22 Hot Swapping Supports to disconnect one redundant power module from the outside power supply system, plug and unplug power modules while the device is powered on. Power Supply Alarm Alarms power supply faults through the power status LED. www.qtech.ru...
- Page 23 QSW-6200 Series Switch Hardware Installation and Reference Guide Panel Identification State Meaning Status LED There is no power input or input under voltage. Solid green The module is operational. www.qtech.ru...
-
Page 24: Preparation Before Installation
Any non-standard and impropriate electric operations may cause an accident such as a fire or electrical shock, thus causing severe even fatal damage to human bodies and equipment. Direct or indirect touch through a wet object on high-voltage and commercial electricity may bring a fatal danger. www.qtech.ru... -
Page 25: Installation Site Requirements
Make sure the air vent of the machine room is away from the sewage pipe, septic tank, and sewage treatment tank. Keep the machine room under positive pressure to prevent corrosive gas from entering the machine room to corrode components and circuit boards. Keep the machine room away from industrial boiler and heating boiler. www.qtech.ru... -
Page 26: Temperature And Humidity
Such electrostatic adherence may occur more easily when the relative humidity is low, not only affecting the use life of the equipment, but also causing communication faults. The following table shows the requirements for the dust content and granularity in the equipment room. www.qtech.ru... - Page 27 The grounding required for EMC design includes shielding grounding, filter grounding, noise and interference suppression, and level reference. All the above constitute the comprehensive grounding requirements. The grounding resistance should be less than 1Ω. The QSW-6200 back panel has one grounding connector. Figure 2-1 Grounding of the QSW-6200 www.qtech.ru...
-
Page 28: Lightning Resistance
Electromagnetic shielding methods should be applied when necessary, such as using the shielded cable as the interface cable. Cables must be connected to interfaces inside the room to prevent damage to the device’s signal ports caused www.qtech.ru... -
Page 29: Precautions For Fiber Connections
List of Installation Tools Common Tools Phillips screwdriver, flat-head screwdriver, related electric cables and optical cables, bolts, diagonal pliers, straps Anti-static tools Special Tools Meters Multimeter QSW-6200 is not provided with a tool kit. Please prepare tools on your own. www.qtech.ru... -
Page 30: Product Installation
The switch should be located far away from the large power radio launch pad, radar launch pad, and high-frequency large-current devices. If necessary, electromagnetic shielding should be adopted. For example, use interface cables to shield cables. Interface cables should be laid inside the equipment room. Outdoor cabling is prohibited, avoiding damages to www.qtech.ru... -
Page 31: Mounting The Switch In A Standard 19-Inch Rack
Figure 3-2 Attaching the Mounting Brackets to the Switch for Wall-Mounting 3.3.3 Mounting the Switch on a Table For often, users may not have a 19-inch rack. Thus, it is common to mount the switch on the workbench with 2 simple steps: www.qtech.ru... - Page 32 Step 2: Install a baffle in the power module slot and put the removed power module into its package. Figure 3-4 Removing a Power Module www.qtech.ru...
- Page 33 Step 3: Connect the other ends of power cables to the DC panelboard: connect the blue one to the -48VDC terminal, the red one to -48VGND, and the yellow-green one to PGND. Figure 3-7 Installing a Power Module Figure 3-7 Connecting Power Cables to the DC Panelboard www.qtech.ru...
- Page 34 Figure 3-9 Removing a Power Module Remove the power module uprightly and slowly. Install a baffle in the location where the power module is removed to ensure the normal ventilation and dissipation and avoid the dust in the chassis. www.qtech.ru...
-
Page 35: Grounding The Switch
Step 2: Insert the single-mode or multi-mode fiber into the appropriate interface according to the identification on the panel of the module. Step 3: Insert the twisted pair with the RJ45 port into the appropriate interface according to the identification on the panel of the module. Distinguish the crossover cable and straight-through cable. www.qtech.ru... -
Page 36: Bundling The Cables
Check that all interface cables are laid out inside the equipment room. In the case of external cabling, check that the lightning resistance socket or network interface lightning protector is connected. Check that sufficient airflow is available around the device (over 10 cm). www.qtech.ru... -
Page 37: System Commissioning
If both the Mini USB port and Console port are connected, the default Console port is the former. When the Mini USB port is connected to PCs, besides the Mini USB Console driver should be installed on PCs and the cable connector is different, other configuration is the same as that of the serial port. www.qtech.ru... - Page 38 Choose Setup > Program > Attachment > Communication > Super Terminal. Choose Cancel to display the following page. Figure 4-2 Enter the name of the new connection and click OK to display the following page. Choose the series port used currently in the column [use when connecting]. Figure 4-3 www.qtech.ru...
-
Page 39: Power-On Startup
The console cable is correctly connected; the terminal (can be a PC) used for configuration is already started; the parameters are already configured. Checking after Power-on (Recommended) After power-on, you are recommended to perform the following checks to ensure the normal operation of follow-up configurations. www.qtech.ru... - Page 40 QSW-6200 Series Switch Hardware Installation and Reference Guide Check that information is displayed on the terminal interface. Check that the device LEDs are normal. www.qtech.ru...
-
Page 41: Monitoring And Maintenance
For the configuration and functions, refer to the Configuration Guide. 5.1 Hardware Maintenance Expansion Module Maintenance If any fault occurs and an expansion module shall be replaced, remove it and install a new one according to the section “Installing and Removing the Expansion Modules”. www.qtech.ru... - Page 42 Please contact the TAC of QTECH for replacing lithium batteries. Technical staff of QTECH will replace the battery of the same model. Replacing Fuses Please contact the TAC of QTECH for replacing fuses. Technical staff of QTECH will replace the fuse of the same model. www.qtech.ru...
-
Page 43: General Troubleshooting Flowchart
Make sure that the optical fibers or cables are correctly connected to the ports. Contact QTECH Customer Service Department for any hardware failure. 6.2 Troubleshooting Common Faults Fault 1: The password to login the management interface is lost. - Page 44 Series Switch Hardware Installation and Reference Guide that described in Configuration Guide. If not, modify the serial port configuration parameters. If there is still no serial port printed information, please contact TAC of QTECH for technical support. Fault 4: The serial port console outputs illegible characters.
- Page 45 100-ohm Category-5 cables for 100 Mbps, both of which can be up to 100 m. 0 shows the pinouts of the 100BASE-TX/10BASE-T. Figure A-2 Pinouts of the 100BASE-TX/10BASE-T Figure A-3 shows the straight-through and crossover cable connections for the 100BASE-TX/10BASE-T. www.qtech.ru...
- Page 46 Optical Fiber Connection For the optical fiber ports, select single-mode or multiple-mode optical fibers for connection according to the fiber module connected. The connection schematic diagram is shown in Figure A-4: Figure A-4 Schematic Diagram for optical fiber connection www.qtech.ru...
- Page 47 L line is on the left and the N line is on the right, the polarity of the arrester power cable shall be reversed; if the LED is still Red, it is confirmed that the arrester PE terminal has not been grounded. www.qtech.ru...
- Page 48 Figure B-2 Schematic Diagram for the Ethernet port Arrester Installation The Ethernet port arrester is only for the 10M/100M copper Ethernet ports with the RJ-45 connector; The Ethernet port arrester is not provided, the user can purchase them to address their own pratical requirements. www.qtech.ru...
- Page 49 Use the multimeter to confirm the contact condition after the grounding. Incomplete arrester installation. If there is more than one port connected to the peer device on the switch, it needs to install the arresters on all connection ports for the purpose of the lightning protection. www.qtech.ru...
- Page 50 During cabling of an optical fiber, the bend radius of the fiber should be equal to or greater than 10 times the diameter of the fiber. Precautions for Cable Bundling Before bundling cables, correctly mark labels and stick the labels to cables where appropriate. Cables should be neatly and properly bundled, as shown in Figure C-1. www.qtech.ru...
- Page 51 If cables are to be bent, bind them first but do not tie cable ties within the bend to avoid stress on the cables, which may otherwise cause the wires inside to break, as shown in Figure C-3. www.qtech.ru...
- Page 52 When using screws to fasten cable lugs, the bolts or nuts shall be tightened and prevented from loosening, as shown in Figure C-4. Figure C-4 Fastening Cable Lugs Spring washer Flat washer Note Flat washer When using a stiff cable, fix it near the cable lug to avoid stress on the lug and cable. www.qtech.ru...
- Page 53 10 to 30 150 to 200 200 to 300 Do not tie knots for cables or cable bundles. The metal parts of the cold-pressed terminal blocks, such as air circuit breakers, shall not be exposed outside of the blocks. www.qtech.ru...
- Page 54 32-bit Windows XP, 64-bit Windows XP, 32-bit Window Vista, 64-bit Window Vista, 32-bit Windows 7, and 64-bit Windows 7. Installation Steps Step 1: Double click the Setup file and choose Next. Step 2: Accept the License Agreement and click Next. www.qtech.ru...
- Page 55 QSW-6200 Series Switch Hardware Installation and Reference Guide Step 3: Select the unpackage directory and click Install. Step 4: After the driver is installed, click Finish. www.qtech.ru...
- Page 56 Right click Computer, choose Manage-Device Manager-Ports (COM & LPT), you will see the TUSB3410 Device. Change the serial port number to the port number of TUSB3410 Device, and then perform system commissioning. If you cannot find TUSB3410 Device there, re-install it or change the Type-A USB to Mini USB cables. www.qtech.ru...
